Audio, video, and related equipment - Determination of power consumption - Part 2: Signals and media

IEC 62087-2:2023 is available as IEC 62087-2:2023 RLV which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition. IEC 62087-2:2023 specifies the signals used to determine the power consumption of audio, video, and related equipment, such as television sets and computer monitors. It also specifies signals for determining the peak luminance ratio that is sometimes associated with television set power consumption measurement programs. In addition, this part specifies equipment, interfaces, and accuracy related to signal generation. IEC 62087-2:2023 cancels and replaces the first edition published in 2015. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: a) HDR and UHD video test signals have been added; b) dynamic box and outline test signals have been added, replacing the static box and outline test signals; c) all test signals are provided as media files for download from a specified IEC online repository, which replaces previous DVD and Blu-ray media.

Audio-, Video- und verwandte Geräte - Messverfahren für die Leistungsaufnahme - Teil 2: Signale und Medien

Appareils audio, vidéo et matériel connexe - Détermination de la consommation de puissance - Partie 2 : Signaux et supports

IEC 62087-2:2023 est disponible sous forme de IEC 62087-2:2023 RLV qui contient la Norme internationale et sa version Redline, illustrant les modifications du contenu technique depuis l'édition précédente. L'IEC 62087-2:2023 spécifie les signaux utilisés pour déterminer la consommation de puissance des appareils audio, vidéo et du matériel connexe, tels que les téléviseurs et les moniteurs d'ordinateurs. Elle spécifie également des signaux pour déterminer le rapport de luminance de crête qui est parfois associé aux programmes de mesurage de la consommation de puissance des téléviseurs. En outre, la présente partie spécifie le matériel, les interfaces ainsi que l'exactitude associés à la génération de ces signaux. L'IEC 62087-2:2023 annule et remplace la première édition parue en 2015. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente: a) ajout des signaux d'essai vidéo HDR et UHD; b) ajout des signaux d'essai de boîte et de contour dynamiques, qui remplacent les signaux d'essai de boîte et de contour statiques; c) mise à disposition de l'ensemble des signaux d'essai sous forme de fichiers multimédias à télécharger à partir d'un référentiel en ligne spécifié de l'IEC, qui remplace les supports DVD et Blu-ray précédents.

Avdio, video in pripadajoča oprema - Ugotavljanje porabe energije - 2. del: Signali in mediji (IEC 62087-2:2023)

General Information

Status
Published
Publication Date
30-Mar-2023
Current Stage
6060 - Document made available - Publishing
Start Date
31-Mar-2023
Due Date
22-Apr-2022
Completion Date
31-Mar-2023

Relations

Buy Standard

Draft
prEN IEC 62087-2:2022 - BARVE
English language
36 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)

SLOVENSKI STANDARD
oSIST prEN IEC 62087-2:2022
01-september-2022

Avdio, video in pripadajoča oprema - Ugotavljanje porabe energije - 2. del: Signali

in mediji (TA 19)

Audio, video, and related equipment - Determination of power consumption - Part 2:

Signals and media (TA 19)
Appareils audio, vidéo et matériel connexe - Détermination de la consommation de
puissance - Partie 2 : Signaux et supports (TA 19)
Ta slovenski standard je istoveten z: prEN IEC 62087-2:2022
ICS:
17.220.20 Merjenje električnih in Measurement of electrical
magnetnih veličin and magnetic quantities
33.160.01 Avdio, video in avdiovizualni Audio, video and audiovisual
sistemi na splošno systems in general
oSIST prEN IEC 62087-2:2022 en,fr,de

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
oSIST prEN IEC 62087-2:2022
---------------------- Page: 2 ----------------------
oSIST prEN IEC 62087-2:2022
100/3771/CDV
COMMITTEE DRAFT FOR VOTE (CDV)
PROJECT NUMBER:
IEC 62087-2 ED2
DATE OF CIRCULATION: CLOSING DATE FOR VOTING:
2022-07-01 2022-09-23
SUPERSEDES DOCUMENTS:
100/3667/CD, 100/3727A/CC

