ASTM C1134-23

Standard Test Method for Water Retention of Rigid Thermal Insulations Following Partial Immersion

SIGNIFICANCE AND USE
4.1 Materials less than or equal to 15 mm (0.59 in.) in thickness shall not be tested in accordance with this test method in order to avoid complete immersion of the specimens. This type of exposure is beyond the scope of this test method.
4.2 This test method is used to assess both the short-term water retention and the long-term water retention. The short-term water retention is assessed as the average of the water retained following partial immersion intervals of 0.75-h and 3.00-h, in kilograms per square meter (percent by volume) (for materials tested at 25.4 mm (1.00 in.) thickness). The long-term water retention is assessed as the water retained following a 168-h partial immersion interval, in kilograms per square meter (percent by volume) (for materials tested at 25.4 mm (1.00 in.) thickness).
4.3 Materials shall be tested at both actual product thickness and 25.4 mm (1.00 in.) thickness provided the materials can be cut to a thickness of 25.4 mm (1.00 in.) without changing the original character of the materials. If a product cannot be cut without changing the original character of the material, the corresponding information shall be provided in the test report. Results shall be reported on the basis of equal nominal wetted specimen surface area (in units of kilograms per square meter) for materials tested at actual product thickness and on the basis of equal specimen volume (in units of percent by volume) for materials tested at 25.4 mm (1.00 in.) thickness. If a product cannot be cut to a thickness of 25.4 mm (1.00 in.) or if the actual product thickness is less than 25.4 mm (1.00 in.) but greater than 15 mm (0.59 in.), the product shall only be tested at actual product thickness and results only reported on the basis of equal nominal wetted specimen surface area.
4.3.1 By reporting results on the basis of equal nominal wetted specimen surface area, specimens of different thicknesses can be compared equitably. For some specimens, the water intake ...
SCOPE
1.1 This test method determines the amount of water retained (including surface water) by rigid block and board thermal insulations used in building construction applications after these materials have been partially immersed in liquid water for prescribed time intervals under isothermal conditions. This test method is intended to be used for the characterization of materials in the laboratory. It is not intended to simulate any particular environmental condition potentially encountered in building construction applications.
1.2 This test method does not address all the possible mechanisms of water intake and retention and related phenomena for rigid thermal insulations. It relates only to those conditions outlined in 1.1. Determination of moisture accumulation in thermal insulations due to complete immersion, water vapor transmission, internal condensation, freeze-thaw cycling, or a combination of these effects requires different test procedures.
1.3 Each partial immersion interval is followed by a brief free-drainage period. This test method does not address or attempt to quantify the drainage characteristics of materials. Therefore, results for materials with different internal structure and porosity, such as cellular materials and fibrous materials, are not necessarily directly comparable. Also, test results for specimens of different thickness are not necessarily directly comparable because of porosity effects. The surface characteristics of a material also affect drainage. It is possible that specimens with rough surfaces will retain more surface water than specimens with smooth surfaces, and that surface treatment during specimen preparation will affect water intake and retention. Therefore, it is not advisable to directly compare results for materials with different surface characteristics.
1.4 For most materials the size of the test specimens is small compared with the size of the products actually inst...

General Information

• Status: Published
• Publication Date: 28-Feb-2023
• ICS: 27.220 - Heat recovery. Thermal insulation
• Technical Committee: C16 - Thermal Insulation
• Drafting Committee: C16.33 - Insulation Finishes and Moisture

