Safety of machinery - Safety requirements for the design and construction of printing and paper converting machines - Part 4: Bookbinding, paper converting and finishing machines

This document applies to
-   bookbinding machines:
-   stitching, riveting, eyeletting and attaching machines;
-   gang stitchers;
-   gathering machines;
-   perfect binders;
-   paper drills;
-   book signature presses;
-   book presses;
-   sheet folding machines;
-   book production lines for the production of books with hard covers;
-   back rounding and pressing machines;
-   backlining and head banding machines;
-   casing-in machines;
-   book cover crease forming machines.
-   paper converting machines:
-   machines for the production of envelopes;
-   machines for the production of sanitary items;
-   inserting machines;
-   counter-stackers;
-   paper embossing machines.
-   paper finishing machines:
-   coaters;
-   laminators.
This document shall be used together with EN 1010-1:2004+A1. Both parts together identify all significant hazards relevant to bookbinding, paper converting and paper finishing machines when they are used as intended and under the conditions foreseen by the manufacturer (see clause 4). The specific requirements in EN 1010 4 take precedence over respective requirements in EN 1010-1:2004+A1.
This document does not deal with risks generated by noise emitted from the machines. These issues are covered basically in EN 1010-1:2004+A1. However, for machines like sheet folding machines and machines for the production of envelopes and sanitary items, some specific proposals for noise reduction measures are given.
This document is not applicable to bookbinding, paper converting and finishing machines manufactured before the date of publication of this document by CEN.

Sicherheit von Maschinen - Sicherheitsanforderungen an Konstruktion und Bau von Druck- und Papierverarbeitungsmaschinen - Teil 4: Buchbinderei-, Papierverarbeitungs- und Papierveredelungsmaschinen

Dieses Dokument gilt für:
-   Buchbindereimaschinen:
-   Heft-, Niet-, Öse- und Ansetzmaschinen;
-   Sammelhefter;
-   Zusammentragmaschinen;
-   Klebebinder;
-   Papierbohrmaschinen;
-   Bündelpressen;
-   Bücherpressen;
-   Bogenfalzmaschinen;
-   Buchfertigungsstraßen;
-   Buchrückenrunde- und Abpressmaschinen;
-   Buchblockhinterklebe- und Kapitalmaschinen;
-   Bucheinhängemaschinen;
-   Falzeinbrennmaschinen.
-   Papierverarbeitungsmaschinen:
-   Briefumschlag-, Versandtaschenmaschinen;
-   Hygieneartikelmaschinen;
-   Einsteckmaschinen;
-   Kreuzleger;
-   Papierprägemaschinen.
-   Papierveredelungsmaschinen:
-   Beschichtungsmaschinen;
-   Kaschiermaschinen.
Dieses Dokument ist gemeinsam mit !EN 1010-1:2004+A1" anzuwenden. Beide Teile zusammen behandeln alle signifikanten Gefährdungen, die auf die Buchbinderei-, Papierverarbeitungs- und Papier-veredelungsmaschinen zutreffen, wenn sie bestimmungsgemäß und entsprechend den vorhersehbaren Bedingungen des Herstellers verwendet werden (siehe Abschnitt 4). Die spezifischen Anforderungen in EN 1010-4 haben Vorrang vor entspre¬chenden Anforderungen in der !EN 1010-1:2004+A1".
Dieses Dokument befasst sich nicht mit Risiken, die durch Lärm entstehen, der von den Maschinen erzeugt wird. Dies ist grundlegend in !EN 1010-1:2004+A1" behandelt. Jedoch gibt es für Falzmaschinen, Briefumschlag- und Versandtaschenmaschinen und Hygieneartikelmaschinen Anforderungen bezüglich Lärmminderung.
Dieses Dokument gilt nicht für Buchbinderei-, Papierverarbeitungs- und Papierveredelungsmaschinen, die hergestellt wurden, bevor CEN dieses Dokument veröffentlichte.

Sécurité des machines - Prescriptions de sécurité pour la conception et la construction de machines d'impression et de transformation du papier - Partie 4 : Machines à relier les livres, machines de transformation et de finition du papier

Le présent document s'applique aux :
- machines à relier les livres :
-   brocheuses à fil métallique, riveteuses, machines à poser les œillets et machines à agrafer ;
-   encarteuses-piqueuses ;
-   assembleuses ;
-   machines à relier par collage ;
-   perceuses/foreuses ;
-   presseurs de cahiers ;
-   presses à livres ;
-   plieuses de feuilles ;
-   lignes de production de livres à couverture rigide ;
-   machines à arrondir les dos et à presser ;
-   machines à coller la mousseline et le tranchefile ;
-   machines à emboîter dans les couvertures ;
-   machines à repincer ;
- machines de transformation du papier :
-   machines à fabriquer les enveloppes et les pochettes ;
-   machines à fabriquer les articles sanitaires ;
-   machines à insérer les encarts ;
-   machines d'empilage ;
-   gaufreuses ;
- machines de finition du papier :
-   machines d'enduction ;
-   machines de contre-collage.
Le présent document doit être appliqué conjointement avec l’EN 1010-1:2004+A1. Ces deux normes traitent tous les phénomènes dangereux significatifs engendrés par les machines d'impression et de transformation du papier lorsqu'elles sont utilisées normalement et dans les conditions prévues par le constructeur (voir article 4). Les spécifications de la partie 4 de l'EN 1010:2001 ont la priorité sur les spécifications de la partie 1.
Le présent document ne traite pas les risques engendrés par le bruit émis par les machines à l'exception des plieuses de feuilles, des machines à fabriquer les enveloppes et les pochettes et des machines à fabriquer les articles sanitaires. Il existe pour ces machines des exigences relatives aux mesures de réduction du bruit. Ceci est traité fondamentalement dans l’EN 1010-1:2004+A1.
Ce document n’est pas applicable aux machines à relier les livres et machines de transformation et de finition du papier qui ont été fabriquées avant la date de publication de ce document par le CEN.

