EN 13160-4:2016

Leak detection systems - Part 4: Requirements and test/assessment methods for sensor based leak detection systems

This European Standard gives requirements and the corresponding test/assessment methods applicable to leak detection kits based on the detection of the presence of liquid and/or vapour in interstitial spaces, leakage containments or monitoring wells. The kits are usually composed by:
- sensing device(s);
- evaluation device;
- alarm device.

Leckanzeigesysteme - Teil 4: Anforderungen und Prüf-/Bewertungsmethoden für sensorbasierte Leckanzeigesysteme

Diese Europäische Norm legt Anforderungen an und die einschlägigen Prüf-/Bewertungsverfahren für  sensorbasierte Leckanzeigesysteme (Leckanzeiger) fest. Die Leckanzeiger sind für die Verwendung in Überwachungsräumen, Leckageräumen oder Überwachungsschächten bestimmt. Die Leckanzeiger bestehen in der Regel aus:
   Messfühlereinrichtung(en);
   Auswerteeinrichtung;
   Alarmeinrichtung.

Systèmes de détection de fuites - Partie 4: Exigences et méthodes d'essai/d'évaluation des systèmes de détection de fuites par capteur

La présente Norme spécifie les exigences et les méthodes d'essai/d'évaluation correspondantes applicables aux kits de détection de fuites, fondées sur la présence de liquide et/ou de vapeur dans les espaces interstitiels, les espaces de confinement des fuites ou les puits piézométriques. Les kits sont généralement constitués des éléments suivants :
-   dispositif(s) de mesurage ;
-   dispositif d'évaluation ;
-   dispositifs d'alarme ;

Sistemi za kontrolo tesnosti - 4. del: Zahteve in metode za preskušanje in ocenjevanje senzorskih sistemov za zaznavanje netesnosti

Ta standard določa zahteve ter ustrezne metode za preskušanje in ocenjevanje, ki se uporabljajo za komplete za kontrolo tesnosti, ki temeljijo na zaznavanju prisotnosti tekočine in/ali hlapov v vmesnih prostorih, zadrževalnikih ali nadzornih jaških. Kompleti so običajno sestavljeni iz:
– senzorjev,
– naprave za ocenjevanje,
– alarmne naprave.
