ETSI TS 129 554 V15.4.0 (2019-10)

5G; 5G System; Background Data Transfer Policy Control Service; Stage 3 (3GPP TS 29.554 version 15.4.0 Release 15)

RTS/TSGC-0329554vf40

General Information

• Status: Published
• Publication Date: 23-Oct-2019
• Technical Committee: 3GPP CT 3 - Interworking with external networks (formely CN3)
• Current Stage: 12 - Completion
• Completion Date: 24-Oct-2019

Standards Content (Sample)

ETSI TS 129 554 V15.4.0 (2019-10)






TECHNICAL SPECIFICATION
5G;
5G System;
Background Data Transfer Policy Control Service;
Stage 3
(3GPP TS 29.554 version 15.4.0 Release 15)



---------------------- Page: 1 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 1 ETSI TS 129 554 V15.4.0 (2019-10)



Reference
RTS/TSGC-0329554vf40
Keywords
5G
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: [phone]  Fax: [phone]

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
The present document can be downloaded from:
http://www.etsi.org/standards-search
The present document may be made available in electronic versions and/or in print. The content of any electronic and/or
print versions of the present document shall not be modified without the prior written authorization of ETSI. In case of any
existing or perceived difference in contents between such versions and/or in print, the prevailing version of an ETSI
deliverable is the one made publicly available in PDF format at www.etsi.org/deliver.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
https://portal.etsi.org/TB/ETSIDeliverableStatus.aspx
If you find errors in the present document, please send your comment to one of the following services:
https://portal.etsi.org/People/CommiteeSupportStaff.aspx
Copyright Notification
No part may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying
and microfilm except as authorized by written permission of ETSI.
The content of the PDF version shall not be modified without the written authorization of ETSI.
The copyright and the foregoing restriction extend to reproduction in all media.

© ETSI 2019.
All rights reserved.

DECT™, PLUGTESTS™, UMTS™ and the ETSI logo are trademarks of ETSI registered for the benefit of its Members.

3GPP™ and LTE™ are trademarks of ETSI registered for the benefit of its Members and
of the 3GPP Organizational Partners.
oneM2M™ logo is a trademark of ETSI registered for the benefit of its Members and
of the oneM2M Partners.
®
GSM and the GSM logo are trademarks registered and owned by the GSM Association.
ETSI

---------------------- Page: 2 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 2 ETSI TS 129 554 V15.4.0 (2019-10)
Intellectual Property Rights
Essential patents
IPRs essential or potentially essential to normative deliverables may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (https://ipr.etsi.org/).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Trademarks
The present document may include trademarks and/or tradenames which are asserted and/or registered by their owners.
ETSI claims no ownership of these except for any which are indicated as being the property of ETSI, and conveys no
right to use or reproduce any trademark and/or tradename. Mention of those trademarks in the present document does
not constitute an endorsement by ETSI of products, services or organizations associated with those trademarks.
Legal Notice
This Technical Specification (TS) has been produced by ETSI 3rd Generation Partnership Project (3GPP).
The present document may refer to technical specifications or reports using their 3GPP identities. These shall be
interpreted as being references to the corresponding ETSI deliverables.
The cross reference between 3GPP and ETSI identities can be found under http://webapp.etsi.org/key/queryform.asp.
Modal verbs terminology
In the present document "shall", "shall not", "should", "should not", "may", "need not", "will", "will not", "can" and
"cannot" are to be interpreted as described in clause 3.2 of the ETSI Drafting Rules (Verbal forms for the expression of
provisions).
"must" and "must not" are NOT allowed in ETSI deliverables except when used in direct citation.
ETSI

