EN 1870-5:2002+A2:2012

Safety of woodworking machines - Circular sawing machines - Part 5: Circular sawbenches/up-cutting cross-cut sawing machines

This European Standard deals with all significant hazards, hazardous situations and events as listed in Clause 4 which are relevant to circular saw benches/up-cutting cross-cut sawing machines, hereinafter referred to as machines, designed to cut solid wood, chipboard, fibreboard, plywood and also these materials if (where) they are covered with plastic edging and/or plastic/light alloy laminates when they are used as intended and under the conditions foreseen by the manufacturer including reasonably foreseeable misuse.
This European Standard does not apply to:
hand-held motor-operated electric tools or any adaptation permitting their use in a different mode, i.e. bench mounting;
NOTE 1   Hand-held motor-operated electric tools and saw benches to form an integrated whole with a hand-held motor-operated electric tools are covered by EN 60745-1:2006 together with EN 60745-2-5:2007.
machines set up on a bench or a table similar to a bench, which is intended to carry out work in a stationary position, capable of being lifted by one person by hand.
NOTE 2   Transportable motor-operated electric tools are covered by the requirements of EN 61029-1:2000 together with EN 61029-2-1:2002.
deleted text
For Computer Numerically Controlled (CNC) machines this European Standard does not cover hazards related to Electro-Magnetic Compatibility (EMC).
This European Standard is primarily directed at machines which are manufactured after the date of issue of this European Standard.
NOTE 3   Circular saw benches are dealt with in #prEN 1870-19:2011.
NOTE 4   Machines covered by this document are listed under 1.1 of Annex IV of the Machinery Directive.

Sicherheit von Holzbearbeitungsmaschinen - Kreissägemaschinen - Teil 5: Kombinierte Tischkreissägemaschinen/von unten schneidende Kappsägemaschinen

!Dieses Dokument behandelt die in Abschnitt 4 aufgeführten signifikanten Gefährdungen, Gefährdungs-situationen und Gefährdungsereignisse, die auf kombinierte Tischkreissägemaschinen/von unten schneidende Kappsägemaschinen zutreffen  im Folgenden als Maschinen bezeichnet  die konstruiert sind zum Schneiden von Massivholz, Spanplatten, Faserplatten oder Sperrholz, sowie diesen Werkstoffen, wenn sie mit Kunststoffkanten versehen und/oder kunststoff/aluminium-beschichtet sind."
Diese Europäische Norm gilt nicht für:
   !handgeführte motorbetriebene Elektrowerkzeuge oder irgendwelchen Einrichtungen, die ihre Verwen-dung in einer anderen Weise z. B. in einer Stationäreinrichtung ermöglichen;"
!ANMERKUNG 1   Handgeführte motorbetriebene Elektrowerkzeuge und Sägetische, die eine Gesamtheit mit einem handgeführten motorbetriebenen Elektrowerkzeug bilden, sind in EN 60745-1:2006 zusammen mit EN 60745-2-5:2007 behandelt."
   !Maschinen, die auf ein Gestell oder auf einen Tisch, der einem Gestell ähnlich ist, aufgesetzt sind, und die vorgesehen sind, während des Betriebs stationär verwendet zu werden, und die von Hand von einer Person angehoben werden können."
!ANMERKUNG 2   Transportable motorbetriebene Elektrowerkzeuge sind durch die Anforderungen in EN 61029 1:2000 zusammen mit EN 61029-2-1:2002 erfasst."
!gestrichener Text"
Diese Europäische Norm behandelt bei CNC-Maschinen nicht die Gefährdungen im Zusammenhang mit der elektromagnetischen Verträglichkeit (EMV).
Diese Europäische Norm ist in erster Linie auf Maschinen anzuwenden, die nach dem Datum der Herausgabe dieser Europäischen Norm hergestellt werden.
!ANMERKUNG 3"   Tischkreissägemaschinen werden in EN 1870-1:1999 behandelt.

