ASTM B719-20

Standard Specification for Nickel-Chromium-Molybdenum-Cobalt-Tungsten-Iron-Silicon Alloy Bar

ABSTRACT
This specification covers the standard for hot-finished and cold-finished UNS N06333 alloy bars and flats proposed for use in heat resisting applications and general corrosive service. Materials shall conform to mechanical properties of the material such as tensile strength, yield strength, elongation, and hardness. Each specimen will be subjected to a chemical analysis, tension, Brinell hardness, and Rockwell hardness test.
SCOPE
1.1 This specification covers wrought alloy UNS N06333 in the form of hot-finished and cold-finished bars and flats intended for heat resisting applications and general corrosive service.
1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to become familiar with all hazards including those identified in the appropriate Material Safety Data Sheet (MSDS) for this product/material as provided by the manufacturer, to establish appropriate safety, health, and environmental practices, and determine the applicability of regulatory limitations prior to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 31-Mar-2020
• ICS: 77.120.40 - Nickel, chromium and their alloys
• Technical Committee: B02 - Nonferrous Metals and Alloys
• Drafting Committee: B02.07 - Refined Nickel and Cobalt and Their Alloys

Standards Content (Sample)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation:B719 −20
Standard Specification for
Nickel-Chromium-Molybdenum-Cobalt-Tungsten-Iron-Silicon
1
Alloy Bar
This standard is issued under the fixed designation B719; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope* E18 Test Methods for Rockwell Hardness of Metallic Ma-
terials
1.1 This specification covers wrought alloy UNS N06333 in
E29 Practice for Using Significant Digits in Test Data to
the form of hot-finished and cold-finished bars and flats
Determine Conformance with Specifications
intended for heat resisting applications and general corrosive
E140 Hardness Conversion Tables for Metals Relationship
service.
Among Brinell Hardness, Vickers Hardness, Rockwell
1.2 The values stated in inch-pound units are to be regarded
Hardness, Superficial Hardness, Knoop Hardness, Sclero-
as standard. The values given in parentheses are mathematical
scope Hardness, and Leeb Hardness
conversions to SI units that are provided for information only
E1473 Test Methods for Chemical Analysis of Nickel, Co-
and are not considered standard.
balt and High-Temperature Alloys
1.3 This standard does not purport to address all of the
safety concerns, if any, associated with its use. It is the
3. Terminology
responsibility of the user of this standard to become familiar
3.1 Definitions of Terms Specific to This Standard:
with all hazards including those identified in the appropriate
3.1.1 bars, n—material of round, hexagonal, octagonal, or
Material Safety Data Sheet (MSDS) for this product/material
1
square solid section, furnished in straight lengths, ⁄4 in. (6.35
as provided by the manufacturer, to establish appropriate
mm) and over in diameter or size.
safety, health, and environmental practices, and determine the
1
applicability of regulatory limitations prior to use. 3.1.2 flats, n—material ⁄4 to 10 in. (6.35 to 254 mm),
1.4 This international standard was developed in accor- inclusive, in width and 120 in. (3.05 mm) and over in
dance with internationally recognized principles on standard- thickness.
ization established in the Decision on Principles for the
Development of International Standards, Guides and Recom-
4. Ordering Information
mendations issued by the World Trade Organization Technical
4.1 It is the responsibility of the purchaser to specify all
Barriers to Trade (TBT) Committee.
requirements that are necessary for the safe and satisfactory
performance of material ordered under this specification.
2. Referenced Documents
Examples of such requirements include, but are not limited to,
2
2.1 ASTM Standards:
the following:
B880 Specification for General Requirements for Chemical
4.1.1 Alloy name or UNS number.
Check Analysis Limits for Nickel, Nickel Alloys and
4.1.2 Quantity.
Cobalt Alloys
4.1.3 ASTM Designation and year of issue.
E8 Test Methods for Tension Testing of Metallic Materials
[Metric] E0008_E0008M 4.1.4 Section (round, square, hexagonal, and so forth).
E10 Test Method for Brinell Hardness of Metallic Materials
4.1.5 Dimensions, including length.
4.1.6 Finish, hot or cold.
4.1.7 Certification—state if certification is required (Section
1
This specification is under the jurisdiction of ASTM Committee B02 on
Nonferrous Metals and Alloys and is the direct responsibility of Subcommittee 16).
B02.07 on Refined Nickel and Cobalt and Their Alloys.
4.1.8 Samples for Product (Check) Analysis—State whether
Current edition approved April 1, 2020. Published April 2020. Originally
samples shall be furnished.
approved in 1983. Last previous edition approved in 2014 as B719 – 00 (2014).
DOI: 10.1520/B0719-20.
4.1.9 Purchaser Inspection—If a purchaser wishes to wit-
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or
ness tests or inspections of material at the place of
contact ASTM Customer Service at [e-mail]. For Annual Book of ASTM
manufacture, the purchase order must so state indicating which
Standards volume information, refer to the standard’s Document Summary page on
the ASTM website. tests or inspections are to be witnessed.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1