IEC TA 19 : ENVIRONMENTAL AND ENERGY ASPECTS FOR MULTIMEDIA SYSTEMS AND EQUIPMENT

SECRETARIAT: SECRETARY:
Germany Mr Andreas Schneider
OF INTEREST TO THE FOLLOWING COMMITTEES: PROPOSED HORIZONTAL STANDARD:
Other TC/SCs are requested to indicate their interest, if
any, in this CDV to the secretary.
FUNCTIONS CONCERNED:
EMC ENVIRONMENT QUALITY ASSURANCE SAFETY

SUBMITTED FOR CENELEC PARALLEL VOTING NOT SUBMITTED FOR CENELEC PARALLEL VOTING

Attention IEC-CENELEC parallel voting
The attention of IEC National Committees, members of
CENELEC, is drawn to the fact that this Committee Draft
for Vote (CDV) is submitted for parallel voting.
The CENELEC members are invited to vote through the
CENELEC online voting system.

This document is still under study and subject to change. It should not be used for reference purposes.

Recipients of this document are invited to submit, with their comments, notification of any relevant patent rights of

which they are aware and to provide supporting documentation.
TITLE:

Audio, video, and related equipment - Determination of power consumption - Part 2: Signals

and media (TA 19)
PROPOSED STABILITY DATE: 2027
NOTE FROM TC/SC OFFICERS:

Copyright © 2022 International Electrotechnical Commission, IEC. All rights reserved. It is permitted to download this

electronic file, to make a copy and to print out the content for the sole purpose of preparing National Committee positions.

You may not copy or "mirror" the file or printed version of the document, or any part of it, for any other purpose without

permission in writing from IEC.
---------------------- Page: 3 ----------------------
oSIST prEN IEC 62087-2:2022
100/3771CDV - 2 - IEC CDV 62087-2 © IEC:2022
1 CONTENTS

2 CONTENTS ............................................................................................................................ 1

3 FOREWORD ........................................................................................................................... 4

4 INTRODUCTION ..................................................................................................................... 6

5 1 Scope .............................................................................................................................. 7

6 2 Normative references ...................................................................................................... 7

7 3 Terms, definitions, and abbreviations .............................................................................. 8

8 3.1 Terms and definitions.............................................................................................. 8

9 3.2 Abbreviations ........................................................................................................ 10

10 4 Signals .......................................................................................................................... 11

11 4.1 Audio-visual signals used for the determination of power consumption ................. 11

12 4.1.1 Overview ....................................................................................................... 11

13 4.1.2 Static video signals ........................................................................................ 12

14 4.1.3 Dynamic broadcast-content video signal ........................................................ 12

15 4.1.4 Internet-content video signal .......................................................................... 13

16 4.1.5 Audio signal associated with video signals..................................................... 13

17 4.2 Video signals used for the determination of the peak luminance ratio .................... 14

18 4.2.1 General ......................................................................................................... 14

19 4.2.2 Video signals ................................................................................................. 14

20 4.3 Audio signals used for determination of audio power consumption ........................ 15

21 4.3.1 Audio signals ................................................................................................. 15

22 4.3.2 Signal levels .................................................................................................. 15

23 5 Media ............................................................................................................................ 16

24 5.1 Online repository .................................................................................................. 16

25 5.2 Compatibility of test signals with previous packaged media ................................... 16

26 6 Signal provision ............................................................................................................. 17

27 6.1 General ................................................................................................................. 17

28 6.2 Signal provision equipment ................................................................................... 17

29 6.2.1 USB stick media inserted in a UUT USB port ................................................. 17

30 6.2.2 External audio-visual equipment .................................................................... 17

31 6.2.3 Service provider network equipment .............................................................. 18

32 6.2.4 Audio signal generator ................................................................................... 18

33 6.3 Interfaces.............................................................................................................. 18

34 6.3.1 USB ............................................................................................................... 18

35 6.3.2 HDMI® .......................................................................................................... 18

36 6.3.3 DisplayPort .................................................................................................... 18

37 6.3.4 Component analogue video ........................................................................... 19

38 6.3.5 S-Video ......................................................................................................... 19

39 6.3.6 Composite analogue video ............................................................................. 19

40 6.3.7 Analogue terrestrial interface ......................................................................... 19

41 6.3.8 Cable television interface .............................................................................. 19

