EN 10277-5:2008

Bright steel products - Technical delivery conditions - Part 5: Steels for quenching and tempering

This part of EN 10277 applies to bright steel bars in the drawn, turned or ground condition, in straight lengths of steels for quenching and tempering.
This EN 10277-5 is complemented by EN 10277-1.

Blankstahlerzeugnisse - Technische Lieferbedingungen - Teil 5: Vergütungsstähle

Dieser Teil der EN 10277 gilt für gerichteten und abgelängten Blankstahl im gezogenen, geschälten oder
geschliffenen Zustand aus Vergütungsstählen.
Diese EN 10277-5 wird vervollständigt durch EN 10277-1.

Produits en acier transformés à froid - Conditions techniques de livraison - Partie 5: Aciers pour trempe et revenu

La présente partie de l’EN 10277 s'applique aux barres en acier pour trempe et revenu, transformées à froid, à l'état étiré, écroûté galeté ou rectifié, en longueurs droites.
La présente norme EN 10277-5 est complétée par l’EN 10277-1.

Svetli jekleni izdelki - Tehnični dobavni pogoji - 5. del: Jekla za poboljšanje

General Information

• Status: Withdrawn
• Publication Date: 11-Mar-2008
• Withdrawal Date: 19-Jun-2018
• ICS: 77.140.20 - Stainless steels
• ICS: 77.140.60 - Steel bars and rods
• Technical Committee: ECISS/TC 105 - Steels for heat treatment, alloy steels, free-cutting steels and stainless steels
• Drafting Committee: ECISS/TC 105 - Steels for heat treatment, alloy steels, free-cutting steels and stainless steels
• Current Stage: 9960 - Withdrawal effective - Withdrawal
• Completion Date: 20-Jun-2018
• Directive: 97/23/EC - Directive 97/23/EC of the European Parliament and of the Council of 29 May 1997 on the approximation of the laws of the Member States concerning pressure equipment
• Mandate: M/005 - Mandate to CEN/ECISS concerning standardization in the iron and steel sector
• Mandate: M/071 - Mandate to CEN for standardization in the field of Pressure equipment
• Ref Project: SIST EN 10277-5:2008 - Bright steel products - Technical delivery conditions - Part 5: Steels for quenching and tempering

Relations

• Replaces: EN 10277-5:1999 - Bright steel products - Technical delivery conditions - Part 5: Steels for quenching and tempering
• Effective Date: 22-Dec-2008
• Replaced By: EN 10277:2018 - Bright steel products - Technical delivery conditions
• Effective Date: 19-Oct-2016

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Blankstahlerzeugnisse - Technische Lieferbedingungen - Teil 5: VergütungsstähleProduits en acier transformés à froid - Conditions techniques de livraison - Partie 5: Aciers pour trempe et revenuBright steel products - Technical delivery conditions - Part 5: Steels for quenching and tempering77.140.01Železni in jekleni izdelki na splošnoIron and steel products in generalICS:Ta slovenski standard je istoveten z:EN 10277-5:2008SIST EN 10277-5:2008en,fr,de01-maj-2008SIST EN 10277-5:2008SLOVENSKI
STANDARDSIST EN 10277-5:20001DGRPHãþD

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 10277-5March 2008ICS 77.140.20; 77.140.60Supersedes EN 10277-5:1999
English VersionBright steel products - Technical delivery conditions - Part 5:Steels for quenching and temperingProduits en acier transformés à froid - Conditionstechniques de livraison - Partie 5: Aciers pour trempe etrevenuBlankstahlerzeugnisse - Technische Lieferbedingungen -Teil 5: VergütungsstähleThis European Standard was approved by CEN on 4 February 2008.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2008 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 10277-5:2008: ESIST EN 10277-5:2008

2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 10083-2, Steels for quenching and tempering - Part 2: Technical delivery conditions for non alloy steels EN 10083-3, Steels for quenching and tempering - Part 3: Technical delivery conditions for alloy steels EN 10277-1, Bright steel products - Technical delivery conditions - Part 1: General 3 Terms and definitions For the purposes of this European Standard, the terms and definitions given in EN 10277-1 and the following apply. 3.1 steels for quenching and tempering engineering steels which because of their chemical composition are suitable for hardening and in the quenched and tempered condition have good toughness at a given tensile strength. 4 Classification and designation
4.1 Classification Steel grades C35E, C35R, C40E, C40R, C45E, C45R, C50E, C50R, C60E and C60R are non-alloy special steels. All other steel grades covered by this European Standard are alloy special steels. 4.2 Designation See EN 10277-1. 5 Information to be supplied by the purchaser See EN 10277-1. 6 Manufacturing process See EN 10277-1. SIST EN 10277-5:2008