Relations

• Refers: ASTM C168-24 - Standard Terminology Relating to Thermal Insulation
• Effective Date: 15-Apr-2024
• Refers: ASTM C168-18 - Standard Terminology Relating to Thermal Insulation
• Effective Date: 15-Apr-2018
• Refers: ASTM C168-17 - Standard Terminology Relating to Thermal Insulation
• Effective Date: 01-Jun-2017
• Refers: ASTM C168-15a - Standard Terminology Relating to Thermal Insulation
• Effective Date: 15-Oct-2015
• Refers: ASTM C168-15 - Standard Terminology Relating to Thermal Insulation
• Effective Date: 01-Jun-2015
• Refers: ASTM E691-13 - Standard Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method
• Effective Date: 01-May-2013
• Refers: ASTM C168-13 - Standard Terminology Relating to Thermal Insulation
• Effective Date: 01-Apr-2013
• Refers: ASTM E691-11 - Standard Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method
• Effective Date: 01-Nov-2011
• Refers: ASTM C168-10 - Standard Terminology Relating to Thermal Insulation
• Effective Date: 01-Jan-2010
• Refers: ASTM C168-08b - Standard Terminology Relating to Thermal Insulation
• Effective Date: 15-Dec-2008
• Refers: ASTM E691-08 - Standard Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method
• Effective Date: 01-Oct-2008
• Refers: ASTM C168-08a - Standard Terminology Relating to Thermal Insulation
• Effective Date: 01-Sep-2008
• Refers: ASTM C168-08 - Standard Terminology Relating to Thermal Insulation
• Effective Date: 01-Jun-2008
• Refers: ASTM E691-05 - Standard Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method
• Effective Date: 01-Nov-2005
• Refers: ASTM C168-05a - Standard Terminology Relating to Thermal Insulation
• Effective Date: 01-Nov-2005

Overview

ASTM C1134-23 is the standardized test method for determining the water retention of rigid thermal insulation products following partial immersion. Developed by ASTM International, this standard provides an objective laboratory procedure for assessing how much water is absorbed and retained by rigid block and board insulation materials after they are partially submerged in liquid water for set time intervals. The results help characterize insulation materials used in building construction, ensuring product performance and facilitating informed selection and specification.

This method specifically applies to rigid thermal insulation products with thicknesses greater than 15 mm and is not intended to simulate real-world moisture exposure in field conditions.

Key Topics

• Scope Limitations

  • Only rigid insulation materials thicker than 15 mm are suitable for testing.
  • The test focuses on partial immersion under controlled, isothermal laboratory conditions.
  • Does not address all mechanisms of moisture absorption, such as water vapor transmission or complete immersion.

• Water Retention Assessment

  • Measures both short-term (after 0.75 and 3 hours) and long-term (after 168 hours) water retention.
  • Results can be reported as kilograms per square meter (by wetted surface area) or percent by volume (for 25.4 mm thick specimens).
  • Provides a method to compare specimens equitably by standardizing specimen dimensions and reporting metrics.

• Test Methodology

  • Specifies sample preparation, immersion procedures, and weighing protocols.
  • Testing includes conditioning specimens to constant mass, controlled temperature and humidity during testing, and draining post-immersion prior to final mass determination.
  • Determines density for reference and requires reporting of unusual test observations (e.g., warping or cracking).

• Reporting and Comparability

  • Test reports must include material identification, specimen description, test conditions, and both short and long-term retention results.
  • Due to differences in material structure and surface characteristics, direct comparison across different product types or thicknesses is discouraged unless reporting is standardized.

Applications

ASTM C1134-23 is an essential reference for:

• Building product manufacturers: Evaluating and qualifying rigid insulation materials for moisture resistance.
• Architects and engineers: Selecting appropriate insulation based on water retention performance.
• Specifiers and quality assurance personnel: Verifying compliance for construction documents, product submittals, and regulatory requirements.
• Laboratory technicians and product developers: Conducting product research, development, and comparative material analysis.

The standard’s protocols support quality assurance processes and ensure that insulation materials used in construction will maintain their thermal performance by minimizing unwanted water absorption. Although laboratory-based, the method provides baseline moisture absorption data relevant to long-term durability in building applications.

Related Standards

Several ASTM standards are referenced or related to ASTM C1134-23:

• ASTM C168 - Terminology Relating to Thermal Insulation: Provides definitions used throughout C1134.
• ASTM E691 - Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method: Basis for evaluating test precision and reproducibility.
• Other moisture and thermal insulation test methods: For comprehensive moisture performance assessment, consider standards addressing water vapor transmission, full immersion, freeze-thaw cycling, and internal condensation.

By following ASTM C1134-23, stakeholders can objectively assess and compare the water retention characteristics of rigid thermal insulation products, contributing to more durable, energy-efficient buildings and reliable material performance.