42 6.3.9 Digital terrestrial interface.............................................................................. 19

43 6.3.10 Satellite interface ........................................................................................... 19

44 6.3.11 Network interfaces ......................................................................................... 20

45 6.3.12 Other interfaces ............................................................................................. 20

46 6.4 Accuracy of video signal levels ............................................................................. 20

---------------------- Page: 4 ----------------------
oSIST prEN IEC 62087-2:2022
IEC CDV 62087-2  IEC:2022 – 3 – 100/3771/CDV

47 Annex A (normative) Video signals used for the determination of power consumption .......... 21

48 A.1 Source of test media (video signals) ..................................................................... 21

49 A.2 Test media (video signals) available for download from the IEC 62087-2

50 online repository ................................................................................................... 21

51 Annex B (Informative) Description of video signals used for the determination of

52 power consumption ........................................................................................................ 28

53 B.1 General ................................................................................................................. 28

54 B.2 Static video signals ............................................................................................... 28

55 B.3 Dynamic broadcast-content video signals (SDR) ................................................... 28

56 B.4 Internet-content video signals ............................................................................... 29

57 B.5 Dynamic broadcast-content data (SDR) ................................................................ 30

58 B.6 Internet-content data ............................................................................................. 33

59 B.7 Dynamic broadcast-content video signals (HDR) ................................................... 33

60 Annex C (informative) Description of video signals used for the determination of the

61 peak luminance ratio ..................................................................................................... 34

62 C.1 General ................................................................................................................. 34

63 C.2 Three bar video signal .......................................................................................... 34

64 C.3 Dynamic box and outline video signal ................................................................... 34

65 Bibliography .......................................................................................................................... 35

67 Figure 1 – Occurrence of linear and non-linear signal encodings in context of a typical

68 display processing pipeline and how they can be used to compute APL and APL’ ................... 9

69 Figure 2 – Dynamic box and outline video signal (L20PeakLumMotion)................................. 14

70 Figure B.1 – SDR Dynamic broadcast-content video signal APL′ ........................................... 29

71 Figure B.2 – Internet-content video signal APL′ ..................................................................... 30

73 Table 1 – Static video signals overview ................................................................................. 12

74 Table 2 – Dynamic broadcast-content video signals overview ............................................... 13

75 Table 3 – Dynamic box and outline video signal naming ....................................................... 14

76 Table A.1 – 50p (50Hz) SDR SD video signals used for the determination of power

77 consumption ......................................................................................................................... 22

78 Table A.2 – 50p (50Hz) SDR HD & UHD video signals used for the determination of

79 power consumption ............................................................................................................... 23

80 Table A.3 – 50p (50Hz) HDR HD & UHD video signals used for the determination of

81 power consumption ............................................................................................................... 24

82 Table A.4 – 59.94p (60Hz) SDR SD video signals used for the determination of power

83 consumption ......................................................................................................................... 25

84 Table A.5 – 59.94p (60Hz) SDR HD & UHD video signals used for the determination of

85 power consumption ............................................................................................................... 26

86 Table A.6 – 59.94p (60Hz) HDR HD & UHD video signals used for the determination of

87 power consumption ............................................................................................................... 27

88 Table B.1 – SDR Dynamic broadcast-content data ................................................................ 30

89 Table B.2 – Internet-content data .......................................................................................... 33

---------------------- Page: 5 ----------------------
oSIST prEN IEC 62087-2:2022
100/3771CDV - 4 - IEC CDV 62087-2 © IEC:2022
92 INTERNATIONAL ELECTROTECHNICAL COMMISSION
93 ____________
95 AUDIO, VIDEO, AND RELATED EQUIPMENT –
96 DETERMINATION OF POWER CONSUMPTION –
98 Part 2: Signals and media
100 FOREWORD

101 1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising

102 all national electrotechnical committees (IEC National Committees). The object of IEC is to promote international

103 co-operation on all questions concerning standardization in the electrical and electronic fields. To this end and

104 in addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,

105 Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC Publication(s)”). Their

106 preparation is entrusted to technical committees; any IEC National Committee interested in the subject dealt with

107 may participate in this preparatory work. International, governmental and non-governmental organizations liaising

108 with the IEC also participate in this preparation. IEC collaborates closely with the International Organization for

109 Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.