Sécurité des machines pour le travail du bois - Machines à scie circulaire - Partie 5: Scies circulaires combinées à table et à coupe transversale ascendante

Le présent document traite des phénomènes, situations et événements dangereux significatifs tels qu’énumérés dans l'Article 4 qui sont pertinents pour les scies circulaires combinées à table et à coupe transversale ascendante, ci-après désignées «machines», conçues pour la coupe de bois massif, de panneaux de particules, de panneaux de fibres, de contreplaqué, ainsi que ces matériaux lorsque leurs surfaces ou leurs chants sont recouverts de matière plastique et/ou de plastique/alliage léger stratifié durant l'utilisation normale et dans les conditions prévues par le fabricant, incluant une mauvaise utilisation raisonnablement prévisible.
Le présent document ne s'applique pas aux :
-   outils électriques à moteur portatifs ou toute adaptation permettant leur utilisation de manière différente, c'est-à-dire fixés sur un établi ;
NOTE 1   Les outils électriques portatifs à moteur et les scies à table destinés à former un ensemble intégré avec des outils électriques portatifs à moteur sont couverts par l'EN 60745-1:2006 et l'EN 60745 2 5:2007.
-   machines montées sur un établi ou une table similaire à un établi, conçues pour réaliser un travail en position fixe et qui peuvent être soulevées à la main par une personne.
NOTE 2   Les outils électriques transportables à moteur sont couverts par les exigences de l'EN 61029-1:2009 et de l'EN 61029-2-1:2002.
-texte supprimé-
Le présent document n'est pas applicable aux machines fabriquées avant la date de publication de la présente Norme européenne.
NOTE 3   Les scies circulaires à table sont traitées dans le prEN 1870-19:2011.
NOTE 4   Les machines couvertes par le présent document sont énumérées en 1.1 de l'Annexe IV de la Directive Machines.

Varnost lesnoobdelovalnih strojev - Krožne žage - 5. del: Krožne žage z delovno mizo/krožne žage za prečni rez od spodaj navzgor (z dopolnili do vključno A2)

Ta dokument obravnava vsa večja tveganja, nevarne razmere in dogodke iz točke 4, ki se nanašajo na krožne žage z delovno mizo/krožne žage za prečni rez od spodaj navzgor, v nadaljnjem besedilu »stroji«, ki so namenjene za rezanje polnega lesa, ivernih plošč, vlaknenih plošč, vezanih plošč in teh materialov, prevlečenih s plastično obrobo in/ali plastjo iz plastike/lahkih zlitin, #ter se uporabljajo v skladu z namenom in pod pogoji, ki jih je predvidel proizvajalec, vključno z razumno predvideno nepravilno uporabo. Ta dokument se ne uporablja za: – električna ročna orodja ali njihovo prilagajanje, ki omogoča njihovo uporabo na drugačen način, npr. namestitev na delovno mizo; stroje na delovni mizi ali na njej podobni mizi, ki so namenjeni delu v stacionarnem položaju in jih lahko z roko dvigne ena oseba. Ta dokument ne velja za stroje, ki so bili izdelani, preden je bil izdan ta standard EN.

General Information

• Status: Published
• Publication Date: 11-Sep-2012
• Withdrawal Date: 30-Mar-2013
• ICS: 79.120.10 - Woodworking machines
• Technical Committee: CEN/TC 142 - Woodworking machines - Safety
• Drafting Committee: CEN/TC 142/WG 14 - Safety of manually fed machines
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 16-Apr-2018
• Completion Date: 14-Apr-2025
• Directive: 2006/42/EC - Directive 2006/42/EC of the European Parliament and of the Council of 17 May 2006 on machinery, and amending Directive 95/16/EC (recast)
• Mandate: M/396 - Mandate to CEN and Cenelec for standardisation in the field of machinery
• Ref Project: SIST EN 1870-5:2003+A2:2012 - Safety of woodworking machines - Circular sawing machines - Part 5: Circular sawbenches/up-cutting cross-cut sawing machines

Relations

• Merged From: EN 1870-5:2002+A1:2009 - Safety of woodworking machines - Circular sawing machines - Part 5: Circular sawbenches/up-cutting cross-cut sawing machines
• Effective Date: 19-Jan-2023
• Merged From: EN 1870-5:2002+A1:2009/FprA2 - Safety of woodworking machines - Circular sawing machines - Part 5: Circular sawbenches/up-cutting cross-cut sawing machines
• Effective Date: 19-Jan-2023

