EN ISO 21013-3:2026

• Abstract:

  This document specifies calculation methods for determining the required mass flow to be relieved for each specified conditions described in Table 1.; Recommendations for pressure relief devices for cryostats are given in Annex A.

• Status: Published
• Publication Date: 20-Oct-2026
• ICS: 23.020.40 - Cryogenic vessels
• Technical Committee: CEN/TC 268 - Cryogenic vessels
• Drafting Committee: CEN/TC 268 - Cryogenic vessels
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 21-Oct-2026
• Completion Date: 21-Oct-2026
• Directive: 2008/68/EC - Directive 2008/68/EC of the European Parliament and of the council of 24 September 2008 on the inland transport of the dangerous goods
• Directive:

  ---

  2014/68/EU - Directive 2014/68/EU of the European Parliament and of the Council of 15 May 2014 on the harmonisation of the laws of the Member States relating to the making available on the market of pressure equipment
• Mandate: M/071 - Mandate to CEN for standardization in the field of Pressure equipment
• Mandate: M/601 - COMMISSION IMPLEMENTING DECISION of 1.3.2024 on a standardisation request to the European Committee for Standardization and the European Committee for Electrotechnical Standardization as regards pressure equipment and assemblies in support of Directive 2014/68/EU of the European Parliament and of the Council
• Mandate: M/TDG - Standards for referencing in the RID-ADR
• Ref Project: SIST EN ISO 21013-3:2026 - Cryogenic vessels - Pressure-relief accessories for cryogenic service - Part 3: Sizing and capacity determination (ISO 21013-3:2026)

• Replaces: EN ISO 21013-3:2016 - Cryogenic vessels - Pressure-relief accessories for cryogenic service - Part 3: Sizing and capacity determination (ISO 21013-3:2016)
• Effective Date: 18-Jan-2023
• Referred By: EN 13648-2:2002 - Cryogenic vessels - Safety devices for protection against excessive pressure - Part 2: Bursting disc safety devices for cryogenic service
• Effective Date: 28-Oct-2026
• Referred By: EN 13458-2:2002 - Cryogenic vessels - Static vacuum insulated vessels - Part 2: Design, fabrication, inspection and testing
• Effective Date: 28-Oct-2026
• Referred By: EN 14398-1:2003 - Cryogenic vessels - Large transportable non-vacuum insulated vessels - Part 1: Fundamental requirements
• Effective Date: 28-Oct-2026
• Referred By: EN 14398-2:2003+A2:2008 - Cryogenic vessels - Large transportable non-vacuum insulated vessels - Part 2: Design, fabrication, inspection and testing
• Effective Date: 28-Oct-2026
• Consolidated By: ISO 21013-3:2026 - Cryogenic vessels — Pressure-relief accessories for cryogenic service — Part 3: Sizing and capacity determination
• Effective Date: 12-Feb-2026

EN ISO 21013-3:2026 is a CEN standard for cryogenic vessels that covers pressure-relief accessories for cryogenic service. It specifies calculation methods for the mass flow that must be relieved under defined conditions, so designers can size pressure relief valves and bursting discs and check the effect of piping, heat leak, loss of vacuum, and fire cases.

What does EN ISO 21013-3:2026 specify?

EN ISO 21013-3:2026 specifies separate calculation methods for determining the required mass flow to be relieved for the conditions listed in the standard’s condition table. It also gives recommendations for pressure relief devices for cryostats in Annex A.

The document is organized into:

• Clause 1 Scope
• Clause 2 Normative references
• Clause 3 Symbols
• Clause 4 Heat transfer calculations
• Clause 5 Mass flow to be relieved
• Clause 6 Piping for pressure relief devices
• Clause 7 Sizing of pressure relief devices
• Annex A on cryostats
• Annex ZA on the relationship with the Pressure Equipment Directive
• Bibliography

Annex	What it covers
Annex A	Cryostats and design recommendations for their pressure relief devices
Annex ZA	Relationship between this European Standard and Directive 2014/68/EU

In practice, the standard is about turning operating and upset conditions into a required discharge capacity, then using that requirement to size the relief system.

What are the key requirements of EN ISO 21013-3:2026?

