EN 14637:2007

Building hardware - Electrically controlled hold-open systems for fire/smoke door assemblies - Requirements, test methods, application and maintenance

This European Standard specifies requirements, methods of test and performance criteria against which the compatibility of components and their performance can be assessed when used in combination to form an electrically controlled hold-open system. It also specifies requirements for the integrity of such hold-open systems when connected to fire detection and fire alarm systems or other systems, including the signal exchange and technical data for interfaces.
This European Standard provides requirements for the application of electrically controlled hold-open systems used for fire/smoke doors in buildings, where such doors are required to be self-closing. It covers planning, design (see Annex A), installation (see Annex B), commissioning, use and maintenance (see Annex E) of hold-open systems, intended for the protection of life and/or the protection of property. This may also include hold-open systems, or components of the hold-open system, that are self-contained in a single enclosure.
Electrically controlled hold-open systems manufactured, installed and serviced in accordance with this European Standard are recommended for use wherever there is a requirement for reliable hold-open and release of an individual self-closing fire/smoke door assembly in the case of fire.
The use of hold-open systems for closures in conveyor systems conforming to EN 1366-7, which applies in conjunction with EN 1363-1, may require additional proof of suitability, which is not covered by this European Standard.
This European Standard does not cover design, installation, commissioning, use and maintenance of building fire detection and fire alarm systems (covered by CEN/TS 54-14) but does cover the connection of hold-open systems conforming to this European Standard to building fire detection and fire alarm systems, under certain prescribed conditions.
This European Standard does not cover the requirements of performance characteristics and operational environment conditions of part

Schlösser und Baubeschläge - Elektrisch gesteuerte Feststellanlagen für Feuer-/Rauchschutztüren - Anforderungen, Prüfverfahren, Anwendung und Wartung

Quincaillerie pour le bâtiment - Systèmes de retenue contrôlés électriquement pour blocs-portes, coupe-feu ou pare-fumée - Exigences, méthode d'essai, mise en œuvre et maintenance

La présente Norme européenne spécifie les exigences, les méthodes d’essai et les critères de performances par rapport auxquels la compatibilité des composants et leurs performances peuvent être évaluées lorsqu’ils sont utilisés en combinaison pour former un système de retenue contrôlé électriquement. Elle spécifie également les exigences d’intégrité de ces systèmes de retenue lorsqu’ils sont connectés à des systèmes de détection et d’alarme incendie ou à d’autres systèmes, y compris l’échange de signaux, ainsi que les données techniques pour les interfaces.
La présente Norme européenne donne les exigences pour la mise en œuvre de systèmes de retenue contrôlés électriquement sur les portes coupe-feu/pare-fumée dans les bâtiments pour lesquels des portes à fermeture automatique sont exigées. Elle couvre la planification, la conception (voir Annexe A), l’installation (voir Annexe B), la mise en service, l’utilisation et la maintenance (voir Annexe E) de systèmes de retenue destinés à protéger la vie et/ou des biens. Ces derniers peuvent se présenter sous la forme de systèmes de retenue indépendants ou de composants de système de retenue contenus dans un boîtier séparé.
Les systèmes de retenue contrôlés électriquement fabriqués, installés et entretenus conformément à la présente Norme européenne sont recommandés chaque fois qu’une fonction fiable de retenue et de fermeture automatique est requise pour un bloc-porte coupe-feu/pare-fumée en cas d’incendie.
L'utilisation de systèmes de retenue pour fermetures dans des systèmes de convoyeurs conformes à l'EN 1366-7, qui s'applique avec l'EN 1363-1, peut exiger des preuves d'adéquation supplémentaires qui ne sont pas couvertes par la présente Norme européenne.

