Overview

EN IEC 63203-201-1:2022 - Wearable electronic devices and technologies, Part 201-1: Electronic textile - Measurement methods for basic properties of conductive yarns - provides standardized procedures for handling and measuring the fundamental properties of conductive yarns used in e-textiles and wearable electronic devices. It focuses on yarns with sufficient conductivity for signal transmission, power supply and electromagnetic shielding, and explicitly excludes high-resistance yarns intended only for anti‑static or heating functions. The standard defines measurement environments and test methods rather than performance requirements.

Key topics

• Scope and classification
  • Defines conductive fibres and yarn structures (metallic coatings, core-sheath, blended constructions) and classifications relevant to e-textiles.
• Environmental conditioning
  • Specifies atmospheric conditions and specimen conditioning for reproducible measurements (aligned with textile testing practice).
• Electrical measurements
  • Methods to measure linear and bulk electrical resistance of conductive yarns and procedures for recording results.
  • Fusing current test to assess current carrying limits and failure behavior.
• Durability tests
  • Perspiration resistance: specimen preparation, artificial perspiration solutions and test procedure to evaluate corrosion and conductivity changes.
  • Detergent/wash resistance: washing procedures and reporting to assess wash durability of conductive yarns.
• Reporting and handling
  • Guidance on specimen preparation, test reporting, and referencing normative documents to ensure reproducibility.

Practical applications

Who uses EN IEC 63203-201-1:2022 and why:

• E-textile and wearable product designers - to select and specify conductive yarns for signal traces, power distribution and electromagnetic shielding in garments and wearable systems.
• Textile and yarn manufacturers - to characterize products consistently for datasheets and quality control.
• Test laboratories and certification bodies - to perform repeatable electrical and durability testing for compliance, R&D validation and supplier qualification.
• R&D teams and integrators - to compare conductive yarn options, evaluate wash and perspiration durability, and determine safe current-carrying limits.

Practical benefits include improved interoperability between materials and devices, predictable electrical performance in clothing-type wearables, and quantifiable metrics for reliability and wash durability.

Related standards

Normative references and closely related documents include:

• IEC 60468 - Method of measurement of resistivity of metallic materials
• ISO 105‑E04 - Colour fastness to perspiration
• ISO 139 - Standard atmospheres for conditioning and testing
• ISO 6330 - Domestic washing and drying procedures for textile testing
• EN 16812:2016 - Determination of linear electrical resistance of conductive tracks

Using EN IEC 63203-201-1:2022 helps stakeholders ensure reliable measurement of conductive yarn properties essential for robust, safe and durable wearable electronics and smart textiles.
