EN 12599:2026
(Main)Ventilation for buildings - Test procedures and measurement methods to hand over air conditioning and ventilation systems for non-residential buildings
- Abstract
This document specifies checks, measurement methods and procedures in order to verify the fitness for purpose of the installed ventilation systems and air conditioning systems according to design.
It establishes a procedure intended to technically support the handing over and inspection of these systems.
This document enables the choice between checks and measurements when sufficient, and additional measurements, when necessary.
This document applies to mechanical ventilation systems (including the mechanical part of hybrid systems) and full and (partial) air conditioning systems in non-residential (parts of) buildings.
This document does not apply to:
— heat generating systems and their control;
— refrigerating systems and their control;
— distribution of heating and cooling medium to the air handling units;
— compressed air supplying systems;
— water conditioning systems;
— central steam generating systems for air humidifying;
— electric supply systems.
This document is not applicable to ventilation systems and air conditioning systems for industrial or other special process environments.
- Status
- Published
- Publication Date
- 06-Oct-2026
- Technical Committee
- CEN/TC 156 - Ventilation for buildings
- Drafting Committee
- CEN/TC 156/WG 8 - Installation
- Current Stage
- 6060 - Definitive text made available (DAV) - Publishing
- Start Date
- 07-Oct-2026
- Due Date
- 27-May-2026
- Completion Date
- 07-Oct-2026
EN 12599:2026 is a CEN standard for test procedures and measurement methods used to hand over ventilation and air conditioning systems in non-residential buildings. It specifies checks, measurements and reporting steps to verify that an installed system matches the design and is fit for purpose. The document applies to mechanical ventilation systems, including the mechanical part of hybrid systems, and to full or partial air conditioning systems.
What does EN 12599:2026 specify?
EN 12599:2026 specifies the procedure for checking, measuring and documenting installed ventilation and air conditioning systems before handover or inspection. It is intended to support technical acceptance of the installation, and it allows checks alone when they are sufficient, or extra measurements when needed.
The scope is limited to non-residential buildings or parts of buildings. It does not cover:
- heat generating systems and their control
- refrigerating systems and their control
- distribution of heating and cooling medium to air handling units
- compressed air supplying systems
- water conditioning systems
- central steam generating systems for air humidifying
- electric supply systems
The document is also not applicable to industrial or other special process environments.
The body of the document runs from the scope and normative references through terms, the test and check procedure, administrative and completeness checks, functional checks, measurements, additional measurements, uncertainty, and test reports.
| Annex | What it covers |
|---|---|
| Annex A | Administrative and completeness check, including a report example |
| Annex B | Functional checks for components and control functions |
| Annex C | Determination of the extent of functional checks or measurements |
| Annex D | Surface area calculation of ductworks |
| Annex E | Additional measurements for pressure, temperature, humidity, indoor air quality and room conditions |
| Annex F | Technical specifications to agree before testing |
| Annex G | Examples for determining the number of functional checks and measurements |
| Annex H | Examples for measurement uncertainty |
| Annex I | Calculations on airflow correction under reference conditions |
What are the key requirements of EN 12599:2026?
EN 12599:2026 sets out a clear order for handover work: administrative checks, completeness checks, functional checks, measurements, additional measurements when required, and then a report. In practice, that means the team should first verify documents and installation completeness before spending time on detailed performance measurements.
Administrative checks and completeness checks
Clause 5 requires an administrative check before on-site measurement work starts. EN 12599:2026 expects the relevant specifications, inventory documents, operation and maintenance documents, balancing reports and any earlier measurement reports to be available. This matters because missing documentation can make later acceptance unclear or hard to defend.
Clause 6 requires a completeness check to confirm that the installation matches the specification and the relevant technical rules. Annex A expands this into checks on accessibility, cleanliness, fire protection, insulation, marking, damage, balancing and the condition of major components such as air handling units, fans, heat exchangers, filters, humidifiers, dampers and ductwork. For the reader, this means the physical installation is checked for completeness before performance is judged.