Overview

EN 1870-5:2002+A2:2012 (equivalent to EN 1870-5:2002+A2:2012) is the European harmonised Type C standard for the safety of woodworking machines specifically addressing circular sawbenches and up‑cutting cross‑cut sawing machines. It covers significant hazards, hazardous situations and events (see Clause 4) for machines designed to cut solid wood, chipboard, fibreboard, plywood and these materials when covered with plastic edging or laminates, when used as intended or under reasonably foreseeable misuse. The standard incorporates Amendments A1 (2009) and A2 (2012) and supports conformity with the EU Machinery Directive (see informative Annex ZA).

Key topics and technical requirements

• Scope and exclusions: excludes hand‑held motor tools (and bench‑mounted adaptations), small bench/table machines liftable by one person, and-for CNC machines-EMC hazards are not covered in this document.
• Hazard listing: clause structure identifies mechanical and non‑mechanical hazards relevant to circular sawbenches/up‑cut cross‑cut machines.
• Safety requirements (Clause 5): general safety measures, control design, mechanical protection, and protection against non‑mechanical hazards (e.g., electrical, ergonomic, noise).
• Information for use (Clause 6): marking, instructions, and user information required from manufacturers.
• Normative tests and annexes (A–H): prescriptive test methods and criteria such as stability tests for open‑frame machines, saw spindle tolerances, riving knife strength and stability tests, saw blade guard stability and impact tests, and brake tests.
• Normative references: cross‑references to standards such as EN 60204‑1 (electrical equipment), EN 847‑1 (woodworking tooling), EN 1037 (prevention of unexpected start‑up), and EN 60529 (IP code) for complementary requirements.

Practical applications and who uses it

• Machine designers and manufacturers: to design, test and document circular sawbenches and up‑cut cross‑cut sawing machines that meet EU essential requirements.
• Suppliers, importers and conformity assessors: to demonstrate conformity with the Machinery Directive and support CE marking.
• Test laboratories and certification bodies: to perform the normative stability, guard impact and brake tests detailed in the annexes.
• Safety engineers, workshop managers and purchasers: to assess hazards, specify safe equipment and verify user information and guarding systems.

Related standards and compliance

• Harmonises with the EU Machinery Directive 2006/42/EC (see Annex ZA).
• Complements general safety standards such as EN ISO 12100 (risk assessment & design principles) and the tooling and electrical standards cited in its normative references (e.g., EN 847‑1, EN 60204‑1).

Keywords: SIST EN 1870-5, EN 1870-5, circular sawing machines, circular sawbenches, up-cutting cross-cut sawing machines, safety of woodworking machines, Machinery Directive, riving knife, saw blade guard, stability test, brake tests.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Sicherheit von Holzbearbeitungsmaschinen - Kreissägemaschinen - Teil 5: Kombinierte Tischkreissägemaschinen/von unten schneidende KappsägemaschinenSécurité des machines pour le travail du bois - Machines à scie circulaires - Partie 5: Scies circulaires combinées à table et à coupe transversale ascendanteSafety of woodworking machines - Circular sawing machines - Part 5: Circular sawbenches/up-cutting cross-cut sawing machines79.120.10Lesnoobdelovalni strojiWoodworking machines25.080.60Strojne žageSawing machinesICS:Ta slovenski standard je istoveten z:EN 1870-5:2002+A2:2012SIST EN 1870-5:2003+A2:2012en,fr,de01-december-2012SIST EN 1870-5:2003+A2:2012SLOVENSKI
STANDARDSIST EN 1870-5:2003+A1:20091DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 1870-5:2002+A2
September 2012 ICS 79.120.10 Supersedes
EN 1870-5:2002+A1:2009English Version
Safety of woodworking machines - Circular sawing machines - Part 5: Circular sawbenches/up-cutting cross-cut sawing machines
Sécurité des machines pour le travail du bois - Machines à scie circulaires - Partie 5: Scies circulaires combinées à table et à coupe transversale ascendante
Sicherheit von Holzbearbeitungsmaschinen - Kreissägemaschinen - Teil 5: Kombinierte Tischkreissägemaschinen/von unten schneidende Kappsägemaschinen This European Standard was approved by CEN on 8 November 2001 and includes Amendment 1 approved by CEN on 30 July 2009 and Amendment 2 approved by CEN on 27 July 2012.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2012 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 1870-5:2002+A2:2012: ESIST EN 1870-5:2003+A2:2012