Ključavnice in stavbno okovje - Električno krmiljeni odprti sistemi za požar/dim vratnih elementov - Zahteve, preskusne metode, uporaba in vzdrževanje

General Information

• Status: Published
• Publication Date: 06-Nov-2007
• ICS: 91.060.50 - Doors and windows
• ICS: 91.190 - Building accessories
• Technical Committee: CEN/TC 33 - Doors, windows, shutters and building hardware
• Drafting Committee: CEN/TC 33/WG 4 - Building hardware
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 04-Jul-2024
• Completion Date: 14-Apr-2025
• Ref Project: SIST EN 14637:2008 - Building hardware - Electrically controlled hold-open systems for fire/smoke door assemblies - Requirements, test methods, application and maintenance

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Building hardware - Electrically controlled hold-open systems for fire/smoke door assemblies - Requirements, test methods, application and maintenanceDQMHQuincaillerie pour le bâtiment - Systemes de retenue contrôlés électriquement pour blocs-portes, coupe-feu ou pare-fumée - Exigences, méthode d’essai, mise en oeuvre et maintenanceSchlösser und Baubeschläge - Elektrisch gesteuerte Feststellanlagen für Feuer-/Rauchschutztüren - Anforderungen, Prüfverfahren, Anwendung und WartungTa slovenski standard je istoveten z:EN 14637:2007SIST EN 14637:2008en,fr,de91.060.50ICS:SLOVENSKI
STANDARDSIST EN 14637:200801-maj-2008

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 14637November 2007ICS 91.060.50; 91.190 English VersionBuilding hardware - Electrically controlled hold-open systems forfire/smoke door assemblies - Requirements, test methods,application and maintenanceQuincaillerie pour le bâtiment - Systèmes de retenuecontrôlés électriquement pour blocs-portes, coupe-feu oupare-fumée - Exigences, méthode d'essai, mise en œuvreet maintenanceSchlösser und Baubeschläge - Elektrisch gesteuerteFeststellanlagen für Feuer-/Rauchschutztüren -Anforderungen, Prüfverfahren, Anwendung und WartungThis European Standard was approved by CEN on 30 September 2007.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2007 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 14637:2007: E

Evaluation of conformity.52 F.1 General.52 F.1.1 Introduction.52 F.1.2 Initial type test.52 F.1.3 Characteristics.52 F.1.4 Use of historical data.53 F.1.5 Treatment of calculated values and design.53 F.1.6 Sampling, testing and conformity criteria.53 F.2 Factory production control (FPC).53 F.2.1 General.53 F.2.2 FPC requirements for all manufacturers.54 F.3 Further testing of sample systems.54 F.3.1 Periodic testing.54 F.3.2 Yearly testing.54 F.3.3 Manufacturer-specific FPC system requirements.54 Annex G (informative) Type test report and list of approved components.57 G.1 Test report.57 G.2 List of approved components.57 Annex H (informative) Example methodology for theoretical analysis.58 H.1 Introduction.58 H.2 Points for analysis.58 H.2.1 General.58 H.2.2 List of characteristics.58 Bibliography.62
Figure 1 — Basic system components with essential functions.6 Figure 2 — Typical system with additional functions and components.7 Figure 3 — Logic diagram for modes of operation of an electrically controlled hold-open system.8 Figure A.1 — Ceiling types and critical dimensions.38 Figure A.2 — Installation area in accordance with A.3.2.1.39 Figure A.3 — Flow chart to determine the requisite number of detectors.40 Figure A.4 — Typical electrically controlled hold-open system with release of connected hold-open devices triggered directly by the FDAS (see A.3.2.2 a)).41 Figure A.5 — Typical electrically controlled hold-open system with release of connected hold-open devices by the control unit of the hold-open system driven by the information coming from the FDAS (see A.3.2.2 b)).42 Table G.1 — List of approved components.57