EN ISO 21013-3:2026 builds the sizing method in three steps: estimate heat input, convert that heat input into required mass flow, then verify that the complete relief path can pass that flow. The clause structure matters because it separates vessel heat loads, piping effects, and the final device sizing.

Heat transfer cases in Clause 4

Clause 4 covers the heat transferred from the warm side to the cold side of the vessel in the main service cases. EN ISO 21013-3:2026 distinguishes normal operation, pressure build-up device operation, loss of vacuum, fire exposure, and air or nitrogen condensation.

In practice, this means you do not size a relief device from one generic heat load. You choose the case that matches the vessel construction and upset condition, because different insulation states and different ambient conditions can change the required relieving capacity.

Fire and pressure build-up conditions

Clause 4 treats fire as a separate case, using an external fire temperature of 922 K, and it also requires pressure build-up device conditions to be considered. The text notes that fire may not be the worst case, so fire and PBU conditions both have to be checked.

In practice, a vessel that is safe for normal service can still need a larger relief system for fire exposure or for a pressure build-up circuit. If the PBU arrangement changes later in the field, the sizing needs to be reviewed again.

Loss of vacuum and low-temperature condensation

Clause 4 also covers loss of vacuum and, for fluids with a saturation temperature below 75 K at 1 bar, air or nitrogen condensation. The document applies this to multi-layer insulated containers and gives guidance for handling other insulation types.

In practice, this matters for very cold fluids such as liquid hydrogen. The relief load may be governed by condensation and insulation performance rather than by the vessel contents alone.

Converting heat load to mass flow in Clause 5

Clause 5 turns total heat transfer into the mass flow to be relieved. For pressures below the critical pressure, the method is based on heat input or on normal evaporation rate. For pressures at or above the critical pressure, it uses the relieving temperature approach with thermophysical properties.

In practice, the relieving pressure determines which calculation route to use. That choice affects the discharge rate that must be met by the relief device.

Piping effects in Clause 6

Clause 6 requires pressure drop, back pressure, and heat transfer in the piping to be taken into account. The text also says that if piping between the outer jacket and the safety relief device is longer than 0.6 m, heat transfer to the flowing fluid must be included.

In practice, the relief valve or bursting disc cannot be sized in isolation. The upstream and downstream piping can reduce capacity, increase back pressure, and change the fluid temperature before discharge.

Final sizing in Clause 7

Clause 7 gives separate sizing methods for pressure relief valves and bursting discs. It distinguishes critical and subcritical gas flow, requires the selected device capacity to meet or exceed the required mass flow, and explains how to combine multiple devices when they discharge together.

In practice, the selected orifice or net flow area must match the actual system conditions, including inlet pressure drops and outlet back pressure. For bursting discs, the flow resistance of the complete pipe network is part of the sizing check.

Cryostat-specific guidance in Annex A

Annex A adds cryostat-specific recommendations. It says to include heat generated by upset process conditions, and it gives design advice on gas space volume, set pressure, outlet pressure, and certified flow area after rupture for bursting discs.

In practice, cryostats can need extra attention because process upsets can add heat load and create mixed flow in the relief piping.

What terms does EN ISO 21013-3:2026 define?

• NER - Normal evaporation rate, the fraction of vessel mass that evaporates per day and can be used as an alternate basis for heat leak.
• PBU - Pressure build-up, the condition where a pressure build-up device adds heat input to the system.
• Relieving pressure, P - The absolute inner-vessel pressure used to calculate required relief capacity.
• Critical flow - A gas or vapour flow regime where lowering outlet pressure no longer increases discharge capacity.
• Subcritical flow - A gas flow regime where outlet pressure still influences the discharge capacity.
• Built-up back pressure - The pressure rise at the relief outlet caused by flow through the downstream piping and fittings.
• Coefficient of discharge, Kd - The discharge coefficient used in valve capacity calculations, with a derated form used in the sizing equations.

Who uses EN ISO 21013-3:2026?

EN ISO 21013-3:2026 is used by engineers who design cryogenic vessels, pressure-relief systems, and the piping connected to them. It is also used by manufacturers and suppliers of pressure relief valves and bursting discs when they need to rate device capacity for a specific cryogenic application.

