EN 1854:2022+A1:2023

Safety and control devices for burners and appliances burning gaseous and/or liquid fuels - Pressure sensing devices for gas burners and gas burning appliances

EN 13611:2019, Clause 1 applies with the following modification:
Modification:
The 1st paragraph of EN 13611:2019, Clause 1 is replaced by:
This document specifies the safety, design, construction, and performance requirements and testing of pressure sensing devices for burners and appliances burning one or more gaseous fuels.
This document is applicable to pressure sensing devices for gaseous fuels, air, or combustion products with declared maximum inlet pressures up to and including 500 kPa.
It applies to all types of pressure sensing devices, including electronic, differential and inferential types.
It also specifies requirements for pressure sensing devices which are intended to be applied to steam boilers and as such need to meet increased reliability requirements.
EN 13611:2019 Clause 1, 4th paragraph is not applicable.

Sicherheits- und Regeleinrichtungen für Brenner und Brennstoffgeräte für gasförmige und/oder flüssige Brennstoffe - Druckwächter für Gasbrenner und Gasgeräte

EN 13611:2019, Abschnitt 1, gilt mit folgender Änderung:
Änderung:
Der 1. Absatz von EN 13611:2019, Abschnitt 1, wird durch Folgendes ersetzt:
Dieses Dokument legt die Sicherheits-, Auslegungs-, Konstruktions- und Leistungsanforderungen sowie die Prüfung von Druckwächtern für Brenner und Brennstoffgeräte für einen oder mehrere gasförmige(n) Brennstoff(e) fest.
Dieses Dokument gilt für Druckwächter für gasförmige Brennstoffe, Luft oder Verbrennungsprodukte mit deklarierten maximalen Eingangsdrücken bis einschließlich 500 kPa.
Es gilt für alle Arten von Druckwächtern, einschließlich elektronischer Ausführungen sowie für Differenzdruckwächter und indirekt messende Ausführungen.
Es werden auch Anforderungen an Druckwächter festgelegt, die für den Einsatz an Dampfkesseln vorgesehen sind und die erhöhte Anforderungen an die Zuverlässigkeit erfüllen müssen.
EN 13611:2019, Abschnitt 1, 4. Absatz, gilt nicht.

Equipements auxiliaires pour brûleurs et appareils utilisant des combustibles gazeux ou liquides - Dispositifs de surveillance de pression pour brûleurs et appareils à gaz

L'article 1 de la norme EN13611 :2019 s'applique avec la modification suivante:
Modification:
Le 1er paragraphe de l'article 1 de la EN13611:2019 est remplacé par :
Ce document spécifie les exigences de sécurité, de construction, de fonctionnement et les méthodes d'essais des dispositifs de surveillance de pression des brûleurs et des appareils à gaz.
Elle s’applique aux dispositifs de surveillance de pression pour le contrôle des pressions de gaz combustibles, d'air et de gaz de combustion pour des pressions amont maximales déclarées allant jusqu’à 500 kPa (5 bar).
Elle s’applique à tous les types de dispositifs de surveillance de pression, y compris électroniques, différentiels et inférentiels.
Elle spécifie également les exigences des dispositifs de surveillance de pression qui sont destinés à être utilisés dans des chaudières à vapeur et qui, en tant que tels, doivent respecter des exigences de fiabilité plus strictes.
Le 4ième paragraphe de l'article 1 de la EN13611:2019 n'est pas applicable.

Varnostne in nadzorne naprave za gorilnike in aparate na plin in/ali tekoča goriva - Tlačna zaznavala za plinske gorilnike in plinske aparate (vključno z dopolnilom A1)

Točka 1 standarda EN 13611:2019 se uporablja z naslednjo spremembo:
Sprememba:
Prvi odstavek točke 1 standarda EN 13611:2019 nadomešča naslednje besedilo:
Ta dokument določa zahteve za varnost, načrtovanje, izdelavo in delovanje ter preskušanje tlačnih zaznaval za gorilnike in aparate, ki uporabljajo eno ali več plinastih goriv.
Ta dokument se uporablja za tlačna zaznavala za plinska goriva, zrak ali produkte zgorevanja z določenim največjim vstopnim tlakom do vključno 500 kPa.
Uporablja se za vse vrste tlačnih zaznaval, vključno z elektronskimi, diferenčnimi in inferenčnimi napravami.
Določa tudi zahteve za tlačna zaznavala, ki so namenjena za uporabo v parnih kotlih in morajo kot taka izpolnjevati večje zahteve glede zanesljivosti.
Četrti odstavek točke 1 standarda EN 13611:2019 se ne uporablja.

General Information

• Status: Published
• Publication Date: 12-Dec-2023
• ICS: 23.060.40 - Pressure regulators
• Technical Committee: CEN/TC 58 - Safety and control devices for burners and appliances burning gaseous or liquid fuels
• Drafting Committee: CEN/TC 58/WG 12 - Electronics
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 13-Dec-2023
• Completion Date: 13-Dec-2023
• Directive: 2016/426 - REGULATION (EU) 2016/426 OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 9 March 2016 on appliances burning gaseous fuels and repealing Directive 2009/142/EC
• Mandate: M/595 - [C(2023)4789] - Commission Implementing Decision of 20.7.2023 on a standardisation reques as regards gas appliances and fittings in support of Regulation (EU) 2016/426 of the European Parliament and of the Council
• Ref Project: SIST EN 1854:2023+A1:2024 - Safety and control devices for burners and appliances burning gaseous and/or liquid fuels - Pressure sensing devices for gas burners and gas burning appliances