---------------------- Page: 3 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 3 ETSI TS 129 554 V15.4.0 (2019-10)
Contents
Intellectual Property Rights . 2
Legal Notice . 2
Modal verbs terminology . 2
Foreword . 5
1 Scope . 6
2 References . 6
3 Definitions and abbreviations . 7
3.1 Definitions . 7
3.2 Abbreviations . 7
4 Background Data Transfer Policy Control Service . 8
4.1 Service Description . 8
4.1.1 Overview . 8
4.1.2 Service Architecture . 8
4.1.3 Network Functions . 9
4.1.3.1 Policy Control Function (PCF) . 9
4.1.3.2 NF Service Consumers . 9
4.2 Service Operations . 9
4.2.1 Introduction. 9
4.2.2 Npcf_BDTPolicyControl_Create service operation . 9
4.2.2.1 General . 9
4.2.2.2 Retrieval of BDT policies . 10
4.2.3 Npcf_BDTPolicyControl_Update service operation . 11
4.2.3.1 General . 11
4.2.3.2 Indication about selected transfer policy . 11
5 Npcf_BDTPolicyControl API . 12
5.1 Introduction . 12
5.2 Usage of HTTP . 13
5.2.1 General . 13
5.2.2 HTTP standard headers . 13
5.2.2.1 General . 13
5.2.2.2 Content type . 13
5.2.3 HTTP custom headers . 13
5.3 Resources . 14
5.3.1 Resource Structure . 14
5.3.2 Resource: BDT policies (Collection) . 14
5.3.2.1 Description . 14
5.3.2.2 Resource definition . 14
5.3.2.3 Resource Standard Methods . 15
5.3.2.3.1 POST . 15
5.3.2.4 Resource Custom Operations . 15
5.3.3 Resource: Individual BDT policy (Document) . 15
5.3.3.1 Description . 15
5.3.3.2 Resource definition . 15
5.3.3.3 Resource Standard Methods . 16
5.3.3.3.1 GET . 16
5.3.3.3.2 PATCH . 16
5.4 Custom Operations without associated resources. 17
5.5 Notifications . 17
5.6 Data Model . 17
5.6.1 General . 17
5.6.2 Structured data types . 18
5.6.2.1 Introduction . 18
5.6.2.2 Type BdtPolicy . 18
ETSI

---------------------- Page: 4 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 4 ETSI TS 129 554 V15.4.0 (2019-10)
5.6.2.3 Type BdtReqData . 19
5.6.2.4 Type BdtPolicyData . 19
5.6.2.5 Type TransferPolicy . 20
5.6.2.6 Type BdtPolicyDataPatch . 20
5.6.2.7 Void. 20
5.6.2.8 Type NetworkAreaInfo . 20
5.6.2.9 Void. 20
5.6.3 Simple data types and enumerations . 20
5.6.3.1 Introduction . 20
5.6.3.2 Simple data types . 21
5.7 Error handling . 21
5.7.1 General . 21
5.7.2 Protocol Errors . 21
5.7.3 Application Errors . 21
5.8 Feature negotiation . 21
5.9 Security . 22
Annex A (normative): OpenAPI specification . 23
A.1 General . 23
A.2 Npcf_BDTPolicyControl API . 23
Annex B (informative): Change history . 28
History . 29

ETSI

---------------------- Page: 5 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 5 ETSI TS 129 554 V15.4.0 (2019-10)
Foreword
rd
This Technical Specification has been produced by the 3 Generation Partnership Project (3GPP).
The contents of the present document are subject to continuing work within the TSG and may change following formal
TSG approval. Should the TSG modify the contents of the present document, it will be re-released by the TSG with an
identifying change of release date and an increase in version number as follows:
Version x.y.z
where:
x the first digit:
1 presented to TSG for information;
2 presented to TSG for approval;
3 or greater indicates TSG approved document under change control.
y the second digit is incremented for all changes of substance, i.e. technical enhancements, corrections,
updates, etc.
z the third digit is incremented when editorial only changes have been incorporated in the document.
ETSI

