EN 10223-7:2002

Steel wire and wire products for fences - Part 7: Steel wire welded panels - For fencing

This Part of this European Standard specifies requirements for steel wire welded mesh panels for fencing. The panels are used for fencing parks, schools, sport stadia, public buildings, factories, airports, military sites, etc. This standard specifies the general characteristics of welded mesh supplied as panels and recommended coatings, properties and tolerances.

Stahldraht und Drahterzeugnisse für Zaüne - Teil 7 : Geschweisste Paneele für Zaüne

Dieser Teil dieser Europäischen Norm legt die Anforderungen für geschweißte Paneele für Zäune fest. Die Paneele finden Einsatz bei der Umzäumung von Parkanlagen, Schulen, Sportstadien, öffentlichen Gebäuden, Fabriken, Flughäfen, militärischen Einrichtungen usw.
Diese Europäische Norm legt die allgemeinen Eigenschaften von geschweißten Gittern, die als Paneele geliefert werden, sowie die empfohlenen Beschichtungen, Eigenschaften und Toleranzen fest. Sie gilt für Paneele aus Rund- oder Formdrähten, die nicht dicker als 10 mm sind.
Die Paneele bestehen aus Drähten mit rundem, rechteckigem oder dreieckigem Querschnitt, doppelten Spanndrähten und dürfen Querdrähte mit dreieckigem Querschnitt haben.

Fils et produits tréfilés en acier pour clôtures - Partie 7 : Panneaux en acier soudés - Pour clôturage

La présente partie de cette Norme européenne spécifie les exigences relatives aux panneaux grillagés en acier soudés destinés au clôturage. Les panneaux sont utilisés pour clôturer des parcs, des écoles, des stades de sport, des bâtiments publics, des usines, des aéroports, des sites militaires, etc..
La présente norme spécifie les caractéristiques générales du grillage soudé livré en panneaux, ainsi que les revêtements, caractéristiques et tolérances recommandés. Elle ne couvre que les panneaux fabriqués à partir de fils ronds ou profilés de diamètre ou épaisseur inférieur ou égal à 10 mm.
Les panneaux ont des fils ronds, rectangulaires ou triangulaires, des fils doubles horizontaux et peuvent ou ne pas avoir des fils verticaux formés en V.

Jeklena žica in žični izdelki za ograje - 7. del: Iz jeklenih žic zvarjene ograjne plošče

General Information

• Status: Withdrawn
• Publication Date: 24-Sep-2002
• Withdrawal Date: 27-Nov-2012
• ICS: 77.140 - Iron and steel products
• ICS: 77.140.65 - Steel wire, wire ropes and link chains
• Technical Committee: ECISS/TC 106 - Wire rod and wires
• Drafting Committee: ECISS/TC 30 - Steel wires
• Current Stage: 9960 - Withdrawal effective - Withdrawal
• Start Date: 28-Nov-2012
• Completion Date: 28-Nov-2012
• Ref Project: SIST EN 10223-7:2003 - Steel wire and wire products for fences - Part 7: Steel wire welded panels - For fencing

Relations

• Replaced By: EN 10223-7:2012 - Steel wire and wire products for fencing and netting - Part 7: Steel wire welded panels for fencing
• Effective Date: 05-Dec-2012

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.SORãþHStahldraht und Drahterzeugnisse für Zaüne - Teil 7 : Geschweisste Paneele für ZaüneFils et produits tréfilés en acier pour clôtures - Partie 7 : Panneaux en acier soudés - Pour clôturageSteel wire and wire products for fences - Part 7: Steel wire welded panels - For fencing91.090Konstrukcije zunaj stavbExternal structures77.140.65Jeklene žice, jeklene vrvi in verigeSteel wire, wire ropes and link chainsICS:Ta slovenski standard je istoveten z:EN 10223-7:2002SIST EN 10223-7:2003en01-april-2003SIST EN 10223-7:2003SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 10223-7September 2002ICS 77.140.65English versionSteel wire and wire products for fences - Part 7: Steel wirewelded panels - For fencingFils et produits tréfilés en acier pour clôtures - Partie 7 :Panneaux en acier soudés - Pour clôturageStahldraht und Drahterzeugnisse für Zaüne - Teil 7 :Geschweisste Paneele für ZaüneThis European Standard was approved by CEN on 1 August 2002.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Management Centre has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece,Iceland, Ireland, Italy, Luxembourg, Malta, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2002 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 10223-7:2002 ESIST EN 10223-7:2003

Weld shear strength test method (welded mesh).11Bibliography.13SIST EN 10223-7:2003

It is the product of E.I where E isthe modulus of elasticity and I is the moment of inertia4
Information to be obtained from the purchaserThe following information as appropriate shall be obtained from the purchaser at the time of enquiry and/or order:a) the number of this European Standard;b) the quantity and packaging requirements;c) the main characteristic dimensions and length, width and diameters of the wires;d) mesh sizes for a simple and repetitive design;e) the grade of zinc or zinc alloy coating and whether applied before or after welding;f) whether organic coating is required, and if so, the type and colour;g) the tensile strengths of the wires.5 DesignationThe panel shall be designated by:a) the number of this European Standard;b) its length;c) its width;d) for a simple and repetitive design: the mesh and wire dimensions;for a more complex design: a drawing with wire dimensions, meshes and other ornamental and additionalwires;e) the type and grade of zinc alloy coating and whether applied before or after fabrication;f) if subsequently organically coated: the type and colour of the coating.6 Manufacture6.1 Base metalThe base metal of the welded mesh panel shall be low carbon steel.6.2 FabricationPanels shall be produced by electrical resistance welded zinc or zinc alloy coated wires or subsequently zinc orzinc alloy coated after fabrication in accordance with EN ISO 1461. No bare patches shall be permitted. Whererequested by the purchaser (see 4f), the panel shall be subsequently organically coated in accordance withEN 10245-1 and the other relevant part of EN 10245 depending on the purchaser's specification. The organiccoating shall be free from blisters, craters, pin holes or scratches on the base metal, visible from a distance ofabout 0,5 m. The substrate shall not be visible at any edge.SIST EN 10223-7:2003
...