Varnost strojev - Varnostne zahteve za načrtovanje in konstrukcijo tiskarskih strojev in strojev za obdelavo papirja - 4. del: Stroji za vezavo knjig, obdelavo in izdelavo papirja

General Information

Status
Published
Publication Date
13-Oct-2009
Current Stage
9093 - Decision to confirm - Review Enquiry
Due Date
02-Dec-2017
Completion Date
02-Mar-2018

RELATIONS

Buy Standard

Standard
EN 1010-4:2004+A1:2009
English language
70 pages
sale 10% off
Preview
sale 10% off
Preview

e-Library read for
1 day

Standards Content (sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Sicherheit von Maschinen - Sicherheitsanforderungen an Konstruktion und Bau von Druck- und Papierverarbeitungsmaschinen - Teil 4: Buchbinderei, Papierverarbeitungs- und PapierveredelungsmaschinenSécurité des machines - Exigences de sécurité pour la conception et la construction de machines d'impressions et de transformation du papier - Partie 4: Machines à relier les livres, machines de transformation et de finition du papierSafety of machinery - Safety requirements for the design and construction of printing and paper converting machines - Part 4: Bookbinding, paper converting and finishing machines85.100Oprema za papirno industrijoEquipment for the paper industry37.100.10Reprodukcijska opremaReproduction equipmentICS:Ta slovenski standard je istoveten z:EN 1010-4:2004+A1:2009SIST EN 1010-4:2004+A1:2009en01-december-2009SIST EN 1010-4:2004+A1:2009SLOVENSKI

STANDARD
SIST EN 1010-4:2004+A1:2009
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 1010-4:2004+A1
October 2009 ICS 37.100.10; 85.100 Supersedes En 1010-4:2004English Version

Safety of machinery - Safety requirements for the design and construction of printing and paper converting machines - Part 4: Bookbinding, paper converting and finishing machines

Sécurité des machines - Exigences de sécurité pour la conception et la construction de machines d'impressions et de transformation du papier - Partie 4: Machines à relier les livres, machines de transformation et de finition du papier Sicherheit von Maschinen - Sicherheitsanforderungen an Konstruktion und Bau von Druck- und Papierverarbeitungsmaschinen - Teil 4: Buchbinderei, Papierverarbeitungs- und Papierveredelungsmaschinen This European Standard was approved by CEN on 21 November 2003 and includes Amendment 1 approved by CEN on 15 September 2009.

CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.

This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.

CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.

EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,

B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 1010-4:2004+A1:2009: ESIST EN 1010-4:2004+A1:2009

EN 1010-4:2004+A1:2009 (E) 2 Contents Page Foreword ..............................................................................................................................................................4Introduction .........................................................................................................................................................51Scope ......................................................................................................................................................52Normative references ............................................................................................................................63Terms and definitions ...........................................................................................................................74List of significant hazards ................................................................................................................. 105Safety requirements and/or measures ............................................................................................. 175.1General ................................................................................................................................................. 175.2Bookbinding machines ...................................................................................................................... 175.2.1Stitching, riveting, eyeletting and attaching machines (with manual feeding) ............................ 175.2.2Gang stitchers ..................................................................................................................................... 195.2.3Gathering machines ........................................................................................................................... 215.2.4Perfect binders (Figure 11) ................................................................................................................ 235.2.5Paper drills .......................................................................................................................................... 255.2.6Book signature presses ..................................................................................................................... 265.2.7Book presses ...................................................................................................................................... 265.2.8Sheet folding machines (Figure 16) .................................................................................................. 275.2.9Book production lines for the production of hard cover books .................................................... 285.2.10Back rounding and pressing machines............................................................................................ 305.2.11Backlining and head banding machines .......................................................................................... 315.2.12Casing-in machines ............................................................................................................................ 315.2.13Book cover crease forming machines (presses) ............................................................................. 325.3Paper converting machines ............................................................................................................... 335.3.1Machines for the production of envelopes ...................................................................................... 335.3.2Machines for the production of sanitary items ................................................................................ 405.3.3Inserting machines (Figure 28) .......................................................................................................... 455.3.4Counter-stackers ................................................................................................................................ 465.3.5Paper embossing machine ................................................................................................................ 465.4Finishing machines ............................................................................................................................ 485.4.1Coaters ................................................................................................................................................. 485.4.2Laminators ........................................................................................................................................... 526Verification of safety requirements and/or measures ..................................................................... 567Information for use ............................................................................................................................. 667.1Instruction handbook ......................................................................................................................... 667.1.1Stitching, riveting, eyeletting and attaching machines .................................................................. 667.1.2Perfect binders .................................................................................................................................... 667.1.3Machines for the production of envelopes ...................................................................................... 667.1.4Machines for the production of sanitary items ................................................................................ 677.1.5Paper embossing machines .............................................................................................................. 677.1.6Coaters ................................................................................................................................................. 677.1.7Hold-to-run speeds of above 10 m/min under two-hand control ................................................... 677.1.8High contact temperatures ................................................................................................................ 67Annex A (normative)

General requirements ................................................................................................ 68A.1Production lines .................................................................................................................................. 68A.2Start-up warning device ..................................................................................................................... 68A.3Limit values for interlocking guards ................................................................................................. 68SIST EN 1010-4:2004+A1:2009

EN 1010-4:2004+A1:2009 (E) 3 Annex ZA (informative)