---------------------- Page: 6 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 6 ETSI TS 129 554 V15.4.0 (2019-10)
1 Scope
The present specification provides the stage 3 definition of the Background Data Transfer (BDT) Policy Control Service
(Npcf_BDTPolicyControl) of the 5G System.
The 5G System Architecture is defined in 3GPP TS 23.501 [2]. The stage 2 definition and related procedures for BDT
Policy Control Service are specified in 3GPP TS 23.502 [3] and 3GPP TS 23.503 [4].
The 5G System stage 3 call flows are provided in 3GPP TS 29.513 [5].
The Technical Realization of the Service Based Architecture and the Principles and Guidelines for Services Definition
are specified in 3GPP TS 29.500 [6] and 3GPP TS 29.501 [7].
The Policy Control Function (PCF) provides the BDT Policy Control Service. This service provides background data
transfer policy negotiation function.
2 References
The following documents contain provisions which, through reference in this text, constitute provisions of the present
document.
- References are either specific (identified by date of publication, edition number, version number, etc.) or
non-specific.
- For a specific reference, subsequent revisions do not apply.
- For a non-specific reference, the latest version applies. In the case of a reference to a 3GPP document (including
a GSM document), a non-specific reference implicitly refers to the latest version of that document in the same
Release as the present document.
[1] 3GPP TR 21.905: "Vocabulary for 3GPP Specifications".
[2] 3GPP TS 23.501: "System Architecture for the 5G System; Stage 2".
[3] 3GPP TS 23.502: "Procedures for the 5G System; Stage 2".
[4] 3GPP TS 23.503: "Policy and Charging Control Framework for the 5G System; Stage 2".
[5] 3GPP TS 29.513: "5G System; Policy and Charging Control signalling flows and QoS parameter
mapping; Stage 3".
[6] 3GPP TS 29.500: "5G System; Technical Realization of Service Based Architecture; Stage 3".
[7] 3GPP TS 29.501: "5G System; Principles and Guidelines for Services Definition; Stage 3".
[8] IETF RFC 7540: "Hypertext Transfer Protocol Version 2 (HTTP/2)".
[9] IETF RFC 8259: "The JavaScript Object Notation (JSON) Data Interchange Format".
[10] OpenAPI: "OpenAPI 3.0.0 Specification", https://github.com/OAI/OpenAPI-
Specification/blob/master/versions/3.0.0.md.
[11] 3GPP TS 29.504: "5G System; Unified Data Repository Services; Stage 3".
[12] 3GPP TS 29.519: "5G System; Usage of the Unified Data Repository service for Policy Data,
Application Data and Structured Data for exposure; Stage 3".
[13] 3GPP TS 29.571: "5G System; Common Data Types for Service Based Interfaces; Stage 3".
[14] 3GPP TS 29.122: "T8 reference point for Northbound APIs".
[15] IETF RFC 7396: "JSON Merge Patch".
[16] IETF RFC 3986: "Uniform Resource Identifier (URI): Generic Syntax".
ETSI

---------------------- Page: 7 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 7 ETSI TS 129 554 V15.4.0 (2019-10)
[17] IETF RFC 7807: "Problem Details for HTTP APIs".
[18] 3GPP TS 33.501: "Security architecture and procedures for 5G system".
[19] IETF RFC 6749: "The OAuth 2.0 Authorization Framework".
[20] 3GPP TS 29.510: "5G System; Network Function Repository Services; Stage 3".
[21] 3GPP TR 21.900: "Technical Specification Group working methods".
3 Definitions and abbreviations
3.1 Definitions
For the purposes of the present document, the terms and definitions given in 3GPP TR 21.905 [1] and the following
apply. A term defined in the present document takes precedence over the definition of the same term, if any, in
3GPP TR 21.905 [1].
Background data transfer: feature that enables a 3rd party service provider to keep their costs lower by favouring
time windows for data transfer to specific UEs in a geographical area during non-busy hours that are less costly and
able to handle larger bitrates.
For the purposes of the present document, the following terms and definitions given in 3GPP TS 23.501 [2],
subclause 3.1 apply:
5G System
Network Function
NF service
NF service operation
Service based interface
3.2 Abbreviations
For the purposes of the present document, the abbreviations given in 3GPP TR 21.905 [1] and the following apply. An
abbreviation defined in the present document takes precedence over the definition of the same abbreviation, if any, in
3GPP TR 21.905 [1].
AF Application Function
ASP Application Service Provider
BDT Background Data Transfer
JSON JavaScript Object Notation
NEF Network Exposure Function
NG-RAN Next Generation - Radio Access Network
NRF Network Repository Function
PCF Policy Control Function
SBI Service Based Interface
TAI Tracking Area Identity
UDR Unified Data Repository
ETSI

