Ships and marine technology - Drainage systems on ships and marine structures - Part 2: Sanitary drainage, drain piping for gravity system (ISO 15749-2:2004)

ISO 15749-2:2004 applies to the design of sanitary drain lines in gravity systems (gravity drainage) on ships and marine structures.
For planning and basic requirements, ISO 15749-1 is applicable.

Schiffe und Meerestechnik - Entwässerungsanlagen auf Schiffen und Seebauwerken - Teil 2: Sanitär-Entwässerung, Abflussleitungen im Fallsystem (ISO 15749-2:2004)

Diese Norm gilt für die Konstruktion von Sanitär-Abflussleitungen in Fallsystemen (Schwerkraft-Entwässerung) auf Schiffen und Seebauwerken.
Für die Planung und grundsätzlichen Anforderungen gilt ISO 15749-1.

Navires et technologie maritime - Installations de drainage sur navires et structures maritimes - Partie 2: Drainage sanitaire, tuyaux de drainage pour système par gravité (ISO 15749-2:2004)

Ladje in pomorska tehnologija – Sistemi za odvajanje vode/odplak z ladij in struktur na morju – 2. del: Sanitarni sistem, odtočne cevi za težnostni sistem (ISO 15749-2:2004)

General Information

Status
Published
Publication Date
30-Apr-2004
Withdrawal Date
29-Nov-2004
ICS
47.020.30 - Piping systems
Technical Committee
CEN/TC 300 - Sea-going vessels and marine technology
Drafting Committee
CEN/TC 300 - Sea-going vessels and marine technology
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Start Date
01-May-2004
Completion Date
01-May-2004
Ref Project
SIST EN ISO 15749-2:2004 - Ships and marine technology - Drainage systems on ships and marine structures - Part 2: Sanitary drainage, drain piping for gravity system (ISO 15749-2:2004)

Overview

EN ISO 15749-2:2004 - Ships and marine technology - Drainage systems on ships and marine structures - Part 2: Sanitary drainage, drain piping for gravity system - specifies requirements for the design of sanitary drain lines using gravity drainage on ships and marine structures. It covers acceptable pipe materials and dimensions, routing and gradients, nominal bore sizing based on wastewater flow, cleaning and odour-control provisions, and interfaces with collector tanks or sewage treatment plants. For planning and basic requirements, see ISO 15749-1; for sewage disposal lines downstream of treatment, see ISO 15749-4.

Key topics and requirements

  • Scope: Design of sanitary drain lines in gravity systems that convey wastewater by gravity to a collector tank or sewage treatment plant.
  • Operating pressure: Sanitary drain and vent pipes shall be designed so internal pressure does not exceed 0.5 bar.
  • Approved pipe materials:
    • Steel (seamless, welded, threaded)
    • CuNiFe alloys (CuNi10Fe1.6Mn)
    • Spigot-and-socket steel or CuNiFe pipes
    • PVC-U (subject to IMO Resolution A.753 approval for plastic pipes)
  • Nominal bores (NB): Sizes and permitted materials are listed (common NBs include 32, 40, 50, 65, 80, 100, 125, 150). Branch and collecting pipe sizes are determined from flow-rate tables.
  • Flow-rate sizing: Nominal bores are calculated from standard flow rates for single branches (e.g., water closet ≈ 2.5 l/s → NB 100; urinal ≈ 0.5 l/s → NB 32–50). Collecting branches and gravity delivery lines use sum-flow tables to select NB.
  • Routing and gradient:
    • Drain lines must be self-draining; branch gradients typically from 1:100 to 1:66.7, main sewers 1:66.7 to 1:50.
    • Branches should be short; wastewater from midships should discharge at least one deck height down to both sides or center.
  • Operational features:
    • All sanitary fixtures and floor drains require odour seals.
    • Cleaning openings are mandatory where sections cannot otherwise be cleaned, notably in galleys and water-closet runs.
  • Testing and operation: Acceptance and leakage testing follow ISO 15749-1 procedures.

Applications and practical value

  • Use this standard when designing or installing sanitary gravity drainage on:
    • Commercial ships, ferries, offshore platforms, and other marine structures
    • Newbuild plumbing systems, refits, and upgrades
    • Integration with collector tanks and onboard sewage treatment plants
  • Practical benefits include consistent pipe selection, reliable self-draining layouts, compliance with classification societies, and safer sewage handling aboard vessels.