Functional checks
Clause 7 requires functional checks on all types of installed equipment. These checks verify that the system operates correctly in its relevant modes, including the response of control devices to changed sensor values where occupancy or demand control is used. Annex B lists component checks for air handling units, fans, heat exchangers, filters, humidifiers, dampers, fire and smoke dampers, ductwork, room air flow pattern and control cabinets. In practice, this confirms that the installed system actually reacts as designed, not just that it is present.
Sampling and extent of checks
Annex C sets the method for deciding how many similar locations need to be checked or measured. EN 12599:2026 uses sampling levels SL1 to SL5, with the default being SL5 if nothing else is agreed. The same annex explains how similar locations are identified and how sample size is calculated. This matters on larger projects because it allows a justified sample instead of testing every identical point.
Measurements and measurement quality
Clause 8 covers the measurements used to verify design conditions and set points. Table 2 in the document shows which measurements are relevant, required or optional for different system types and functions, and Clause 8 requires the measurement conditions to be recorded. Table 3 gives target expanded uncertainties for key measurands such as air flow rate, supply air temperature, relative humidity, air velocity, air temperature in the occupied zone and A-weighted sound pressure level. In practice, this tells the testing team what level of measurement quality to aim for and what to record with the result.
Air flow rate measurements are carried out according to EN 16211. EN 12599:2026 also covers ductwork airtightness testing, room air velocity, air temperature, air humidity, sound pressure level, fan electrical power and filter pressure difference. For the reader, these are the performance checks that show whether the system delivers the design air movement, comfort and operating conditions.
Ductwork airtightness
Clause 8.4.3 gives a full on-site method for testing air distribution system and ductwork tightness against the ATC classes in EN 16798-3. It explains the test section, the surface area basis, the test rig, the test pressure, the leakage factor calculation and the reporting of achieved class. Annex D supplies the duct surface area calculation needed for the leakage factor, and Annex I gives airflow correction under reference conditions. In practice, this is the part to use when duct leakage must be proven with a traceable on-site method.
Additional measurements and reporting
Clause 9 covers additional measurements when the standard measurements are not enough or when specific components need separate testing. It includes fans, filters, heat exchangers, humidifiers and control and switching systems. Clause 10 requires measurement uncertainty to be evaluated according to JCGM 100 and expressed as expanded uncertainty with k = 2.
Clause 11 defines the handing over report. It must bring together the general project information, the completeness check, the functional check, the measurement results, any additional measurements and a summary with corrective actions. That report is the formal record of acceptance and deviations.
What terms does EN 12599:2026 define?
- Handover - the process of transferring responsibility for an installation to another person or organization.
- Check - an examination carried out without measurements to confirm that something is correct or as it should be.
- Administrative check - a check of the documentation and specifications of an installation.
- Completeness check - a check of the completeness and arrangement of an installation.
- Functional check - a check of the operation of a primary function of an installation.
- Balancing - the adjustment of the flow rates in each circuit of an installation to meet the specifications.
Who uses EN 12599:2026?
EN 12599:2026 is used by the people who design, install, commission, inspect and accept ventilation and air conditioning systems in non-residential buildings. That includes HVAC contractors, commissioning engineers, test personnel, consultants, facility managers, quality managers and buyers who need a clear handover basis.
It is especially useful when a project needs documented proof that the installation matches the design, that the controls respond correctly, and that measured performance is recorded with an agreed level of uncertainty. It also supports later inspections and maintenance checks.
What changed in EN 12599:2026 from the previous edition?
EN 12599:2026 supersedes EN 12599:2012. The foreword states these significant changes:
- the scope was changed so the document applies to non-residential buildings only
- the wording was updated to show that the procedures support handover and inspections
- the normative references were updated
- air flow measurement methods were transferred to EN 16211
- ductwork airtightness testing according to the ATC classes of EN 16798-3 was added
- Annex C was revised with new sampling levels based on sampling errors
- the ductwork surface area calculation was added as Annex D
- “Special measurements” were renamed “Additional measurements”
- the approach to measurement uncertainty was revised
Which standards are used with EN 12599:2026?