---------------------- Page: 8 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 8 ETSI TS 129 554 V15.4.0 (2019-10)
4 Background Data Transfer Policy Control Service
4.1 Service Description
4.1.1 Overview
The BDT Policy Control Service, as defined in 3GPP TS 23.502 [3] and 3GPP TS 23.503 [4], is provided by the Policy
Control Function (PCF).
This service enables the NF service consumer to negotiate policy for a future background data transfer and offers the
following functionalities:
- get background data transfer policies based on the request from the NEF; and
- update background data transfer policies based on the selection provided by the NEF.
4.1.2 Service Architecture
The 5G System Architecture is defined in 3GPP TS 23.501 [2]. The Policy and Charging related 5G architecture is also
described in 3GPP TS 29.513 [5].
The BDT Policy Control Service (Npcf_BDTPolicyControl) is part of the Npcf service-based interface exhibited by the
Policy Control Function (PCF).
The only known NF service consumer of the Npcf_BDTPolicyControl service is the Network Exposure Function
(NEF).
The NEF accesses the BDT Policy Control Service at the PCF via the N30 Reference point. In the roaming scenario, the
N30 reference point is located between the PCF and the NEF in the home network only.
PCF
Npcf
Npcf_BDTPolicyControl
NEF

Figure 4.1.2-1: Reference Architecture for the Npcf_BDTPolicyControl Service; SBI representation
ETSI

---------------------- Page: 9 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 9 ETSI TS 129 554 V15.4.0 (2019-10)
PCF
N30
NEF

Figure 4.1.2-2: Reference Architecture for the Npcf_BDTPolicyControl Service; reference point
representation
4.1.3 Network Functions
4.1.3.1 Policy Control Function (PCF)
The Policy Control Function (PCF):
- Provides background data transfer policies based on the request from the NEF. The PCF determines, based on
information provided by the NEF and other available information (e.g. network policy, load status estimation for
the requested time window, network area, etc.) one or more transfer policies.
- Updates background data transfer policy based on the selection provided by the NEF.
4.1.3.2 NF Service Consumers
The Network Exposure Function (NEF):
- requests the PCF to provide background data transfer policies; and
- provides the selected background data transfer policy to the PCF.
4.2 Service Operations
4.2.1 Introduction
Table 4.2.1-1: Operations of the Npcf_BDTPolicyControl Service
Service operation name Description Initiated by
Npcf_BDTPolicyControl_Create Provides the requested background data transfer NF service consumer
policies to the NF service consumer. (NEF)
Npcf_BDTPolicyControl_Update Updates the PCF with the background data transfer NF service consumer
policy selected by the NF service consumer. (NEF)

4.2.2 Npcf_BDTPolicyControl_Create service operation
4.2.2.1 General
The Npcf_BDTPolicyControl_Create service operation is used by an NF service consumer to retrieve BDT policies
from the PCF.
The following procedure using the Npcf_BDTPolicyControl_Create service operation is supported:
ETSI