Who should use this standard

  • Marine and naval architects
  • Shipbuilders and shipyards
  • Marine engineers and piping designers
  • Classification societies and surveyors
  • Ship operators, shipboard maintenance teams, and regulatory compliance specialists

Related standards

  • ISO 15749-1 - Sanitary drainage-system design (planning/basic requirements)
  • ISO 15749-4 - Sewage disposal pipes (post-treatment discharge)
  • IMO Resolution A.753 - Approval guidelines for plastic pipes on ships

Keywords: EN ISO 15749-2:2004, sanitary drainage, gravity drainage, drain piping, ships, marine structures, collector tank, sewage treatment plant, PVC-U, CuNiFe, steel pipes, nominal bore.

Frequently Asked Questions

EN ISO 15749-2:2004 is a standard published by the European Committee for Standardization (CEN). Its full title is "Ships and marine technology - Drainage systems on ships and marine structures - Part 2: Sanitary drainage, drain piping for gravity system (ISO 15749-2:2004)". This standard covers: ISO 15749-2:2004 applies to the design of sanitary drain lines in gravity systems (gravity drainage) on ships and marine structures. For planning and basic requirements, ISO 15749-1 is applicable.

ISO 15749-2:2004 applies to the design of sanitary drain lines in gravity systems (gravity drainage) on ships and marine structures. For planning and basic requirements, ISO 15749-1 is applicable.

EN ISO 15749-2:2004 is classified under the following ICS (International Classification for Standards) categories: 47.020.30 - Piping systems. The ICS classification helps identify the subject area and facilitates finding related standards.

You can purchase EN ISO 15749-2:2004 directly from iTeh Standards. The document is available in PDF format and is delivered instantly after payment. Add the standard to your cart and complete the secure checkout process. iTeh Standards is an authorized distributor of CEN standards.

Standards Content (Sample)