Foreword . 40Introduction . 61Scope . 72Normative references . 73Terms and definitions . 113.1General . 113.2Terms . 113.3Definitions . 124List of significant hazards . 165Safety requirements and/or measures . 185.1####General$$$$ . 185.2Controls . 195.3Protection against mechanical hazards . 215.4Protection against non-mechanical hazards . 406Information for use . 456.1####General$$$$ . 456.2Marking . 456.3Instruction handbook . 46Annex A (normative)
Open frame machines stability test . 50Annex B (normative)
Dimensional tolerances of saw spindles . 51Annex C (normative)
Riving knife mounting strength test . 52Annex D (normative)
Riving knife lateral stability test . 53Annex E (normative)
####Saw blade guard stability test with lead-in or in-feed rollers$$$$ . 54E.1General . 54E.2Machines with saw blade guards with lead-in . 54E.3Machines with saw blade guards with in-feed rollers . 54Annex F (normative)
####Saw blade guard mounted on the riving knife or separately stability test$$$$ . 57F.1General . 57F.2Separately from riving knife mounted saw blade guards . 57F.3Riving knife mounted saw blade guards . 59Annex G (normative)
####Impact test method for guards$$$$ . 61G.1General . 61G.2Test method . 61G.3Results . 62G.4Assessment . 62G.5Test report . 62G.6Test equipment for impact test . 62Annex H (normative)
####Brake tests$$$$ . 64H.1Conditions for all tests . 64H.2Tests . 64SIST EN 1870-5:2003+A2:2012

Annex ZA (informative)
!!!!Relationship between this European Standard and the Essential Requirements of EU Directive 2006/42/EC"""" . 66Bibliography . 67 SIST EN 1870-5:2003+A2:2012

#EN ISO 12100:2010$ for a description of A, B and C standards). According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.
1 Scope !This document deals with all significant hazards, hazardous situations and events as listed in Clause 4 which are relevant to circular saw benches/up-cutting cross-cut sawing machines, hereinafter referred to as “machines”, designed to cut solid wood, chipboard, fibreboard, plywood and also these materials #if (where)$ they are covered with plastic edging and/or plastic/light alloy laminates #when they are used as intended and under the conditions foreseen by the manufacturer including reasonably foreseeable misuse$." This #document$ does not apply to:  !hand-held motor-operated electric tools or any adaptation permitting their use in a different mode, i.e. bench mounting;" !NOTE 1 Hand-held motor-operated electric tools and saw benches to form an integrated whole with a hand-held motor-operated electric tools are covered by EN 60745-1:2006 together with EN 60745-2-5:2007."  !machines set up on a bench or a table similar to a bench, which is intended to carry out work in a stationary position, capable of being lifted by one person by hand.". !NOTE 2 Transportable motor-operated electric tools are covered by the requirements of EN 61029-1:2000 together with EN 61029-2-1:2002." !deleted text" #This document is not applicable to machines which are manufactured before the date of issue of this EN.$
!NOTE 3"
Circular saw benches are dealt with in #prEN 1870-19:2011$. #NOTE 4 Machines covered by this document are listed under 1.1 of Annex IV of the Machinery Directive.$ 2 Normative references !The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies.". !deleted text" !#EN 614-1:2006+A1:2009$, Safety of machinery — Ergonomic design principles — Part 1: Terminology and general principles" !#EN 847-1:2005+A1:2007$, Tools for woodworking — Safety requirements — Part 1: Milling tools, circular saw blades" !#EN 894-1:1997+A1:2008$, Safety of machinery — Ergonomics requirements for the design of displays and control actuators — Part 1: General principles for human interactions with displays and control actuators #EN 894-2:1997+A1:2008$, Safety of machinery — Ergonomics requirements for the design of displays and control actuators — Part 2: Displays SIST EN 1870-5:2003+A2:2012