110 2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international

111 consensus of opinion on the relevant subjects since each technical committee has representation from all

112 interested IEC National Committees.

113 3) IEC Publications have the form of recommendations for international use and are accepted by IEC National

114 Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC

115 Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any

116 misinterpretation by any end user.

117 4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications

118 transparently to the maximum extent possible in their national and regional publications. Any divergence between

119 any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.

120 5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity

121 assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any

122 services carried out by independent certification bodies.

123 6) All users should ensure that they have the latest edition of this publication.

124 7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and

125 members of its technical committees and IEC National Committees for any personal injury, property damage or

126 other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and

127 expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC

128 Publications.

129 8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is

130 indispensable for the correct application of this publication.

131 9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of patent

132 rights. IEC shall not be held responsible for identifying any or all such patent rights.

133 International Standard IEC 62087-2 has been prepared by technical area 19: Environmental

134 and energy aspects for multimedia systems and equipment, of IEC technical committee 100:

135 Audio, video and multimedia systems and equipment.
136 This edition constitutes a technical revision.

137 This second edition of IEC 62087-2 includes the following significant technical changes with

138 respect to IEC 62087-2:2015:
139 - HDR and UHD video test signals have been added.

140 - Dynamic box and outline test signals have been added, replacing the static box and

141 outline test signals.

142 - All test signals are provided as media files for download from a specified IEC online

143 repository, which replaces previous DVD and Blu-ray media.
---------------------- Page: 6 ----------------------
oSIST prEN IEC 62087-2:2022
IEC CDV 62087-2  IEC:2022 – 5 – 100/3771/CDV
144 The text of this standard is based on the following documents:
FDIS Report on voting
100/xxx/FDIS 100/xxx/RVD
145

146 Full information on the voting for the approval of this standard can be found in the report on

147 voting indicated in the above table.

148 A list of all parts in the IEC 62087 series, published under the general title Audio, video, and

149 related equipment – Determination of power consumption, can be found on the IEC website.

150 This publication contains multiple test signals downloadable from a specified IEC online

151 repository, as indicated in the list of normative references. These files form an integral part of

152 this standard.

153 This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.

154 The committee has decided that the contents of this publication will remain unchanged until the

155 stability date indicated on the IEC website under "http://webstore.iec.ch" in the data related to

156 the specific publication. At this date, the publication will be
157 • reconfirmed,
158 • withdrawn,
159 • replaced by a revised edition, or
160 • amended.
161
162 A bilingual version of this publication may be issued at a later date.
163

IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates that it

contains colours which are considered to be useful for the correct understanding of its

contents. Users should therefore print this document using a colour printer.
164
165
---------------------- Page: 7 ----------------------
oSIST prEN IEC 62087-2:2022
100/3771CDV - 6 - IEC CDV 62087-2 © IEC:2022
166 INTRODUCTION

167 This document identifies test signals to be used to determine power consumption and related

168 characteristics specified in some other parts of the IEC 62087 series.

169 IEC 62087:2008 (second edition) added methods for measuring On (average) mode power

170 consumption of televisions, based on three video signal sets. These include static, dynamic

171 broadcast-content, and Internet-content signals.

172 IEC 62087:2011 (third edition) revised methods for measuring power consumption of set top

173 boxes. The signals and media were not changed in this third edition.

174 IEC 62087-2:2015 (first edition) separates signals and media that are to be used for

175 determining power consumption and related characteristics into a dedicated part. The three

176 original video signal sets (static, dynamic broadcast-content, and Internet-content) are not

177 changed. This edition adds signals for the purpose of determining the peak luminance ratio that

178 is sometimes associated with television power consumption measurement programs.

179 This second edition of IEC 62087-2 adds HDR and UHD video test signals and dynamic box

180 and outline test signals for TV power consumption testing. All test signals are available from a

181 specified IEC online repository for download, replacing former physical media distribution.