The mechanical properties of the steels shall be as specified in Table 3, Table 4 and Table 5.
7.3 Hardenability Where steels are ordered with hardenability requirements, the requirements of EN 10083-2 shall apply for non alloyed steels and EN 10083-3 shall apply for alloyed steels.
7.4 Grain size Unless otherwise agreed at the time of ordering the grain size of non-alloy steels shall be left to the discretion of the manufacturer. If a fine grain structure is required in accordance with a reference treatment, option B.2 of EN 10277-1 shall be ordered. All alloy steels shall show an austenitic grain size of 5 or finer. Only for verification see B.2 of EN 10277-1. 7.5 Non-metallic inclusions 7.5.1 Microscopic inclusions The steels shall have a cleanness corresponding to special steel quality. For details of the requirements for the verification of non-alloy steels see EN 10083-2, A.4 for and of alloy steels see EN 10083-3, A.3. 7.5.2 Macroscopic inclusions As freedom from macroscopic inclusions cannot be guaranteed in any steel, any requirement to verify the level present shall be agreed at the time of enquiry and order (see EN 10277-1, 7.5.2 and B.3.2). 7.6 Options
See Annex B of EN 10277-1. 8 Inspection and testing 8.1 Types and contents of inspection documents See EN 10277-1. SIST EN 10277-5:2008

Steel name Steel number Steel grade according to Cd
Si max. Mn P max. S Cr Mo Ni V Cr+Mo+Ni max.d C35E 1.1181 EN 10083-2 0,32 to 0,39 0,40 0,50 to 0,80 0,030 ≤ 0,035 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C35R 1.1180 EN 10083-2 0,32 to 0,39 0,40 0,50 to 0,80 0,030 0,020 to 0,040 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C40E 1.1186 EN 10083-2 0,37 to 0,44 0,40 0,50 to 0,80 0,030 ≤ 0,035 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C40R 1.1189 EN 10083-2 0,37 to 0,44 0,40 0,50 to 0,80 0,030 0,020 to 0,040 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C45E 1.1191 EN 10083-2 0,42 to 0,50 0,40 0,50 to 0,80 0,030 ≤ 0,035 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C45R 1.1201 EN 10083-2 0,42 to 0,50 0,40 0,50 to 0,80 0,030 0,020 to 0,040 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C50E 1.1206 EN 10083-2 0,47 to 0,55 0,40 0,60 to 0,90 0,030 ≤ 0,035 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C50R 1.1241 EN 10083-2 0,47 to 0,55 0,40 0,60 to 0,90 0,030 0,020 to 0,040 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C60E 1.1221 EN 10083-2 0,57 to 0,65 0,40 0,60 to 0,90 0,030 ≤ 0,035 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 C60R 1.1223 EN 10083-2 0,57 to 0,65 0,40 0,60 to 0,90 0,030 0,020 to 0,040 ≤ 0,40 ≤ 0,10 ≤ 0,40 - 0,63 34CrS4 1.7037 EN 10083-3 0,30 to 0,37 0,40 0,60 to 0,90 0,025 0,020 to 0,040 0,90 to 1,20 - - - - 41CrS4 1.7039 EN 10083-3 0,38 to 0,45 0,40 0,60 to 0,90 0,025 0,020 to 0,040 0,90 to 1,20 - - - - 25CrMoS4 1.7213 EN 10083-3 0,22 to 0,29 0,40 0,60 to 0,90 0,025 0,020 to 0,040 0,90 to 1,20 0,15 to 0,30 - - - 42CrMoS4 1.7227 EN 10083-3 0,38 to 0,45 0,40 0,60 to 0,90 0,025 0,020 to 0,040 0,90 to 1,20 0,15 to 0,30 - - - 34CrNiMo6 1.6582 EN 10083-3 0,30 to 0,38 0,40 0,50 to 0,80 0,025 ≤ 0,035 1,30 to 1,70 0,15 to 0,30 1,30 to 1,70 - - 39NiCrMo3 1.6510 EN 10083-3 0,35 to 0,43 0,40 0,50 to 0,80 0,025 ≤ 0,035 0,60 to 1,00 0,15 to 0,25 0,70 to 1,00 - - 51CrV4 1.8159 EN 10083-3 0,47 to 0,55 0,40 0,70 to 1,10 0,025 ≤ 0,025 0,90 to 1,20 - - 0,10 to 0,25 - a Elements not quoted shall not be intentionally added to the steel without the agreement of the purchaser, other than for the purpose of finishing the heat. All reasonable precautions shall be taken to prevent the addition of such elements from scrap or other material used in manufacture, which affect the hardenability, mechanical properties and applicability. b Where requirements are made on hardenability (see 7.3) slight deviations from the limits for the cast analysis are permissible, except for the elements, carbon (see footnote d), phosphorus and sulphur; the deviations shall not exceed the specifications of Table 2. c Steels with improved machinability as a result of the addition of higher sulphur contents up to around 0,10 % S (including resulphurized steels with controlled inclusion content (e.g. Ca-treatment))
(modern method) or lead may be supplied on request. In the first case the upper limit for the manganese content may be increased by 0,15 %. d If the unalloyed steels are ordered without hardenability requirements (symbols +H, +HH, +HL) or without requirements on the mechanical properties in the quenched and tempered condition restrictio
...