EN 12599:2026 cites four normative references:
- EN 16211 - provides the site methods for measuring air flow rates
- EN 16798-3 - provides non-residential ventilation performance requirements and the ATC airtightness classes used for ductwork testing
- EN ISO 7730 - provides the PMV and PPD thermal comfort framework used when assessing room conditions
- JCGM 100 - provides the general rules for expressing measurement uncertainty
The introduction also says that EN 12599:2026, together with EN 16211, is applicable within the energy inspection framework of EN 16798-17 and CEN/TR 16798-18.
What does the EN 12599:2026 document contain?
EN 12599:2026 contains checklists, test procedures, sampling rules, measurement methods, uncertainty guidance and report structures for handover work. Annex A and Annex B give practical component-level checks, while Annex C turns “how many locations?” into a sampling method.
The document also includes formulas and examples for ductwork surface area, airtightness testing and airflow correction under reference conditions. Annex E covers pressure, temperature, humidity, indoor air quality and room measurements, and Annex H explains how to build measurement uncertainty from instrument, method and calculation contributions. In practice, the document is a commissioning and acceptance framework, not just a list of test points.
Relations
- Effective Date
- 19-Jan-2023
- Effective Date
- 21-Oct-2026
- Effective Date
- 21-Oct-2026
- Effective Date
- 14-Oct-2026
- Effective Date
- 14-Oct-2026
- Effective Date
- 14-Oct-2026
- Referred By
EN 15780:2011 - Ventilation for buildings - Ductwork - Cleanliness of ventilation systems - Effective Date
- 14-Oct-2026
- Effective Date
- 14-Oct-2026
Get Certified
Connect with accredited certification bodies for this standard
DIBt (Deutsches Institut für Bautechnik)
German Institute for Building Technology.
DIN CERTCO
DIN Group product certification.
Aboma Certification B.V.
Specialized in construction, metal, and transport sectors.
Sponsored listings
Frequently Asked Questions
EN 12599:2026 is a standard published by the European Committee for Standardization (CEN). Its full title is "Ventilation for buildings - Test procedures and measurement methods to hand over air conditioning and ventilation systems for non-residential buildings". This standard covers: This document specifies checks, measurement methods and procedures in order to verify the fitness for purpose of the installed ventilation systems and air conditioning systems according to design. It establishes a procedure intended to technically support the handing over and inspection of these systems. This document enables the choice between checks and measurements when sufficient, and additional measurements, when necessary. This document applies to mechanical ventilation systems (including the mechanical part of hybrid systems) and full and (partial) air conditioning systems in non-residential (parts of) buildings. This document does not apply to: — heat generating systems and their control; — refrigerating systems and their control; — distribution of heating and cooling medium to the air handling units; — compressed air supplying systems; — water conditioning systems; — central steam generating systems for air humidifying; — electric supply systems. This document is not applicable to ventilation systems and air conditioning systems for industrial or other special process environments.
This document specifies checks, measurement methods and procedures in order to verify the fitness for purpose of the installed ventilation systems and air conditioning systems according to design. It establishes a procedure intended to technically support the handing over and inspection of these systems. This document enables the choice between checks and measurements when sufficient, and additional measurements, when necessary. This document applies to mechanical ventilation systems (including the mechanical part of hybrid systems) and full and (partial) air conditioning systems in non-residential (parts of) buildings. This document does not apply to: — heat generating systems and their control; — refrigerating systems and their control; — distribution of heating and cooling medium to the air handling units; — compressed air supplying systems; — water conditioning systems; — central steam generating systems for air humidifying; — electric supply systems. This document is not applicable to ventilation systems and air conditioning systems for industrial or other special process environments.
EN 12599:2026 is classified under the following ICS (International Classification for Standards) categories: 91.140.30 - Ventilation and air-conditioning systems. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 12599:2026 has the following relationships with other standards: It is inter standard links to EN 12599:2012, EN 16211:2024, EN 16798-3:2025, EN 15726:2011, EN 16282-5:2017, EN 15251:2007, EN 15780:2011, EN 16798-17:2017. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 12599:2026 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