182 IEC 62087 series currently consists of the following published parts:
183 – Part 1: General
184 – Part 2: Signals and media
185 – Part 3: Television sets
186 – Part 4: Video recording equipment
187 – Part 5: Set top boxes
188 – Part 6: Audio equipment
189 – Part 7: Computer monitors
190
191
192
___________

IEC 62087:2008, Methods of measurement for the power consumption of audio, video and related equipment

IEC 62087:2011, Methods of measurement for the power consumption of audio, video and related equipment

IEC 62087-2:2015, Audio, video, and related equipment – Determination of power consumption, Part 2: Signals

and media
---------------------- Page: 8 ----------------------
oSIST prEN IEC 62087-2:2022
IEC CDV 62087-2  IEC:2022 – 7 – 100/3771/CDV
193 AUDIO, VIDEO, AND RELATED EQUIPMENT –
194 DETERMINATION OF POWER CONSUMPTION –
195
196 Part 2: Signals and media
197
198
199
200 1 Scope

201 This part of IEC 62087 specifies signals used in determination of the power consumption of

202 audio, video, and related equipment, such as television sets and computer monitors. It also

203 specifies signals for determining the peak luminance ratio that is sometimes associated with

204 television power consumption measurement programs. In addition, this part specifies

205 equipment, interfaces, and accuracy related to signal generation.
206 2 Normative references

207 The following documents are referred to in the text in such a way that some or all of their content

208 constitutes requirements of this document. For dated references, only the edition cited applies.

209 For undated references, the latest edition of the referenced document (including any

210 amendments) applies.

211 IEC 60107-1:1997, Methods of measurement on receivers for television broadcast trans-

212 missions – Part 1: General conditions – Measurements at radio and video frequencies

213 IEC 60268-1:1985, Sound system equipment – Part 1: General
214 IEC 60268-1:1985/AMD1:1988-01
215 IEC 60268-1:1985/AMD2:1988-06

216 IEC 60315-1:1988, Methods of measurement on radio receivers for various classes of emission.

217 Part 1: General considerations and methods of measurement, including audio-frequency

218 measurements

219 IEC 60315-3:1989+AMD1:1999 CSV, Methods of measurement on radio receivers for various

220 classes of emission - Part 3: Receivers for amplitude-modulated sound-broadcasting emissions

221 IEC 60315-4:1997, Methods of measurement on radio receivers for various classes of emission

222 - Part 4: Receivers for frequency-modulated sound broadcasting emissions
223 IEC 60958-1:2008, Digital audio interface – Part 1: General
224 IEC 60958-1:2008/AMD1:2014
225 IEC 60958-3:2006, Digital audio interface – Part 3: Consumer applications
226 IEC 60958-3:2006/AMD1:2009

227 IEC 61938:2013, Multimedia systems – Guide to the recommended characteristics of

228 analogue interfaces to achieve interoperability

229 IEC 62087-1:2015, Audio, video, and related equipment – Determination of power

230 consumption – Part 1: General
231 IEC online repository with signals and media for the IEC 62087 series at
232 https://www.iec.ch/tc100/supportingdocuments
---------------------- Page: 9 ----------------------
oSIST prEN IEC 62087-2:2022
100/3771CDV - 8 - IEC CDV 62087-2 © IEC:2022

233 IEC 62216:2009, Digital terrestrial television receivers for the DVB-T system

234 Recommendation ITU-R BT.2100-2: 2018, Image parameter values for high dynamic range

235 television for use in production and international programme exchange
236 3 Terms, definitions, and abbreviations
237 3.1 Terms and definitions

238 For the purposes of this document, the terms and definitions given in IEC 62087-1:2015 as well

239 as in the following apply.

240 ISO and IEC maintain terminological databases for use in standardization at the following

241 addresses:
242 • ISO Online browsing platform: available at https://www.iso.org/obp
243 • IEC Electropedia: available at http://www.electropedia.org/
244 3.1.1
245 average picture level
246 APL

247 average level of all the pixels of a single video signal frame or a group thereof in the linear

248 luminance domain

249 EXAMPLE Display equipment such as television sets or computer monitors that internally use linear encoding after

250 undoing the non-linearity of the input signal.
251 3.1.2
252 backlit display
253 display that generates light from a source behind the display panel
254 EXAMPLE Liquid-crystal display (LCD)
255 3.1.3
256 component analogue video