Part 1: Emission EN 50370-2:2003, Electromagnetic compatibility (EMC) — Product family standard for machine-tools —
Part 2: Immunity" !EN 60204-1:2006", Safety of machinery — Electrical equipment of machines — Part 1: General requirements !(IEC 60204-1:2005, modified)" !EN 60439-1:19991), Low-voltage switchgear and controlgear assemblies — Part 1: Type-tested and partially type-tested assemblies (IEC 60439-1:1999)"
EN 605292), Degree of protection provided by enclosures (IP code) (IEC 60529:1989) !EN 60825-1:2007, Safety of laser products — Part 1: Equipment classification and requirements (IEC 60825-1:2007) " !EN 60497-4-1:2001", Low voltage switchgear and control gear — Part 4: Contactors and motor starters - Section 1: Electromechanical contactors and motor starters !(IEC 60947-4-1:2000)"
!EN 60947-5-1:2004", Low voltage switchgear and control gear — Part 5: Control circuit devices and switching elements
Section 1: Electromechanical control circuit devices !(IEC 60947-5-1:2003)" #EN 61029-1:2009$, Safety of transportable motor operated electric tools — Part 1: General requirements !(IEC 61029-1:1990, modified)"
!EN 61310-1:2008, Safety of machinery — Indication, marking and actuation — Part 1: Requirements for visual, acoustic and tactile signals (IEC 61310-1:2007) "
1) #EN 60439-1:1999 is impacted by EN 60439-1:1999/A1:2004.$ 2) #EN 60529:1991 is impacted by EN 60529:1991/A1:2000.$ SIST EN 1870-5:2003+A2:2012

3) #EN ISO 3745:2009 is replaced by EN ISO 3745:2012.$ SIST EN 1870-5:2003+A2:2012

4) #HD 22.4 S4:2004 is superseded by EN 50525-2-21:2011, Electric cables — Low voltage energy cables of rated voltages up to and including 450/750 V (Uo/U) — Part 2-21: Cables for general applications — Flexible cables with crosslinked elastomeric insulation.$ SIST EN 1870-5:2003+A2:2012

3.2 Terms The main parts of the machine and their terminology are illustrated in Figure 1.
Key1 Under table extraction point
2 Controls
3 Elevation arm
4 Fixed guard beneath table
5 Table
6 Rotating part of table
7 Riving knife
8 Saw blade guard
9 Push stick
10 Saw blade guard exhaust outlet
11 Saw guard support
12 Moveable roller table locking clamp
13 Rip- and cross-cut fence
14 Moveable roller table support
15 Moveable roller table
16 Extension table Figure 1 — Terminology SIST EN 1870-5:2003+A2:2012

Figure 2 — Example of a machine in the ripping mode SIST EN 1870-5:2003+A2:2012

Figure 3 —Example of a machine in the cross-cutting mode with moved workpiece
Figure 4 — Example of a machine in the cross-cutting mode with stationary workpiece
####3.3.2$$$$ infeed table additional table at the infeed of the machine, used as: a) a support for the rip fence and to facilitate feeding the workpiece for ripping during use of the machine as a circular saw bench; SIST EN 1870-5:2003+A2:2012

Key 1 Outfeed table
2 Infeed table
3 Workpiece
4 Operating area for ripping and cross-cutting modes Figure 5 — Operating position ####3.3.4$$$$ !displaceable machine"
machine which is located on the floor, stationary during use and equipped with a device, normally wheels, which allows it to be moved between locations ####3.3.5$$$$ machine actuator power mechanism used to effect motion of the machine ####3.3.6$$$$ hand feed manual holding and/or manual guiding of the workpiece (or of a machine element incorporating a tool) #which$ includes the use of a hand operated carriage on which the workpiece is placed manually or clamped, and the use of a demountable power feed unit NOTE The words in brackets are not applicable to this machine. ####3.3.7$$$$ demountable power feed unit feed mechanism which is mounted on the machine so that it can be moved from the working position without the use of a spanner or similar additional device ####3.3.8$$$$ ejection unexpected movement of the workpiece or parts of it or part of the machine from the machine during processing SIST EN 1870-5:2003+A2:2012

