ASTM F2945-18(2023)

Standard Specification for Polyamide 11 Gas Pressure Pipe, Tubing, and Fittings

ABSTRACT
This specification covers requirements and test methods for the characterization of polyamide 11 pipe, tubing, and fittings for use in fuel gas piping. The pipe and fittings covered by this specification are intended for use in the transport of fuel gases. This specification does not cover threaded pipe. The polyamide 11 material used to make pipe and fittings shall be virgin or reworked material and shall have a Plastics Pipe Institute (PPI) long-term hydrostatic design stress and hydrostatic design basis rating as determined per PPI TR3 and PPI TR4. This specification deals with requirements for materials, requirements for pipe and fittings, test methods, marking, and quality Assurance.
SCOPE
1.1 This specification covers requirements and test methods for the characterization of polyamide 11 pipe, tubing, and fittings for use in fuel gas pipelines. The pipe and fittings covered by this specification are intended for use in the distribution and transmission of fuel gases.
1.1.1 This specification does not cover threaded pipe. Generic fusion guidelines are given in Appendix X1. Design considerations are discussed in Appendix X2. In-plant quality control programs are specified in Annex A1.
1.2 The text of this specification references notes, footnotes, and appendixes which provide explanatory material. These notes and footnotes (excluding those in tables and figures) shall not be considered as requirements of the specification.
Note 1: Heat fusion joining of PA11 pipe and fittings meeting the requirements of this standard is limited to PA11 pipe and fittings meeting the requirements of this standard. Heat Fusion joining of PA11 pipe and fittings meeting the requirements of this standard is not allowed to pipes and fittings made from any other thermoplastic materials (for example, PA12, PEs, PVCs, etc.).
1.3 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.4 The following is an index of the annexes and appendixes in this specification:
Annexes
Subject
Annex A1
In-Plant Quality Control for sizes up to 12 in.
Annex A2
PA-11 Butt Fusion Fittings
Appendixes
Subject
Appendix X1
Butt Fusion Guidelines for PA-11 Piping
Appendix X2
Design Consideration
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 31-Oct-2023
• ICS: 23.040.20 - Plastics pipes
• ICS: 23.040.45 - Plastics fittings
• Technical Committee: F17 - Plastic Piping Systems
• Drafting Committee: F17.60 - Gas

Relations

• Replaces: ASTM F2945-18 - Standard Specification for Polyamide 11 Gas Pressure Pipe, Tubing, and Fittings
• Effective Date: 01-Nov-2023
• Refers: ASTM F1733-24 - Standard Specification for Butt Heat Fusion Polyamide(PA) Plastic Fitting for Polyamide(PA) Plastic Pipe and Tubing
• Effective Date: 01-Feb-2024
• Refers: ASTM F1563-23 - Standard Specification for Tools to Squeeze-off Polyethylene (PE) Gas Pipe or Tubing
• Effective Date: 01-Nov-2023
• Refers: ASTM F2897-23a - Standard Specification for Tracking and Traceability Encoding System of Natural Gas Distribution Components (Pipe, Tubing, Fittings, Valves, and Appurtenances)
• Effective Date: 01-Nov-2023
• Refers: ASTM F2600-09(2023) - Standard Specification for Electrofusion Type Polyamide-11 Fittings for Outside Diameter Controlled Polyamide-11 Pipe and Tubing
• Effective Date: 01-Nov-2023
• Refers: ASTM F2897-23 - Standard Specification for Tracking and Traceability Encoding System of Natural Gas Distribution Components (Pipe, Tubing, Fittings, Valves, and Appurtenances)
• Effective Date: 01-Jul-2023
• Refers: ASTM F1563-01(2019) - Standard Specification for Tools to Squeeze-off Polyethylene (PE) Gas Pipe or Tubing
• Effective Date: 01-Aug-2019
• Refers: ASTM F2600-09(2018) - Standard Specification for Electrofusion Type Polyamide-11 Fittings for Outside Diameter Controlled Polyamide-11 Pipe and Tubing
• Effective Date: 01-Feb-2018
• Refers: ASTM D1600-18 - Standard Terminology for Abbreviated Terms Relating to Plastics (Withdrawn 2024)
• Effective Date: 01-Jan-2018
• Referred By: ASTM F3508-21a - Standard Guide for In-Situ Pipeline Renovation As Dual-Wall Composite Pipeline by Push/Pull Installation of Compressed-Fit Shape-Memory-Polymer Tubular (SMPT)
• Effective Date: 01-Nov-2023
• Referred By: ASTM F3124-23a - Standard Practice for Data Recording the Procedure used to Produce Heat Butt Fusion Joints in Plastic Piping Systems or Fittings
• Effective Date: 01-Nov-2023
• Referred By: ASTM F1733-20 - Standard Specification for Butt Heat Fusion Polyamide(PA) Plastic Fitting for Polyamide(PA) Plastic Pipe and Tubing
• Effective Date: 01-Nov-2023
• Referred By: ASTM F1973-21 - Standard Specification for Factory Assembled Anodeless Risers and Transition Fittings in Polyethylene (PE) and Polyamide 11 (PA11) and Polyamide 12 (PA12) Fuel Gas Distribution Systems
• Effective Date: 01-Nov-2023
• Referred By: ASTM F2509-15(2019) - Standard Specification for Field-assembled Anodeless Riser Kits for Use on Outside Diameter Controlled Polyethylene and Polyamide-11 (PA11) Gas Distribution Pipe and Tubing
• Effective Date: 01-Nov-2023
• Referred By: ASTM F1948-20 - Standard Specification for Metallic Mechanical Fittings for Use on Outside Diameter Controlled Thermoplastic Gas Distribution Pipe and Tubing
• Effective Date: 01-Nov-2023