---------------------- Page: 1 ----------------------
B719−20
TABLE 2 Mechanical Properties
5. Material and Manufacture
Elongation
5.1 All material shall be furnished in the annealed Tensile Yield Strength,
in 2 in. or
...

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: B719 − 00 (Reapproved 2014) B719 − 20
Standard Specification for
Nickel-Chromium-Molybdenum-Cobalt-Tungsten-Nickel-
Chromium-Molybdenum-Cobalt-Tungsten-Iron-Silicon
1
Iron-Silicon Alloy (UNS N06333) Bar
This standard is issued under the fixed designation B719; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope Scope*
1.1 This specification covers wrought alloy UNS N06333 in the form of hot-finished and cold-finished bars and flats intended
for heat resisting applications and general corrosive service.
1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical
conversions to SI units that are provided for information only and are not considered standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to become familiar with all hazards including those identified in the appropriate Material Safety Data
Sheet (MSDS) for this product/material as provided by the manufacturer, to establish appropriate safety safety, health, and
healthenvironmental practices, and determine the applicability of regulatory limitations prior to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2
2.1 ASTM Standards:
B880 Specification for General Requirements for Chemical Check Analysis Limits for Nickel, Nickel Alloys and Cobalt Alloys
E8 Test Methods for Tension Testing of Metallic Materials [Metric] E0008_E0008M
E10 Test Method for Brinell Hardness of Metallic Materials
E18 Test Methods for Rockwell Hardness of Metallic Materials
E29 Practice for Using Significant Digits in Test Data to Determine Conformance with Specifications
E140 Hardness Conversion Tables for Metals Relationship Among Brinell Hardness, Vickers Hardness, Rockwell Hardness,
Superficial Hardness, Knoop Hardness, Scleroscope Hardness, and Leeb Hardness
E1473 Test Methods for Chemical Analysis of Nickel, Cobalt and High-Temperature Alloys
3. Terminology
3.1 Definitions of Terms Specific to This Standard:
1
3.1.1 bars, n—material of round, hexagonal, octagonal, or square solid section, furnished in straight lengths, ⁄4 in. (6.35 mm)
and over in diameter or size.
1
3.1.2 flats, n—material ⁄4 to 10 in. (6.35 to 254 mm), inclusive, in width and 120 in. (3.05 mm) and over in thickness.
4. Ordering Information
4.1 It is the responsibility of the purchaser to specify all requirements that are necessary for the safe and satisfactory
performance of material ordered under this specification. Examples of such requirements include, but are not limited to, the
following:
1
This specification is under the jurisdiction of ASTM Committee B02 on Nonferrous Metals and Alloys and is the direct responsibility of Subcommittee B02.07 on Refined
Nickel and Cobalt and Their Alloys.
Current edition approved Oct. 1, 2014April 1, 2020. Published October 2014April 2020. Originally approved in 1983. Last previous edition approved in 20092014 as
B719 – 00 (2009).00 (2014). DOI: 10.1520/B0719-00R14.10.1520/B0719-20.
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at [e-mail]. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1

---------------------- Page: 1 ----------------------
B719 − 20
4.1.1 Alloy name or UNS number.
4.1.2 Quantity.
4.1.3 ASTM Designation and year of issue.
4.1.4 Section (round, square, hexagonal, and so forth).
4.1.5 Dimensions, including length.
4.1.6 Finish, hot or cold.
4.1.7 Certification—state if certification is required (Section 16).
4.1.8 Samples for Product (Check) Analysis—State whether samples shall be furnished.
4.1.9 Purchaser Inspection—If a purchaser wishes to witness tests or inspections of
...