a) — Example of push stick
#### $$$$ b) — Example of push block ####Key 1 push block handle$ Figure 6 — Examples of a push stick and push block SIST EN 1870-5:2003+A2:2012

statements, sales literature, leaflets or other documents where the manufacturer (or supplier) declares either the characteristics or the compliance of the material or product to a relevant standard ####3.3.14 performance level PL discrete level used to specify the ability of safety-related parts of control systems to perform a safety function under foreseeable conditions [SOURCE: EN ISO 13849-1:2008, 3.1.23]$ 4 List of significant hazards !This clause contains all significant hazards, hazardous situations and events (see #EN ISO 12100:2010$) #deleted text$, identified by risk assessment as significant for the machines as defined in the scope and which require action to eliminate or reduce the risk. This document deals with these significant hazards by defining safety requirements and/or measures or by reference to relevant standards. #These hazards are listed in Table 1:$ ####Table 1 — List of significant hazards (1 of 3)
No Hazards, hazardous situations and hazardous events EN ISO 12100:2010
Relevant sub-clause of this document
1 Mechanical hazards related to: - machine parts or workpieces:
a) shape;
6.2.2.1, 6.2.2.2, 6.3 5.3.3, 5.3.5, 5.3.6, 5.3.7, 5.3.8
b) relative location; 5.2.2, 5.3.5, 5.3.6, 5.3.7
c) mass and stability (potential energy of elements which may move under the effect of gravity) 5.3.6
d) mass and velocity (kinetic energy of elements in controlled or uncontrolled motion); 5.3.6
e) mechanical strength. 5.3.2, 5.3.3, 5.3.5, 5.3.6
- accumulation of energy inside the machinery:
g) liquids and gases under pressure; 6.2.10, 6.3.5.4 5.4.7, 5.4.8 SIST EN 1870-5:2003+A2:2012

No Hazards, hazardous situations and hazardous events EN ISO 12100:2010
Relevant sub-clause of this document 1.1 Crushing hazard
6.2.10 5.3.7, 5.3.8 1.2 Shearing hazard 5.3.7, 5.3.8 1.3 Cutting or severing hazard 5.3.2, 5.3.3, 5.3.4, 5.3.7 1.4 Entanglement hazard 5.3.7 1.5 Drawing-in or trapping hazard 5.3.7 1.9 High pressure fluid injection or ejection hazard 5.3.7 2 Electrical hazards due to: 2.1 Contact of persons with live parts (direct contact) 6.2.9, 6.3.5.4 5.4.4, 5.4.13, 5.4.14 2.2 Contact of persons with parts which have become live under faulty conditions (indirect contact) 6.2.9 5.4.4, 5.4.16, 5.4.17 4 Hazards generated by noise, resulting in: 4.1 Hearing loss (deafness), other physiological disorders (loss of balance, loss of awareness) 6.2.2.2, 6.3 5.4.2 4.2 Interference with speech communication, acoustic signals. 5.4.2 6 Hazards generated by radiation 6.5 Lasers 6.3.4.5 5.4.11 7 Hazards generated by materials and substances (and their constituent elements) processed or used by the machinery 7.1 Hazards from contact with or inhalation of harmful fluids and dusts 6.2.3b, 6.2.4
5.4.3 7.2 Fire hazard 6.2.4 5.4.1, 5.4.3, 6.3 8 Hazards generated by neglecting ergonomic principles in machinery design related to: 8.1 Unhealthy postures or excessive effort 6.2.7, 6.2.8.2, 6.2.11.12, 6.3.5.5, 6.3.5.6
5.2.2 8.2 Hand-arm or foot-leg anatomy 6.2.8.3
5.2.2 8.4 Local lighting 6.2.8.6 6.3 8.6 Human error, human behaviour 6.2.8, 6.2.11.8, 6.2.11.10, 6.3.5.2, 6.4 6.3 8.7 Design, location or identification of manual controls 6.2.8.7, 6.2.11.8 5.2.2 8.8 Design or location of visual display units 6.2.8.8, 6.4.2 5.2.2 9 Combination of hazards 6.3.2.1 5.2.5 SIST EN 1870-5:2003+A2:2012

