EN 14975:2006+A1:2010

Loft ladders - Requirements, marking and testing

This European Standard specifies terms and definitions, product requirements and test methods for the construction and performance of loft ladders.

Bodentreppen - Anforderungen, Kennzeichnung und Prüfung

Diese Europäische Norm legt die Begriffe, Produktanforderungen und Prüfverfahren für die Konstruktion und Funktionsfähigkeit von Bodentreppen fest.

Echelles de grenier - Exigences, marquage et essais

La présente Norme européenne spécifie les termes et les définitions applicables aux échelles de grenier et indique les exigences et méthodes d’essai relatives à la construction et aux performances de ces produits.

Lestve - Zahteve, označevanje in preskušanje

Ta evropski standard določa izraze in opredelitve, zahteve za proizvode in preskusne metode za konstrukcijo in delovanje lestev.

General Information

• Status: Published
• Publication Date: 06-Jul-2010
• Withdrawal Date: 30-Jan-2011
• ICS: 91.060.30 - Ceilings. Floors. Stairs
• Technical Committee: CEN/TC 93 - Ladders
• Drafting Committee: CEN/TC 93/WG 9 - Attic stair/loft ladders
• Current Stage: 9092 - Decision on results of review/2YR ENQ - revise - Review Enquiry
• Start Date: 21-Mar-2022
• Completion Date: 23-Sep-2025
• Ref Project: SIST EN 14975:2007+A1:2010 - Loft ladders - Requirements, marking and testing

Relations

• Merged From: EN 14975:2006/FprA1 - Loft ladders - Requirements, marking and testing
• Effective Date: 19-Jan-2023
• Merged From: EN 14975:2006 - Loft ladders - Requirements, marking and testing
• Effective Date: 18-Jan-2023
• Revised: prEN 14975 - Loft ladders - Requirements, marking and testing
• Effective Date: 28-Jan-2023

Overview

EN 14975:2006+A1:2010 (CEN) - "Loft ladders - Requirements, marking and testing" is the European standard that defines terminology, product requirements and test methods for loft ladders intended to provide access to lofts or similar elevated spaces. It covers functional dimensions, construction and performance limits, marking and user instructions, and required mechanical tests to substantiate safety and durability. The standard is binding for CEN member states and is aimed at single-person loft ladder designs with a maximum total load of 150 kg.

Key topics and technical requirements

• Terms & types: Defines loft ladder types (concertina, hinged/folding, sliding - push-out and pull-out) and component names (stile, rung, tread, handrail, trapdoor, hinge, locking device).
• Maximum load: Designed for one person; maximum total load = 150 kg.
• Functional dimensions & angles: Prescribes key dimensions and climbing angles - for rungs: 60°–80°, for treads: 60°–75°, plus minimum widths, pitches and clearances.
• Construction features: Requirements for bearing surfaces, anti-slip surfaces, handrail provision (required when stile depth > 76 mm), feet, sharp edges, insulation/sealing and operability (stowing/un-stowing).
• Marking & instructions: Includes marking and user instruction requirements (standard defines what must be provided; see full text for specifics).
• Test methods and tolerances:
  • General test conditions: room temperature 15–25 °C; measurement tolerances e.g. ±1 mm (linear), ±1° (angle), ±1% for static forces.
  • Static load test: pre-load 1 000 N, then test force 2 600 N on designated rungs/treads; limits on permanent deformation (sliding/folding ≤ 0.005 × extended stile length).
  • Fatigue test: cyclic load 1 500 N applied 5 000 times; residual deflection ≤ 20 mm/m.
  • Torsion of rungs/treads: torque 50 N·m applied; permanent deformation ≤ ±1°.
  • Handrail test: specified outward/downward loads (outward A/B/C = 100 N, downward D = 500 N, static F = 400 N); permanent deflection limits ≤ 15 mm.
  • Rungs/treads bending: vertical force 2 600 N, max permanent deflection ≤ 3 mm.
  • Ladder stops test for pull-out sliding ladders: repeated drop/arrest procedure to check stops and engagement.

Applications

• Use this standard when designing, manufacturing, testing, certifying or specifying loft ladders for residential and light commercial buildings.
• Practical uses include product development, quality control, third‑party testing, conformity assessment, procurement specifications, and building code compliance verification.

Who should use EN 14975

• Manufacturers and designers of loft ladders
• Test laboratories and conformity assessors
• Installers, architects, specifiers and building safety inspectors
• Procurement teams and regulators requiring compliant loft ladders

Related standards

• EN 14975 is produced by CEN/TC 93 (Ladders). Consult other CEN ladder standards and national implementations for complementary requirements and harmonized procedures.

Keywords: EN 14975, loft ladders, loft ladder testing, loft ladder requirements, marking, CEN standard, ladder safety.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Bodentreppen - Anforderungen, Kennzeichnung und PrüfungEchelles de grenier - Exigences, marquage et essaisLoft ladders - Requirements, marking and testing97.145LestveLaddersICS:Ta slovenski standard je istoveten z:EN 14975:2006+A1:2010SIST EN 14975:2007+A1:2010en,fr,de01-september-2010SIST EN 14975:2007+A1:2010SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 14975:2006+A1
July 2010 ICS 91.060.30 Supersedes EN 14975:2006English Version
Loft ladders - Requirements, marking and testing
Echelles de grenier - Exigences, marquage et essais
Bodentreppen - Anforderungen, Kennzeichnung und Prüfung This European Standard was approved by CEN on 25 November 2006 and includes Amendment 1 approved by CEN on 4 June 2010.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2010 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 14975:2006+A1:2010: ESIST EN 14975:2007+A1:2010

3.2.1 concertina loft ladder loft ladder with extendable climbing support NOTE See Figure 1.
Figure 1 — Concertina loft ladder 3.2.2 hinged/folding loft ladder loft ladder with hinged or folded climbing support NOTE See Figure 2. SIST EN 14975:2007+A1:2010

Figure 2 — Hinged/folding loft ladder 3.2.3 sliding loft ladder loft ladder with sliding climbing support 3.2.3.1 push-out sliding loft ladder sliding loft ladder with climbing support to be pushed out NOTE See Figure 3. SIST EN 14975:2007+A1:2010

Figure 3 — Push-out sliding loft ladder 3.2.3.2 pull-out sliding loft ladder sliding loft ladder with climbing support to be pulled out NOTE See Figure 4.
Figure 4 — Pull-out sliding loft ladder SIST EN 14975:2007+A1:2010

3.3.1 handrail rail fitted to loft ladder to give user support when climbing or descending loft ladder 3.3.2 trapdoor door giving access to loft or similar point at a higher level NOTE The loft ladder may or may not be attached to the trapdoor. 3.3.3 hinge connecting element between loft ladder or trapdoor and loft or trapdoor casing similar point at a higher level 3.3.4 rung climbing support with a standing surface from front to back of less than 80 mm and more than 20 mm 3.3.5 stile side members to which the rungs, treads or cross-members are fitted 3.3.6 stile hinge connecting element between folding ladder parts 3.3.7 locking device mechanism to prevent unintended sliding out, extending or unfolding of the loft ladder 3.3.8 tread climbing support with a standing surface from front to back equal to or greater than 80 mm 4 Maximum load The requirements are based upon a maximum total load of 150 kg. Loft ladders are designed to be used by one person at a time. 5 Test methods 5.1 General 5.1.1 Tolerances For all tests, unless otherwise stated in the particular test, the following tolerances are permitted as uncertaint
...