257 baseband analogue video interface that carries a standard or high definition colour video signal

258 over three signal lines
259 Note 1 to entry: See CTA-770.3-E R-2017.
260 3.1.4
261 composite analogue video

262 baseband analogue video interface that carries a standard definition colour video signal over a

263 single signal line

264 Note 1 to entry: See SMPTE ST 170M:2004 for the 59,94 Hz version and ITU-R BT.470-5 for the 50 Hz version.

265 3.1.5
266 digital visual interface
267 DVI
268 video interface that can carry analogue or digital uncompressed video
269 3.1.6
270 DisplayPort

271 digital display interface developed by the Video Electronics Standards Association

272 3.1.7
273 emissive display
274 display that generates light directly from each sub-pixel
---------------------- Page: 10 ----------------------
oSIST prEN IEC 62087-2:2022
IEC CDV 62087-2  IEC:2022 – 9 – 100/3771/CDV
275 EXAMPLE PDP or OLED displays
276 3.1.8
277 average picture level based on non-linear input signal
278 APL′

279 average level of all pixels of a single video signal frame or a group thereof in the non-linear

280 luminance domain

281 EXAMPLE Display equipment such as television sets or computer monitor receive input signals that encode

282 luminance or brightness in a non-linear way. Examples for such non-linear encoding are PQ (absolute luminance) or

283 HLG (brightness) EOTFs (ITU-R BT.2100-2).

284 Note 1 to entry: APL′ is defined as a percentage of the range between reference black and reference white level.

285 Note 2 to entry: This is not a measure of the linear signal that might be available inside of some display equipment

286 and delivered to the display device. The properties and their differences of the external and internal video signals

287 are shown in Figure 1.
288

289 Figure 1 – Occurrence of linear and non-linear signal encodings in context of a typical

290 display processing pipeline and how they can be used to compute APL and APL’
291 3.1.9
292 hybrid log-gamma
293 HLG

294 one set of transfer functions offering a degree of backwards compatibility by more closely

295 matching the previously established television transfer curves

296 Note 1 to entry: Sets of transfer functions related to HDR signals are specified in Rec. ITU-R BT.2100-2.

297 Note 2 to entry: HLG is used both as a description of a dedicated transfer function and as a video format name.

298 3.1.10
299 high dynamic range video
300 HDR video

301 capability of components in a video pipeline to capture, process, transport or display luminance

302 levels and tone gradations that exceed capabilities of conventional SDR imaging pipelines

303 components

304 EXAMPLE An HDR video signal typically uses a greater bit depth, luminance and colour volume than standard

305 dynamic range (SDR) video. It also typically utilizes different tone curves such as perceptual quantizer (PQ) or hybrid

306 log gamma (HLG) as specified in ITU-R BT.2100 instead of gamma, as used with SDR. When the HDR video signal

307 is rendered on an HDR display, it is possible to see greater luminance ranges and wider colour gamut

308 Note 1 to entry: HDR video can provide an enhanced viewer experience and can more accurately reproduce scenes

309 that include, within the same image, deep dark areas, and bright highlights, such as emissive light sources and

310 reflections.
311 3.1.11
312 high definition
313 HD
314 spatial video resolution ranging from 1 280 × 720 to 1 920 × 1 080
---------------------- Page: 11 ----------------------
oSIST prEN IEC 62087-2:2022
100/3771CDV - 10 - IEC CDV 62087-2 © IEC:2022
315 3.1.12
316 ultra high definition
317 UHD
318 Ultra HD
319 spatial video resolution above 1 920 × 1 080
320 3.1.13
321 universal serial bus
322 USB

323 digital interface that can be used to connect storage media and peripherals to digital devices

324 like computers and TVs
325 Note 1 to entry: See USB specification.
326 3.1.14
327 high definition multimedia interface
328 HDMI®

329 audio-visual interface that is capable of carrying uncompressed video data, compressed or

330 uncompressed digital audio data, and other information
331 Note 1 to entry: See HDMI specification.
332 3.1.15
333 luma
334 Y′
335 gamma-corrected video signal that represents brightness
336 1.1.1
337 standard dynamic range video
338 SDR video
339 capability of components in a video
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