Quality managers, buyers, and certifiers use it to check that a proposed relief system has been sized against the correct vessel condition and that piping effects have been considered. It is particularly relevant in cryogenic industries such as liquid hydrogen, helium, nitrogen, oxygen, and other low-temperature storage and transport applications. Cryostat designers use Annex A when the vessel protects low-temperature test or operating equipment such as superconducting devices.

What changed in EN ISO 21013-3:2026 from the previous edition?

EN ISO 21013-3:2026 is the third edition and it cancels and replaces ISO 21013-3:2016. The foreword says the document was technically revised.

The changes stated in the document are:

• precision added on the total outer surface area of the pipe network containing flow of fluid
• inclusion of the coefficient of discharge symbol
• precision added on the overall convective heat transfer coefficient of the ambient air vaporizer
• additional information added on the fire case and PBU conditions
• correction of the molar mass in kg/kmol and modification of formulas 32 and 43
• supplementary information added on cryostats

Which standards are used with EN ISO 21013-3:2026?

The document lists no normative references. Its bibliography names these related pressure-relief standards:

• ISO 4126-1 - safety valves for protection against excessive pressure
• ISO 4126-6 - application, selection, and installation of bursting disc safety devices
• ISO 4126-10 - sizing of safety valves and bursting discs for gas/liquid two-phase flow

These references help readers place EN ISO 21013-3:2026 in the wider pressure-relief family, especially when comparing valve sizing, disc selection, and two-phase flow practice.

What does the EN ISO 21013-3:2026 document contain?

EN ISO 21013-3:2026 contains the calculation framework, symbols, thermophysical-property tables, and worked methods needed to size relief devices for cryogenic vessels. It includes tables for fluid properties, pipe friction and transition resistance, and flow coefficients used in the sizing equations.

The document also contains a figure for air or nitrogen condensation, examples for relief valve sizing and bursting disc sizing, and detailed pipe-network analysis steps. Annex A adds cryostat-specific design guidance, while Annex ZA maps the European standard to Directive 2014/68/EU for pressure equipment.

SLOVENSKI STANDARD
01-december-2026
Nadomešča:
SIST EN ISO 21013-3:2016
Kriogene posode - Oprema za razbremenitev tlaka za kriogeno območje - 3. del:
Določanje velikosti in pretoka (ISO 21013-3:2026)
Cryogenic vessels - Pressure-relief accessories for cryogenic service - Part 3: Sizing and
capacity determination (ISO 21013-3:2026)
Kryo-Behälter - Druckentlastungseinrichtungen für den Kryo-Betrieb - Teil 3:
Bestimmung von Größe und Durchfluss (ISO 21013-3:2026)
Récipients cryogéniques - Dispositifs de sécurité pour le service cryogénique - Partie 3:
Détermination de la taille et du volume (ISO 21013-3:2026)
Ta slovenski standard je istoveten z: EN ISO 21013-3:2026
ICS:
13.240 Varstvo pred previsokim Protection against excessive
tlakom pressure
23.020.40 Proti mrazu odporne posode Cryogenic vessels
(kriogenske posode)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EN ISO 21013-3
EUROPEAN STANDARD
NORME EUROPÉENNE
October 2026
EUROPÄISCHE NORM
ICS 23.020.40 Supersedes EN ISO 21013-3:2016
English Version
Cryogenic vessels - Pressure-relief accessories for
cryogenic service - Part 3: Sizing and capacity
determination (ISO 21013-3:2026)
Récipients cryogéniques - Dispositifs de sécurité pour Kryo-Behälter - Druckentlastungseinrichtungen für
le service cryogénique - Partie 3: Détermination de la den Kryo-Betrieb - Teil 3: Bestimmung von Größe und
taille et du volume (ISO 21013-3:2026) Durchfluss (ISO 21013-3:2026)
This European Standard was approved by CEN on 26 September 2026.

CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this
European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references
concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN
member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by
translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management
Centre has the same status as the official versions.

CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Türkiye and
United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION

EUROPÄISCHES KOMITEE FÜR NORMUNG

CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2026 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN ISO 21013-3:2026 E
worldwide for CEN national Members.

Contents Page