No Hazards, hazardous situations and hazardous events EN ISO 12100:2010
Relevant sub-clause of this document 10 Unexpected start up, unexpected overrun/overspeed (or any similar malfunction) from: 10.1 Failure/disorder of the control system 6.2.11, 6.3.5.4
5.2.1 10.2 Restoration of energy supply after an interruption 6.2.11.4
5.2.6, 5.2.5, 5.4.7 10.3 External influences on electrical equipment 6.2.11.11 5.2.1, 5.4.4, 5.4.10 10.6 Errors made by the operator (due to mismatch of machinery with human characteristics and abilities, see 8.6) 6.2.8, 6.2.11.8, 6.2.11.10, 6.3.5.2, 6
5.2.1, 5.4.5, 6.3 11 Impossibility of stopping the machine in the best possible conditions 6.2.11.1, 6.2.11.3, 6.3.5.2 5.2.2, 5.2.4 13 Failure of the power supply 6.2.11.1, 6.2.11.4
5.2.5 14 Failure of the control circuit 6.2.11, 6.3.5.4
5.2.1 15 Errors of fitting 6.2.7, 6.4.5
5.3.3, 5.4.12 16 Break-up during operation 6.2.3
5.3.2 17 Falling or ejected objects or fluids 6.2.3, 6.2.10
5.3.2, 5.3.3, 5.3.5, 5.3.6, 5.3.8 18 Loss of stability / overturning of machinery 6.3.2.6
5.3.1 $
5 Safety requirements and/or measures 5.1 ####General$$$$ #The machine shall comply with the safety requirements and/or protective measures of Clause 5. In addition, the machine should be designed in accordance with the requirements of the principles of
EN ISO 12100:2010 for hazards relevant but not significant, which are not dealt with by this document (e.g. sharp edges of the machine frame). For guidance in connection with risk reduction by design, see EN ISO 12100:2010, 6.2, and for safeguarding measures, EN ISO 12100:2010, 6.3.$ SIST EN 1870-5:2003+A2:2012

Key1 Area X Figure 7 —Position of controls Verification: By checking the relevant drawings, measurement and inspection of the machine. 5.2.3 Starting #The requirements of$ 9.2.5.2 of !EN 60204-1:2006" #apply$ and in addition: For the purposes of this #document$ "all of the safeguards in place and functional" is achieved by the interlocking arrangements described in #5.3.7$ and "operation" means rotation of the saw spindle.
The exceptions described in 9.2.5.2 of !EN 60204-1:2006" are not relevant. #The safety related part of the control systems (also see 5.2.1) for start and restart of the machine and for a demountable power feed unit (if fitted) shall at least be PL=c in accordance with the requirements of EN ISO 13849-1:2008.$ Verification: By checking the relevant drawings and/or circuit diagrams, inspection and relevant functional testing of the machine. 5.2.4 Normal stopping Machines shall be fitted with a stop control which, when actuated shall disconnect power from all the machine actuators and actuate the brake (if provided). #For normal stopping of PDS(SR) (power drive system, safety related) see 4.2.2.2 "safe torque off (STO)” and 4.2.2.3 “safe stop 1 (SS1)” of EN 61800-5-2:2007.$ If the machine is fitted with a #spring operated$ mechanical brake this stop control shall be of a category 0 in accordance with the requirements 9.2.2 of !EN 60204-1:2006". If the machine is fitted with #any other type of brake e.g.$ an electrical brake this stop control shall be of category 1 in accordance with the requirements 9.2.2 of !EN 60204-1:2006". When initiated the stopping sequence shall be: SIST EN 1870-5:2003+A2:2012

#deleted text$ Verification: By checking the relevant drawings, inspection and relevant functional testing of the machine. 5.3.2 Risk of break-up during operation The guards for the saw blade shall be manufactured from: a) steel having an ultimate tensile strength of at least 350 N mm-2 and a wall thickness of at least 1,5 mm; b) light alloy with characteristics in accordance with Table 2; SIST EN 1870-5:2003+A2:2012

