This European Standard specifies the equipment and procedures for determining shear behaviour. It is applicable to thermal insulating products.
NOTE The tests described in this standard do not determine pure shear behaviour, but measure the effects of applying two opposite parallel forces to the major faces of the test specimen. The test is however called shear in this text by convention. The application of a force tangentially to the major surface of the test specimen is considered to represent more closely the stresses imposed upon thermal insulation products in many building applications, particularly walls, than other methods of measuring shear performance e.g. bending tests.
Wärmedämmstoffe für das Bauwesen - Bestimmung des Verhaltens bei Scherbeanspruchung
Diese Europäische Norm legt Prüfeinrichtungen und Verfahren zur Bestimmung des Verhaltens bei Scherbeanspruchung fest. Sie gilt für Wärmedämmstoffe.
ANMERKUNG Mit den in dieser Norm beschriebenen Prüfungen wird nicht das reine Scherverhalten bestimmt, sondern die Wirkung zweier gegenläufiger Parallelkräfte gemessen, die auf die größten Oberflächen des Probekörpers einwirken. Trotzdem wird in dieser Norm gewohnheitsmäßig von der Prüfung des Scherverhaltens gesprochen. Es wird davon ausgegangen, dass eine tangential zur größeren Oberfläche des Probekörpers aufgebrachte Kraft mehr den Beanspruchungen entspricht, denen Wärmedämmstoffe in vielen Anwendungsbereichen des Bauwesens — insbesondere bei Wänden — ausgesetzt sind, als die Bestimmung des Scherverhaltens mit anderen Prüfverfahren, wie z. B. dem Biegeversuch.
Produits isolants thermiques destinés aux applications du bâtiment - Détermination du comportement en cisaillement
La présente Norme européenne spécifie l'équipement et les modes opératoires permettant de déterminer le comportement en cisaillement. Elle s'applique aux produits isolants thermiques.
NOTE Les essais décrits dans la présente norme ne déterminent pas le comportement en cisaillement proprement dit, mais mesurent les effets de l'application de deux forces parallèles opposées sur les faces principales de l'éprouvette. Toutefois, l’essai est désigné dans le texte comme de cisaillement par convention. L'application d'une force tangentielle à la face principale de l'éprouvette est considérée représenter mieux les contraintes imposées aux produits isolants thermiques dans beaucoup d'applications du bâtiment, et plus particulièrement pour les murs, que les autres méthodes de mesure de la performance au cisaillement, par exemple les essais de flexion.
Toplotnoizolacijski proizvodi za uporabo v gradbeništvu - Ugotavljanje obnašanja pri strigu
Ta evropski standard določa opremo in postopke za ugotavljanje obnašanja strig. Uporablja se za toplotnoizolacijske proizvode.
General Information
- Status
- Published
- Publication Date
- 12-Mar-2013
- Withdrawal Date
- 29-Sep-2013
- Technical Committee
- CEN/TC 88 - Thermal insulating materials and products
- Drafting Committee
- CEN/TC 88/WG 1 - Common general test methods
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 07-Apr-2025
- Completion Date
- 07-May-2025
- Directive
- 89/106/EEC - Construction products
Relations
- Effective Date
- 20-Mar-2013
Overview
EN 12090:2013 - published by CEN - defines a standardized laboratory method for determining the shear behaviour of thermal insulating products used in building applications. The standard describes the equipment, specimen preparation, test procedures and calculation of results for shear strength and shear modulus. Note: the test applies two opposite parallel forces to the specimen faces and therefore measures practical shear behaviour rather than an idealized pure-shear state.
Key topics and technical requirements
- Test principle: apply tangential (longitudinal shear) forces through rigid supports bonded to the specimen and record force–displacement behavior.
- Test machine: constant movement of the movable head at (3 ± 0.5) mm/min, force and displacement measurement with maximum error 1 %. Displacement transducers may be required when adhesive layers are thick.
- Specimen arrangements:
- Single specimen: square specimen 250 mm × 50 mm, thickness = product thickness (max 50 mm).
- Double specimen: two square parts 200 mm × 100 mm each, assembled per the standard.
- Specimen supports and fixtures: rigid metal plates (examples: 330 mm × 50 mm, 16 mm thick) and arrangements ensuring parallelism and rigidity to avoid test artefacts.
- Adhesive: adhesive film must have shear strength and modulus greater than the product so failure occurs in the specimen, not the bond.
- Specimen preparation & dimensions: retain coatings/facings; flatness/parallelism tolerance ≤ 0.5 % of thickness (max 0.5 mm). Dimensional measurement per EN 12085.
- Conditioning and test conditions: store specimens ≥ 6 h at (23 ± 5) °C (dispute condition: 23 ± 2 °C, 50 ± 5 % RH). Test normally at (23 ± 5) °C.
- Number of specimens: follow the relevant product standard; if absent, at least five specimens.
- Results: calculate shear strength (τ) and shear modulus (G) from measured force–displacement curves.
Practical applications - who uses this standard
- Manufacturers of thermal insulation (mineral wool, rigid foam boards, composite panels) use EN 12090:2013 for product development, quality control and to support performance claims.
- Test laboratories and certification bodies perform reproducible shear tests for compliance, CE marking and technical approvals.
- Specifiers, engineers and consultants assessing insulation performance in wall assemblies where tangential stresses (sliding, layering, adhesive joints) are critical.
- Regulatory authorities and standards committees referencing a harmonized method for comparative data across products.
Related standards
EN 12090 is part of the EN/TC 88 series on thermal insulating products. Relevant companion methods include:
- EN 12085 (dimensions of test specimens)
- EN 822 / EN 823 / EN 824 / EN 825 / EN 826 and others for length, thickness, squareness, flatness, compression and related properties.
Keywords: EN 12090:2013, shear behaviour, thermal insulating products, shear strength, shear modulus, thermal insulation shear test, CEN standard, test specimens, single test specimen, double test specimen.
Frequently Asked Questions
EN 12090:2013 is a standard published by the European Committee for Standardization (CEN). Its full title is "Thermal insulating products for building applications - Determination of shear behaviour". This standard covers: This European Standard specifies the equipment and procedures for determining shear behaviour. It is applicable to thermal insulating products. NOTE The tests described in this standard do not determine pure shear behaviour, but measure the effects of applying two opposite parallel forces to the major faces of the test specimen. The test is however called shear in this text by convention. The application of a force tangentially to the major surface of the test specimen is considered to represent more closely the stresses imposed upon thermal insulation products in many building applications, particularly walls, than other methods of measuring shear performance e.g. bending tests.
This European Standard specifies the equipment and procedures for determining shear behaviour. It is applicable to thermal insulating products. NOTE The tests described in this standard do not determine pure shear behaviour, but measure the effects of applying two opposite parallel forces to the major faces of the test specimen. The test is however called shear in this text by convention. The application of a force tangentially to the major surface of the test specimen is considered to represent more closely the stresses imposed upon thermal insulation products in many building applications, particularly walls, than other methods of measuring shear performance e.g. bending tests.
EN 12090:2013 is classified under the following ICS (International Classification for Standards) categories: 91.100.60 - Thermal and sound insulating materials; 91.100.99 - Other construction materials. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 12090:2013 has the following relationships with other standards: It is inter standard links to EN 12090:1997. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 12090:2013 is associated with the following European legislation: EU Directives/Regulations: 305/2011, 89/106/EEC. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
