TECHNICAL SPECIFICATION
5G;
Management and orchestration;
5G performance measurements
(3GPP TS 28.552 version 15.5.0 Release 15)

3GPP TS 28.552 version 15.5.0 Release 15 1 ETSI TS 128 552 V15.5.0 (2020-01)

Reference
RTS/TSGS-0528552vf50
Keywords
5G
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: [phone]  Fax: [phone]

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
The present document can be downloaded from:
http://www.etsi.org/standards-search
The present document may be made available in electronic versions and/or in print. The content of any electronic and/or
print versions of the present document shall not be modified without the prior written authorization of ETSI. In case of any
existing or perceived difference in contents between such versions and/or in print, the prevailing version of an ETSI
deliverable is the one made publicly available in PDF format at www.etsi.org/deliver.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
https://portal.etsi.org/TB/ETSIDeliverableStatus.aspx
If you find errors in the present document, please send your comment to one of the following services:
https://portal.etsi.org/People/CommiteeSupportStaff.aspx
Copyright Notification
No part may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying
and microfilm except as authorized by written permission of ETSI.
The content of the PDF version shall not be modified without the written authorization of ETSI.
The copyright and the foregoing restriction extend to reproduction in all media.

© ETSI 2020.
All rights reserved.
DECT™, PLUGTESTS™, UMTS™ and the ETSI logo are trademarks of ETSI registered for the benefit of its Members.