Ultimate tensile strength N mm-2 Minimum thickness mm 180
c) #polycarbonate with a wall thickness of at least 3 mm or other plastic material passing the test given in Annex G.$ #The saw blade guard below the table shall be manufactured from one or a combination of the materials required in a), b) or c) or from cast iron with an ultimate tensile strength of at least 200 N mm-2 and a wall thickness of at least 3 mm.$
Verification: By checking the relevant drawings, measurement !and" inspection on the machine !deleted text" #and for plastic materials with characteristics other than those of polycarbonate given in c) above by performing the test in Annex G$. !NOTE For the ultimate tensile strength a confirmation from the manufacturer of the material can be useful." 5.3.3 Tool holder and tool design 5.3.3.1 General It shall not be possible to mount a saw blade in the machine of a greater diameter than the saw blade for which the machine is designed. Saw spindles shall be manufactured in accordance with the tolerances given in Annex B. Verification: By checking the relevant drawings, inspection, measurement and relevant functional testing of the machine. 5.3.3.2 Spindle locking When it is necessary to hold the spindle stationary for tool changing, a spindle holding device shall be provided. This may be e.g. a double spanner arrangement, or an integral locking bar inserted through the spindle. This bar shall have a minimum diameter of 8 mm and be made from steel with an ultimate tensile strength of at least 350 N mm-2. Locking bars shall prevent the spindle from rotating if the spindle drive motor is inadvertently switched on. Verification: By checking the relevant drawings, inspection measurement !deleted text" and relevant functional testing of the machine. Alternatively on machines with locking bars, by the following test: After starting the spindle drive motor with the locking bar in place the spindle shall remain stationary. !NOTE For the ultimate tensile strength a confirmation from the manufacturer of the material can be useful." 5.3.3.3 Saw blade fixing device Saw flanges (or in the case of flush mounted saw blades - a flange) shall be provided. For saw blades with a diameter ≤ 450 mm the diameter of both flanges (or flange for flush mounting) shall be at least D/4 (where D = the maximum diameter of the saw blade for which the machine is designed). For saw blades with a diameter > 450 mm, the diameter of the flanges (or flange for flush mounting) shall be at least D/6, but not less than 115 mm. SIST EN 1870-5:2003+A2:2012

Figure 8 — Saw flange detail Verification: By checking the relevant drawings, measurement and inspection of the machine. 5.3.4 Braking #deleted text$ #An automatic brake shall be provided for the saw spindle with an un-braked run-down time exceeding 10 s.$ The braked run-down time shall be less than 10 s. #A PL of at least c for the braking function shall be achieved. Where the machine is designed with a spring operated mechanical brake or any other type of brake not using electronic components the last paragraph of 9.3.4 of EN 60204-1:2006 does not apply and the minimum life time of the friction coating and method of replacement shall be given (see 6.3).$ Electrical braking shall not be by reverse current. #As an exception where the machine is designed with an electrical brake which contains electronic components the control system for braking shall fulfil at least the requirements of PL=b and be designed in category 2 of EN ISO 13849-1:2008 with the exception that the test rate requirement in 4.5.4 of EN ISO 13849-1:2008 is not applicable. The safety related part of the control systems for braking shall be SIST EN 1870-5:2003+A2:2012

The test works a) independently from the basic control system for braking or an internal watch dog function shall be provided, b) independently from the intention of the operator, c) at least during starting/stopping the spindle. A negative test shall be indicated. Where the test result is negative more than three times in sequence it shall not be possible to operate the machine. The diagnostic coverage (DCavg) shall be ≥ 60 %.
See Annex E of EN ISO 13849-1:2008 for DC estimation. As an exception, a simple electronic brake (using simple electronic parts like rectifiers, transistors, triacs, diodes, resistors, thyristors) may be PL=b and designed in category 1 in accordance with the requirements of EN ISO 13849-1:2008 if the "mean time to a dangerous failure" (MTTFd) according to EN ISO 13849-1:2008, Table 5 reaches a value of "high" (at least 30 year
...