Overview

ASTM F2945-18(2023) - Standard Specification for Polyamide 11 Gas Pressure Pipe, Tubing, and Fittings sets the requirements and test methods for Polyamide 11 (PA11) piping components intended for the conveyance of fuel gases. This internationally recognized ASTM standard ensures the safety, durability, and performance of PA11 pipes, tubing, and fittings used in the gas industry. The standard is applicable to systems for both the distribution and the transmission of fuel gases and excludes threaded pipe from its coverage.

Polyamide 11 materials under this specification may be virgin or reworked, with particular requirements for hydrostatic design stress and basis ratings. A comprehensive approach ensures that only high-quality, traceable materials reach the market.

Key Topics

• Material Requirements: Specifies the use of virgin or appropriately reworked PA11 material, ensuring compliance with hydrostatic design stress ratings as per PPI TR3 and TR4.
• Testing Protocols: Includes methods for evaluating tensile strength, flexibility, burst pressure, rapid crack propagation resistance, and chemical stability.
• Dimensional Tolerances: Outlines precise tolerances for pipe diameter, wall thickness, ovality, and other critical dimensions to guarantee system integrity.
• Joining Methods: Restricts heat fusion joining to PA11-to-PA11 components, maintaining compatibility and system safety.
• Marking and Traceability: Requires permanent, legible markings and unique tracking codes for traceability throughout the product's lifecycle.
• Quality Assurance: Mandates robust in-plant quality control programs and detailed documentation to ensure consistent production standards.

Applications

ASTM F2945-18(2023) is vital for stakeholders in the natural gas and fuel gas distribution sectors, providing a standardized benchmark for safe and efficient pipeline system installation and maintenance. Practical applications include:

• Natural Gas Distribution Systems: Ensuring pipeline materials meet modern demands for flexibility, strength, and corrosion resistance in both urban and rural networks.
• Transmission Pipelines: Supporting infrastructure designed for long-distance and high-pressure fuel gas transport.
• New Installations and System Expansion: Supplying guidelines for fitting and joining PA11 pipes in new builds or expansion of current operations.
• Repair and Retrofit: Offering parameters for the replacement or repair of existing piping systems with PA11 components.

PA11 piping systems are particularly suitable for their chemical resistance, mechanical robustness, and ability to withstand long-term exposure to fuel gases, making them a top choice for safety-critical applications.

Related Standards

For comprehensive quality and compatibility, ASTM F2945-18(2023) references and aligns with numerous related standards, including:

• ASTM D543: Practices for Evaluating the Resistance of Plastics to Chemical Reagents
• ASTM D638, D790: Test Methods for Tensile and Flexural Properties of Plastics
• ASTM D1598, D1599: Test Methods for Time-to-Failure and Burst Pressure of Plastic Pipe
• ASTM F1563, F2600: Specifications for Polyamide Pipe Fittings and Electrofusion Types
• ASTM F2897: Specification for Tracking and Traceability Encoding Systems
• Plastic Pipe Institute (PPI) TR3 & TR4: Guidelines for determining hydrostatic design basis and stresses
• ISO 13478: For evaluating resistance to rapid crack propagation
• ANSI B31.8: Gas Transmission and Distribution Piping Systems

Staying compliant with ASTM F2945-18 and its referenced standards ensures robust fuel gas pipeline networks that are safe, reliable, and ready for regulatory inspection.

---

Keywords: Polyamide 11, PA11 gas pipe, fuel gas piping standard, ASTM F2945, natural gas pipe, plastic gas pipe, gas pressure pipe, tubing and fittings, pipeline standard, PPI hydrostatic design stress
