Air filters for general ventilation - Part 3: Determination of the gravimetric efficiency and the air flow resistance versus the mass of test dust captured (ISO 16890-3:2016)

ISO 16890-3:2016 specifies the test equipment and the test methods used for measuring the gravimetric efficiency and resistance to air flow of air filter for general ventilation.
It is intended for use in conjunction with ISO 16890‑1, ISO 16890‑2 and ISO 16890‑4.
The test method described in this part of ISO 16890 is applicable for air flow rates between 0,25 m3/s (900 m3/h, 530 ft3/min) and 1,5 m3/s (5 400 m3/h, 3 178 ft3/min), referring to a test rig with a nominal face area of 610 mm × 610 mm (24 in × 24 in).
ISO 16890 (all parts) refers to particulate air filter elements for general ventilation having an ePM1 efficiency less than or equal to 99 % and an ePM10 efficiency greater than 20 % when tested as per the procedures defined within ISO 16890 (all parts).
Air filter elements outside of this aerosol fraction are evaluated by other applicable test methods. See ISO 29463 (all parts).
Filter elements used in portable room-air cleaners are excluded from the scope of this part of ISO 16890.
The performance results obtained in accordance with ISO 16890 (all parts) cannot by themselves be quantitatively applied to predict performance in service with regard to efficiency and lifetime.

Luftfilter für die allgemeine Raumlufttechnik - Teil 3: Ermittlung des gravimetrischen Wirkungsgrades sowie des durchflusswiderstandes im Vergleich zu der aufgenommenen Masse von Prüfstaub (ISO 16890-3:2016)

Filtres à air de ventilation générale - Partie 3: Détermination de l'efficacité gravimétrique et de la résistance à l'écoulement de l'air par rapport à la quantité de poussière d'essai retenue (ISO 16890-3:2016)

ISO 16890-3:2016 spécifie l'équipement d'essai et les méthodes d'essai utilisés pour mesurer l'efficacité gravimétrique et la résistance à l'écoulement de l'air d'un filtre à air de ventilation générale.
Elle est destinée à être utilisée conjointement avec l'ISO 16890‑1, ISO 16890‑2 et ISO 16890‑4.
La méthode d'essai décrite dans la présente partie de l'ISO 16890 est applicable pour des débits d'air compris entre 0,25 m3/s (900 m3/h, 530 ft3/min) et 1,5 m3/s (5 400 m3/h, 3 178 ft3/min), en se référant à un banc d'essai ayant une surface frontale nominale de 610 mm × 610 mm (24 inch × 24 inch).
L'ISO 16890 (toutes les parties) concerne les éléments filtrants de ventilation générale ayant une efficacité ePM1 inférieure ou égale à 99 % et une efficacité ePM10 supérieure à 20 %, lorsqu'ils sont soumis à essai selon les modes opératoires définis dans l'ISO 16890 (toutes les parties).
En dehors de ces fractions d'aérosol, les éléments filtrants sont évalués par d'autres méthodes d'essai applicables. Voir l'ISO 29463 (toutes les parties).
Les éléments filtrants utilisés dans les épurateurs d'air ambiant portatifs sont exclus du domaine d'application de la présente partie de l'ISO 16890.
Les résultats de performance obtenus conformément à l'ISO 16890 (toutes les parties) ne peuvent pas être utilisés quantitativement pour prédire les performances en service, en ce qui concerne l'efficacité et la durée de vie.

Zračni filtri pri splošnem prezračevanju - 3. del: Ugotavljanje gravimetrijske učinkovitosti in odpornosti pretoka zraka v odvisnosti od mase zajetega preskusnega prahu (ISO 16890-3:2016)

Ta evropski standard se uporablja za zračne filtre delcev za splošno prezračevanje, katerih začetna učinkovitost je manj kot 99 % glede na vrednosti PM1, ki so določene v standardu ISO 16890-1 Zračni filtri pri splošnem prezračevanju - 1. del: Tehnične specifikacije, zahteve in sistem razvrščanja učinkovitosti na podlagi trdnih delcev (PM). Filtri, ki se uporabljajo pri prezračevanju nizkih stanovanjskih stavb ali premični čistilniki zraka v prostorih so izključeni s področja uporabe tega standarda. Ta mednarodni standard opisuje postopek za določitev gravimetrične učinkovitosti in odpornosti pretoka zraka za dano napravo za čiščenje. V vložek filtra se po ugotovitvi začetne učinkovitosti odstranjevanja delcev in kondicionirane učinkovitosti odstranjevanja delcev nalaga sintetični prah, dokler se ne doseže končni padec tlaka v preskusu. Krivulja padca tlaka v primerjavi z nalaganjem prahu se zabeleži med nalaganjem prahu, s čimer se ugotovi zmogljivost zadrževanja prahu. Rezultatov glede zmogljivosti, pridobljenih v skladu s to serijo standardov, ni mogoče samih po sebi kvantitativno uporabiti za predvidevanje zmogljivosti med obratovanjem, in sicer v zvezi z učinkovitostjo in življenjsko dobo. Drugi dejavniki, ki vplivajo na zmogljivost in jih je treba upoštevati, so opisani v dodatku A (informativnem).

General Information

Status
Published
Publication Date
13-Dec-2016
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Due Date
14-Dec-2016
Completion Date
14-Dec-2016

RELATIONS

Buy Standard

Standard
EN ISO 16890-3:2017
English language
30 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (sample)

SLOVENSKI STANDARD