---------------------- Page: 10 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 10 ETSI TS 129 554 V15.4.0 (2019-10)
- retrieval of BDT policies.
4.2.2.2 Retrieval of BDT policies
This procedure is used by the NEF to request BDT policies from the PCF, as defined in 3GPP TS 23.501 [2],
3GPP TS 23.502 [3] and 3GPP TS 23.503 [4].
Figure 4.2.2.2-1 illustrates a retrieval of BDT policies.
PCF
NEF
1. POST …/bdtpolicies
2. "201 Created"

Figure 4.2.2.2-1: Retrieval of BDT policies
Upon reception of a Background Data Transfer request from the AF indicating a transfer policy request, the NEF shall
invoke the Npcf_BDTPolicyControl_Create service operation by sending an HTTP POST request to the URI
representing a "BDT policies" collection resource of the PCF (as shown in figure 4.2.2.2-1, step 1). The NEF shall
include a "BdtReqData" data type in a payload body of the HTTP POST request. The "BdtReqData" data type shall
contain:
- an ASP identifier in the "aspId" attribute;
- a volume of data per UE in the "volPerUe" attribute;
- an expected number of UEs in the "numOfUes" attribute; and
- a desired time window in the "desTimeInt" attribute,
and may include a network area information (e.g. list of TAIs and/or NG-RAN nodes and/or cells identifiers) in the
"nwAreaInfo" attribute.
If the PCF cannot successfully fulfil the received HTTP POST request due to the internal PCF error or due to the error
in the HTTP POST request, the PCF shall send the HTTP error response as specified in subclause 5.7.
Otherwise, upon the reception of the HTTP POST request from the NEF indicating a BDT policies request, the PCF:
- may invoke the Nudr_DataRepository_Query service operation, as described in 3GPP TS 29.504 [11] and
3GPP TS 29.519 [12], to request from the UDR all stored transfer policies;
NOTE 1: In case only one PCF is deployed in the network, transfer policies can be locally stored in the PCF and the
interaction with the UDR is not required.
- shall determine one or more acceptable transfer policies based on:
a) information provided by the NEF; and
b) other available information (e.g. the existing transfer policies, network policy, load status estimation for the
desired time window); and
- shall create a BDT Reference ID.
The PCF shall send to the NEF a "201 Created" response to the HTTP POST request, as shown in figure 4.2.2.2-1,
step 2. The PCF shall include in the "201 Created" response:
ETSI

---------------------- Page: 11 ----------------------
3GPP TS 29.554 version 15.4.0 Release 15 11 ETSI TS 129 554 V15.4.0 (2019-10)
- a Location header field; and
- a "BdtPolicy" data type in the payload body containing the BDT Reference ID in the "bdtRefId" attribute and
acceptable transfer policy/ies in the "transfPolicies" attribute.
The Location header field shall contain the URI of the created individual BDT policy resource i.e. "{apiRoot}/npcf-
bdtpolicycontrol/v1/bdtpolicies/{bdtPolicyId}".
For each included transfer policy, the PCF shall provide:
- a transfer policy ID in the "transPolicyId" attribute;
- a recommended time window in the "recTimeInt" attribute; and
- a reference to charging rate for the recommended time window in the "ratingGroup" attribute,
and may provide a maximum aggregated bitrate for the uplink direction in the "maxBitRateUl" attribute and/or a
maximum aggregated bitrate for the downlink direction in the "maxBitRateDl" attribute.
If the PCF included in the "BdtPolicy" data type:
- more than one transfer policy, the PCF shall wait for the transfer policy selected by the NEF as described in
subclause 4.2.3; or
- only one transfer policy, the PCF may invoke the Nudr_DataRepository_Update service operation, as described
in 3GPP TS 29.504 [11] and 3GPP TS 29.519 [12], to update the UDR with the selected transfer policy, the
corresponding BDT Reference ID, the volume of data per UE, the expected number of UEs and if available a
network area information for the provided ASP identifier.
NOTE 2: In case only one PCF is deployed in the network, transfer policies can be locally s
...