2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Schiffe und Meerestechnik - Entwässerungsanlagen auf Schiffen und Seebauwerken - Teil 2: Sanitär-Entwässerung, Abflussleitungen im Fallsystem (ISO 15749-2:2004)Navires et technologie maritime - Installations de drainage sur navires et structures maritimes - Partie 2: Drainage sanitaire, tuyaux de drainage pour systeme par gravité (ISO 15749-2:2004)Ships and marine technology - Drainage systems on ships and marine structures - Part 2: Sanitary drainage, drain piping for gravity system (ISO 15749-2:2004)47.020.30Sistemi ceviPiping systemsICS:Ta slovenski standard je istoveten z:EN ISO 15749-2:2004SIST EN ISO 15749-2:2004en01-september-2004SIST EN ISO 15749-2:2004SLOVENSKI
STANDARD
Reference numberISO 15749-2:2004(E)© ISO 2004
INTERNATIONAL STANDARD ISO15749-2First edition2004-05-01Ships and marine technology — Drainage systems on ships and marine structures — Part 2: Sanitary drainage, drain piping for gravity systems Navires et technologie maritime — Installations de drainage sur navires et structures maritimes — Partie 2: Drainage sanitaire, tuyaux de drainage pour système par gravité
ISO 15749-2:2004(E) PDF disclaimer This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but shall not be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In downloading this file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat accepts no liability in this area. Adobe is a trademark of Adobe Systems Incorporated. Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation parameters were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In the unlikely event that a problem relating to it is found, please inform the Central Secretariat at the address given below.
©
ISO 2004 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or ISO's member body in the country of the requester. ISO copyright office Case postale 56 • CH-1211 Geneva 20 Tel.
+ 41 22 749 01 11 Fax
+ 41 22 749 09 47 E-mail
copyright@iso.org Web
www.iso.org Published in Switzerland
ii © ISO 2004 – All rights reserved
ISO 15749-2:2004(E) © ISO 2004 – All rights reserved iii Contents Page Foreword.iv 1 Scope.1 2 Normative references.1 3 Terms and definitions.2 4 Gravity systems.2 5 Pipes.2 6 Laying of drain lines.4 7 Determination of nominal bores.5 8 Collector tank and sewage treatment plant.7 9 Testing and operation of pipes.7 10 Disposal.7 11 Example of wastewater system.8
ISO 15749-2:2004(E) iv © ISO 2004 – All rights reserved Foreword ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies (ISO member bodies). The work of preparing International Standards is normally carried out through ISO technical committees. Each member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, governmental and non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization. International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 2. The main task of technical committees is to prepare International Standards. Draft International Standards adopted by the technical committees are circulated to the member bodies for voting. Publication as an International Standard requires approval by at least 75 % of the member bodies casting a vote. Attention is drawn to the possibility that some of the elements of this document may be the subject of patent rights. ISO shall not be held responsible for identifying any or all such patent rights. ISO 15749-2 was prepared by Technical Committee ISO/TC 8, Ships and marine technology, Subcommittee SC 3, Piping and machinery. ISO 15749 consists of the following parts, under the general title Ships and marine technology — Drainage systems on ships and marine structures: — Part 1: Sanitary drainage-system design — Part 2: Sanitary drainage, drain piping for gravity systems — Part 3: Sanitary drainage, drain piping for vacuum systems — Part 4: Sanitary drainage, sewage disposal pipes — Part 5: Drainage of decks, cargo spaces and swimming pools
INTERNATIONAL STANDARD ISO 15749-2:2004(E) © ISO 2004 – All rights reserved 1 Ships and marine technology — Drainage systems on ships and marine structures — Part 2: Sanitary drainage, drain piping for gravity systems 1 Scope This part of ISO 15749 applies to the design of sanitary drain lines in gravity systems (gravity drainage) on ships and marine structures. For planning and basic requirements, see ISO 15749-1. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. IMO Resolution A.753 (18), Guidelines for the application of plastic pipes on ships 1) ISO 65, Carbon steel tubes suitable for screwing in accordance with ISO 7-1 ISO 4200, Plain end steel tubes, welded and seamless — General tables of dimensions and masses per unit length ISO 7268, Pipe components — Definition of nominal pressure ISO 9329-1, Seamless steel tubes for pressure purposes — Technical delivery conditions — Part 1: Unalloyed steels with specific room temperature properties ISO 9330-1, Welded steel tubes for pressure purposes — Technical delivery conditions — Part 1: Unalloyed steel tubes with specified room temperature properties
ISO 15749-1, Ships and marine technology — Drainage systems on ships and marine structures — Part 1: Sanitary drainage-system design ISO 15749-4, Ships and marine technology — Drainage systems on ships and marine structures — Part 4: Sanitary drainage, sewage disposal pipes
1) Published by International Maritime Organization, London. Available from IMO Secretariat, Publications Section, 101-104 Piccadilly, London W1V, United Kingdom. SIST EN ISO 15749-2:2004

ISO 15749-2:2004(E) 2 © ISO 2004 – All rights reserved 3 Terms and definitions For the purposes of this document, the terms and definitions given in ISO 15749-1 apply. 4 Gravity systems 4.1 Description 4.1.1 Drain lines in gravity systems convey wastewater by gravity to a collector tank or sewage treatment plant. 4.1.2 Wastewater lines downstream of the sewage treatment plant are not part of the gravity system. For their configuration, ISO 15749-4 applies. 4.1.3 Figure 1 gives an example of a drainage system with drain lines in a gravity system. 4.2 Operating pressure Pipes in sanitary systems (drain and vent lines) shall be designed such that the operating pressure 2) (internal pressure) cannot exceed 0,5 bar. 5 Pipes 5.1 General Depending on the location, the following pipes may be used for gravity drain lines and vent lines:  steel pipes in accordance with 5.2;  steel pipes and CuNiFe pipes with spigot and socket joints 3) in accordance with 5.3;  CuNiFe pipes in accordance with 5.4;  PVC-U pipes in accordance with 5.5; plastic pipes shall be approved in accordance with IMO Resolution A.753 (18). For nominal bores see Table 1. Table 1 — Nominal bores for drain lines Nominal bore, NB 32 40 50 65 70 80 100 125 150 Steel and CuNiFe pipes X X X X — X X X X Spigot and socket pipes — X X — X X X X X PVC-U pipes X X X X — X X X X X: NB possible for this type of pipe; —: NB not possible for this type of pipe.
2) For definitions see ISO 7268. 3) Hereinafter referred to as spigot and socket pipes. SIST EN ISO 15749-2:2004

ISO 15749-2:2004(E) © ISO 2004 – All rights reserved 3 5.2 Steel p
...