Introduction The purpose of an electrically controlled hold-open system is to reliably hold open and then release self-closing fire/smoke control door assemblies at the earliest practicable moment, in the event of fire, but not to generate an alarm signal. In this regard the required function of the fire detectors is different to the normal usage of fire detectors in fire detection and fire alarm systems. In the case of hold-open systems, conforming to this European Standard, the primary objective is to release a door reliably for self-closing and any incidence of false alarms is of secondary importance. In the case of fire detection and fire alarm systems, however, the incidence of false alarms needs to be kept to the absolute minimum (See 6.1.1 and 6.1.2). This does not, however, exclude the fact that detectors of fire detection and fire alarm systems may be used to initiate door release signals. A logic diagram for modes of operation of an electrically controlled hold-open system is shown in Figure 3. This European Standard is drafted on the basis of essential system functions and components which are provided on all electrically controlled hold-open systems and which comprise hold-open device(s), a control unit, a power supply unit, and fire detector(s) (see Figure 1). Options with requirements for additional system functions and components can also be provided, such as remote indicating devices, interconnecting cables, door position sensors, interfaces with other systems, manual controls and a stand-by power supply (see Figure 2). It is intended that the options be used for specific applications. The optional function(s) and components are included separately, with their own set of associated requirements, in order to permit electrically controlled hold-open systems with many different combinations of functions to conform to this European Standard. Where an option is taken, corresponding requirements are included. The performance tests incorporated in this European Standard are reproducible and, as such, will provide a consistent and objective assessment of the performance of these hold-open systems. Fire/smoke detectorAControl unitBHold-open deviceCPower supply unitD Figure 1 — Basic system components with essential functions

Fire/smoke detectionsignalControlunitRelease of hold-opendeviceClosingdeviceDoor closed (fire/smoke compartment closed)Door released (fire/smoke compartment open)In case of failure ofcomponent, element, system, mains poweror wiringFail-safe operation Manual control signalManual releaseBasic system with essential functions and elements
Figure 3 — Logic diagram for modes of operation of an electrically controlled hold-open system

The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 54-1:1996, Fire detection and fire alarm systems — Part 1: Introduction EN 54-2:1997, Fire detection and fire alarm systems — Part 2: Control and indicating equipment EN 54-4:1997, Fire detection and fire alarm systems — Part 4: Power supply equipment EN 54-5, Fire detection and fire alarm systems — Part 5: Heat detectors — Point detectors EN 54-7:2000, Fire detection and fire alarm systems — Part 7: Smoke detectors — Point detectors using scattered light, transmitted light or ionization

General requirements (IEC 60950-1:2005, modified) EN 61000-3-2, Electromagnetic compatibility (EMC) — Part 3-2: Limits — Limits for harmonic current emissions (equipment input current up to and including 16 A per phase) (IEC 61000-3-2:2005)
EN 61000-3-3, Electromagnetic compatibility (EMC) — Part 3: Limits — Section 3: Limitation of voltage fluctuations and flicker in low-voltage supply systems for equipment with rated current ≤ 16 A (IEC 61000-3-3:1994) EN 61000-6-2, Electromagnetic compatibility (EMC) — Part 6-2: Generic standards — Immunity for industrial environments (IEC 61000-6-2:2005) EN 61000-6-3, Electromagnetic compatibility (EMC) — Part 6-3: Generic standards; Emission standard for residential, commercial and light-industrial environments (IEC 61000-6-3:2006)

EXAMPLE Doors within factories, office buildings, hotels, hospitals, schools and other buildings which provide access to designated areas and which are used by the public and others frequently carrying or moving bulky objects. 4.3 Durability (second digit) Seven grades of durability are identified, based on the hold-open component of the system:  Grade 0:
500 test cycles;  Grade 1:
2 500 test cycles;  Grade 3:
10 000 test cycles;  Grade 5:
50 000 test cycles;  Grade 6:
100 000 test cycles;  Grade 7:
200 000 test cycles;  Grade 8:
500 000 test cycles. For the test method, 5.5.2 and 5.5.3.2 shall apply. 4.4 Door type (third digit) Five grades of door types and therefore different hold-open systems are identified:  Grade 1: Swing doors;  Grade 2: Sliding doors;  Grade 3: Roller shutter, sectional and lifting doors;  Grade 4: Automatic swing doors;  Grade 5: Automatic sliding and folding doors.

This denotes an electrically controlled hold-open system conforming to Grade 3 category of use, tested for 50 000 cycles, applicable for use on swing doors and sliding doors, suitable for use on fire/smoke door assemblies, with safety Grade 1 and with high corrosion resistance of the hold-open device(s).
...
