EN 60204-1:1997
(Main)Safety of machinery - Electrical equipment of machines - Part 1: General requirements
- BACK
- 10-Dec-1997
- 30-Jun-2001
- 13.110
- 2006/95/EC
- 73/23/EEC
- 98/37/EC
- M/083
- CLC/TC 44X
Safety of machinery - Electrical equipment of machines - Part 1: General requirements
Applies to the electrical and electronic equipment of industrial machines. Promotes the safety of persons who come into contact with industrial machines, not only from hazards associated with electricity (such as electrical shock and fire), but also resulting from the malfunction of the electrical equipment itself. Addresses hazards associated with the machine and its environment.
Sicherheit von Maschinen - Elektrische Ausrüstung von Maschinen - Teil 1: Allgemeine Anforderungen
Sécurité des machines - Equipement électrique des machines - Partie 1: Règles générales
S'applique aux équipements et systèmes électriques et électroniques des machines industrielles. Assure la sécurité des personnes, non seulement contre les risques normalement associés à l'utilisation de l'électricité comme le feu ou les chocs électriques, mais également contre les dangers qui peuvent découler du mauvais fonctionnement de l'équipement proprement dit. Porte aussi sur les dangers engendrés par les machines et leur environnement.
