ETSI EN 301 908-10 V4.2.2 (2016-11)

Electromagnetic compatibility and Radio spectrum Matters (ERM); Base Stations (BS), Repeaters and User Equipment (UE) for IMT-2000 Third-Generation cellular networks; Part 10: Harmonised Standard for IMT-2000, FDMA/TDMA (DECT) covering the essential requirements of article 3.2 of the Directive 2014/53/EU

REN/DECT-000302-C1

Elektromagnetna združljivost in zadeve v zvezi z radijskim spektrom (ERM) - Bazne postaje (BS), ponavljalniki (repetitorji) in uporabniška oprema (UE) za celična omrežja tretje generacije IMT-2000 - 10. del: Harmonizirani standard za IMT-2000, FDMA/TDMA (DECT), ki zajema bistvene zahteve člena 3.2 direktive 2014/53/EU

Ta dokument se uporablja za naslednje vrste opreme celičnih omrežij fiksnih radijskih priključkov (IMT-FT): Celična omrežja fiksnih radijskih priključkov (IMT-FT) so sistem digitalne izboljšane brezvrvične telekomunikacije (DECT), član družine ITU IMT-2000:
a) fiksni del (FP);
b) prenosni del (PP);
c) brezvrvični terminalski prilagodilnik (CTA);
d) brezžična relejna postaja (WRS) (fiksni in prenosni del skupaj);
e) hibridni del (HyP) (prenosni del z zmožnostjo delovanja kot fiksni del za namen zagotovitve komunikacije med dvema prenosnima deloma).
Frekvenčni pasovi celičnih omrežij fiksnih radijskih priključkov digitalnih izboljšanih brezvrvičnih komunikacij (IMT-FT (DECT)) za oddajanje in prejemanje vseh elementov so del evropskega spektra UMTS, ki velja za delovanje TDD, od 1900 MHz do 1980 MHz ter od 2010 MHz do 2025 MHz (glejte ERC/DEC(99)25 [8] in ERC/DEC(00)01 [9]).
OPOMBA: oprema celičnih omrežij fiksnih radijskih priključkov (IMT-FT) ima lahko drug način zagotavljanja delovanja tudi v pasu od 1880 MHz do 1900 MHz digitalnih izboljšanih brezvrvičnih komunikacij (DECT). Uporabo digitalnih izboljšanih brezvrvičnih komunikacij (DECT) v pasu od 1880 MHz do 1900 MHz pokriva standard ETSI
EN 301 406 [i.7].
Podrobnosti skupnega vmesnika za digitalne izboljšane brezvrvične telekomunikacije so navedene v standardih ETSI EN 300 175-1 [i.12], ETSI EN 300 175 (2. in 3. del) od [1] do [2], ETSI EN 300 175-4 [i.i.13], ETSI EN 300 175 (5. in 6. del) od [3] do [4] ter ETSI EN 300 175 (7. in 8. del) od [i.14] do [i.15].
Dodatne podrobnosti o sistemu digitalne izboljšane brezvrvične telekomunikacije (DECT) so na voljo v standardih ETSI TR 101 178 [i.1] in ETSI ETR 043 [i.2]. Informacije o ultra nizki porabi energije (ULE) so na voljo v standardih ETSI TS 102 939-1 [i.16] in ETSI TS 102 939-2 [i.17].
Ta dokument vsebuje zahteve, s katerimi se dokazuje, da radijska oprema optimalno uporablja in podpira učinkovito rabo radijskega spektra z namenom preprečevanja škodljivih motenj.
