Machines and installations for the exploitation and processing of natural stone - Safety - Part 1: Requirements for stationary diamond wire saws

This document deals with all significant hazards, hazardous situations and events, as listed in Annex A, which are relevant to stationary diamond wire saws (stationary diamond mono-wire saws and stationary diamond multi-wire saws), as defined in Clause 3.
Stationary diamond wire saws may be used in quarries or in sawmill for cutting natural stones (e.g. marble, granite), when they are used as intended and under conditions of misuse which are reasonably foreseeable by the manufacturer (see Annex A).
This document deals only with stationary diamond wire saws using coated diamond wire as tool.
This document specifies the appropriate technical measures to eliminate or reduce risks arising from the significant hazards.
This document deals all significant hazards that may occur within the expected lifetime of the machinery including the phases of transport, assembly, dismantling, disabling and scrapping.
This document does not deal with the significant hazards arising by the use of other facilities/devices not described in this document, that may be fitted on the machines or that may be used during the work cycle.
This document does not deal with:
a)   operation under extreme ambient conditions (outside the limits defined in EN 60204-1:2018);
b)   upstream and downstream conveying elements, not integrated with stationary diamond wire saws, for transporting of the work-pieces.
This document is not applicable to machines which are manufactured before the date of publication of this document by CEN.

Maschinen und Anlagen zur Gewinnung und Bearbeitung von Naturstein — Sicherheit — Teil 1: Anforderungen für stationäre Diamantseilsägen

Dieses Dokument behandelt alle in Anhang A aufgeführten signifikanten Gefährdungen, Gefährdungs-situationen und Gefährdungsereignisse, die für stationäre Diamantseilsägen (stationäre Diamanteinzel-seilsägen und stationäre Diamantmehrfachseilsägen) wie in Abschnitt 3 festgelegt maßgebend sind, wenn sie bestimmungsgemäß und unter Bedingungen der Fehlanwendung, die vernünftigerweise vom Hersteller vorhersehbar sind, verwendet werden.
Stationäre Diamantseilsägen können in Steinbrüchen oder in Sägewerken zum Schneiden von Natursteinen (z. B. Marmor, Granit) verwendet werden (siehe Anhang A).
Dieses Dokument behandelt ausschließlich stationäre Diamantseilsägen mit beschichteten Diamantseil-werkzeugen.
Dieses Dokument legt die geeigneten technischen Maßnahmen fest, um die aus den signifikanten Gefährdungen resultierenden Risiken zu beseitigen oder zu verringern.
Dieses Dokument behandelt alle signifikanten Gefährdungen, die innerhalb der erwarteten Lebensdauer der Maschinen auftreten könnten, einschließlich der Phasen Transport, Montage, Demontage, Außer-betriebnahme und Verschrottung.
Dieses Dokument befasst sich nicht mit den signifikanten Gefährdungen, die sich aus der Verwendung anderer in diesem Dokument nicht beschriebener Vorrichtungen/Geräte ergeben, die an den Maschinen angebracht sein könnten oder während des Arbeitszyklus verwendet werden können.
Dieses Dokument ist nicht anzuwenden für:
1)   Maschinen, die für den Betrieb in explosionsgefährdeten Bereichen vorgesehen sind;
2)   Maschinen, die vor dem Datum der Veröffentlichung dieses Dokuments hergestellt wurden.

Machines et installations pour l’exploitation et la transformation de la pierre naturelle - Sécurité - Partie 1 : Prescriptions pour les scies à fil diamanté stationnaires

Le présent document traite de tous les phénomènes dangereux, situations dangereuses et événements dangereux significatifs, tels qu’énumérés dans l’ Annexe A, qui sont pertinents pour les scies à fil diamanté fixes (scies monofil diamanté fixes et scies multifils diamantés fixes), telles que définies dans l’Article 3, lorsqu’elles sont utilisées comme prévu et dans des conditions de mauvaise utilisation qui sont raisonnablement prévisibles par le fabricant.
Les scies à fil diamanté fixes peuvent être utilisées dans des carrières ou dans des scieries pour couper des pierres naturelles, par exemple, le marbre, le granite (voir  Annexe A).
Le présent document traite uniquement des scies à fil diamanté fixes utilisant comme outil un fil diamanté.
Le présent document spécifie les mesures techniques appropriées pour éliminer ou réduire les risques dus aux phénomènes dangereux significatifs.
Le présent document traite de tous les phénomènes dangereux pouvant survenir au cours de la durée de vie prévisible de la machine, y compris les phases de transport, de montage, de démontage, de mise hors service et de mise au rebut.
Le présent document ne traite pas des phénomènes dangereux significatifs engendrés par l’utilisation d’autres installations/dispositifs non décrits dans le présent document, qui peuvent être montés sur les machines ou utilisés pendant le cycle de travail.
Le présent document ne s’applique pas aux :
1)   machines prévues pour une utilisation en atmosphère explosible ;
2)   machines fabriquées avant la date de publication du présent document.

Stroji in oprema za pridobivanje in obdelavo naravnega kamna - Varnost - 1. del: Zahteve za nepremične enožične diamantne žage

Ta dokument obravnava vsa večja tveganja, nevarne situacije in nevarne dogodke, navedene v dodatku A, v zvezi z nepremičnimi žičnimi diamantnimi žagami (nepremičnimi enožičnimi diamantnimi žagami in nepremičnimi diamantnimi večžičnimi žagami), kot so opredeljene v točki 3.
Nepremične žične diamantne žage se lahko uporabljajo v kamnolomih ali žagarskih obratih za žaganje naravnega kamna (npr. marmorja, granita), kadar se uporabljajo v skladu s predvidenim namenom in pod pogoji razumno predvidljive nepravilne uporabe, ki jih določa proizvajalec (glej dodatek A).
Ta dokument obravnava samo tiste nepremične žične diamantne žage, pri katerih se kot delovno orodje uporablja prevlečena diamantna žica.
Ta dokument določa ustrezne tehnične ukrepe za odpravljanje ali zmanjšanje tveganj, ki izhajajo iz večjih nevarnosti.
Ta dokument obravnava vsa večja tveganja v okviru predvidene življenjske dobe strojev, vključno s fazami transporta, sestavljanja, razstavljanja, onemogočanja in razrezovanja.
Ta dokument ne obravnava večjih tveganj, ki izhajajo iz uporabe drugih funkcij/naprav, ki niso opisane v tem dokumentu in so lahko vgrajene v stroje ali se lahko uporabljajo med delovnim ciklom.
Ta dokument ne obravnava:
a)   obratovanja v izrednih okoljskih pogojih (zunaj omejitev, določenih v standardu EN 60204-1:2018);
b)   navzgor in navzdol premikajočih se elementov, ki niso vgrajeni v nepremične žične diamantne žage, za transport obdelovancev.
Ta dokument se ne uporablja za stroje, izdelane preden je CEN izdal ta dokument.