3GPP™ and LTE™ are trademarks of ETSI registered for the benefit of its Members and
of the 3GPP Organizational Partners.
oneM2M™ logo is a trademark of ETSI registered for the benefit of its Members and
of the oneM2M Partners. ®
GSM and the GSM logo are trademarks registered and owned by the GSM Association.
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 2 ETSI TS 128 552 V15.5.0 (2020-01)
Intellectual Property Rights
Essential patents
IPRs essential or potentially essential to normative deliverables may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (https://ipr.etsi.org/).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Trademarks
The present document may include trademarks and/or tradenames which are asserted and/or registered by their owners.
ETSI claims no ownership of these except for any which are indicated as being the property of ETSI, and conveys no
right to use or reproduce any trademark and/or tradename. Mention of those trademarks in the present document does
not constitute an endorsement by ETSI of products, services or organizations associated with those trademarks.
Legal Notice
This Technical Specification (TS) has been produced by ETSI 3rd Generation Partnership Project (3GPP).
The present document may refer to technical specifications or reports using their 3GPP identities. These shall be
interpreted as being references to the corresponding ETSI deliverables.
The cross reference between 3GPP and ETSI identities can be found under http://webapp.etsi.org/key/queryform.asp.
Modal verbs terminology
In the present document "shall", "shall not", "should", "should not", "may", "need not", "will", "will not", "can" and
"cannot" are to be interpreted as described in clause 3.2 of the ETSI Drafting Rules (Verbal forms for the expression of
provisions).
"must" and "must not" are NOT allowed in ETSI deliverables except when used in direct citation.
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 3 ETSI TS 128 552 V15.5.0 (2020-01)
Contents
Intellectual Property Rights . 2
Legal Notice . 2
Modal verbs terminology . 2
Foreword . 6
1 Scope . 7
2 References . 7
3 Definitions, abbreviations and measurement family . 8
3.1 Definitions . 8
3.2 Abbreviations . 8
3.4 Measurement family . 8
4 Concepts and overview . 9
5 Performance measurements for 5G Network Functions . 9
5.1 Performance measurements for gNB . 9
5.1.1 Performance measurements valid for all gNB deployment scenarios . 9
5.1.1.1 Packet Delay . 9
5.1.1.1.1 Average delay DL air-interface . 9
5.1.1.2 Radio resource utilization . 9
5.1.1.2.1 DL Total PRB Usage . 9
5.1.1.2.2 UL Total PRB Usage . 10
5.1.1.2.3 Distribution of DL Total PRB Usage . 10
5.1.1.2.4 Distribution of UL Total PRB Usage . 11
5.1.1.3 UE throughput . 11
5.1.1.3.1 Average DL UE throughput in gNB . 11
5.1.1.3.2 Distribution of DL UE throughput in gNB . 12
5.1.1.3.3 Average UL UE throughput in gNB . 14
5.1.1.3.4 Distribution of UL UE throughput in gNB . 15
5.1.1.3.5 Percentage of unrestricted DL UE data volume in gNB . 16
5.1.1.3.6 Percentage of unrestricted UL UE data volume in gNB . 17
5.1.1.4 RRC connection number . 18
5.1.1.4.1 Mean number of RRC Connections . 18
5.1.1.4.2 Max number of RRC Connections . 18
5.1.2 Performance measurements valid only for non-split gNB deployment scenario . 19
5.1.3 Performance measurements valid for split gNB deployment scenario . 19
5.1.3.1 Packet Loss Rate . 19
5.1.3.1.1 UL PDCP SDU Loss Rate . 19
5.1.3.1.2 UL F1-U Packet Loss Rate . 19
5.1.3.1.3 DL F1-U Packet Loss Rate . 20
5.1.3.2 Packet Drop Rate . 20
5.1.3.2.1 DL PDCP SDU Drop rate in gNB-CU-UP . 20
5.1.3.2.2 DL Packet Drop Rate in gNB-DU . 21
5.1.3.3 Packet Delay . 21
5.1.3.3.1 Average delay DL in CU-UP . 21
5.1.3.3.2 Average delay on F1-U . 22
5.1.3.3.3 Average delay DL in gNB-DU . 22
5.1.3.4 IP Latency measurements . 23
5.1.3.4.1 General information . 23
5.1.3.4.2 IP Latency DL in gNB-DU . 23
5.1.3.5 UE Context Release . 23
5.1.3.5.1 UE Context Release Request (gNB-DU initiated) . 23
5.1.3.5.2 Number of UE Context Release Requests (gNB-CU initiated) . 24
5.2 Performance measurements for AMF. 24
5.2.1 Registered subscribers measurement . 24
5.2.1.1 Mean number of registered subscribers. 24
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 4 ETSI TS 128 552 V15.5.0 (2020-01)
5.2.1.2 Maximum number of registered subscribers . 24
5.2.2 Registration procedure related measurements . 25
5.2.2.1 Number of initial registration requests . 25
5.2.2.2 Number of successful initial registrations . 25
5.2.2.3 Number of mobility registration update requests . 26
5.2.2.4 Number of successful mobility registration updates . 26
5.2.2.5 Number of periodic registration update requests. 26
5.2.2.6 Number of successful periodic registration updates . 27
5.2.2.7 Number of emergency registration requests . 27
5.2.2.8 Number of successful emergency registrations . 27
5.3 Performance measurements for SMF . 28
5.3.1 Session Management . 28
5.3.1.1 Number of PDU sessions (Mean) . 28
5.3.1.2 Number of PDU sessions (Maximum) . 28
5.3.1.3 Number of PDU session creation requests . 28
5.3.1.4 Number of successful PDU session creations . 29
5.3.1.5 Number of failed PDU session creations . 29
5.4 Performance measurements for UPF . 30
5.4.1 N3 interface related measurements . 30
5.4.1.1 Number of incoming GTP data packets on the N3 interface, from (R)AN to UPF . 30
5.4.1.2 Number of outgoing GTP data packets of on the N3 interface, from UPF to (R)AN . 30
5.4.1.3 Number of octets of incoming GTP data packets on the N3 interface, from (R)AN to UPF . 30
5.4.1.4 Number of octets of outgoing GTP data packets on the N3 interface, from UPF to (R)AN . 31
5.4.2 N6 related measurements . 31
5.4.2.1 N6 incoming link usage . 31
5.4.2.2 N6 outgoing link usage . 31
5.5 Performance measurements for PCF . 32
5.5.1 AM policy association related measurements . 32
5.5.1.1 Number of AM policy association requests . 32
5.5.1.2 Number of successful AM policy associations . 32
5.5.2 SM policy association related measurements . 32
5.5.2.1 Number of SM policy association requests . 32
5.5.2.2 Number of successful SM policy associations . 33
5.6 Performance measurements for UDM . 33
5.6.1 Mean number of registered subscribers through UDM . 33
5.6.2 Maximum number of registered subscribers through UDM . 34
6 Measurements related to end-to-end 5G network and network slicing . 34
6.1 Void . 34
6.2 Virtualised resource usage measurement . 34
Annex A (informative): Use cases for performance measurements . 35
A.1 Monitoring of UL and DL user plane latency in NG-RAN . 35
A.2 Monitoring of UL and DL packet loss in NG-RAN . 35
A.3 Monitoring of DL packet drop in NG-RAN . 35
A.4 Monitoring of UL and DL user plane delay in NG-RAN. 35
A.5 Monitoring of UE Context Release Request (gNB-DU initiated) . 36
A.6 Monitoring of physical radio resource utilization . 36
A.7 Monitoring of RRC connection number . 36
A.8 Monitoring of UE Context Release . 36
A.9 Monitoring of UE Throughput in NG-RAN . 36
A.10 Monitoring of Unrestricted volume in NG-RAN . 37
A.11 N3 data volume related measurements . 37
A.12 N6 related measurements . 37
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 5 ETSI TS 128 552 V15.5.0 (2020-01)
A.13 Registration related measurements . 37
A.14 PDU session establishment related measurements . 37
A.15 Policy association related measurements . 38
Annex B (informative): Change history . 39
History . 40

ETSI
3GPP TS 28.552 version 15.5.0 Release 15 6 ETSI TS 128 552 V15.5.0 (2020-01)
Foreword
This Technical Specification has been produced by the 3rd Generation Partnership Project (3GPP).
The contents of the present document are subject to continuing work within the TSG and may change following formal
TSG approval. Should the TSG modify the contents of the present document, it will be re-released by the TSG with an
identifying change of release date and an increase in version number as follows:
Version x.y.z
where:
x the first digit:
1 presented to TSG for information;
2 presented to TSG for approval;
3 or greater indicates TSG approved document under change control.
y the second digit is incremented for all changes of substance, i.e. technical enhancements, corrections,
updates, etc.
z the third digit is incremented when editorial only changes have been incorporated in the document.
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 7 ETSI TS 128 552 V15.5.0 (2020-01)
1 Scope
This document specifies the performance measurements for 5G networks including network slicing. Performance
measurements for NG-RAN (clause 5.1) as well as for 5GC (clause 5.2 to 5.6) are defined in this document. Related
KPIs are defined to those measurements in TS 28.554 [8].
The performance measurements for NG-RAN applies also to NR option 3 in many cases, but not to the RRC connection
related measurements which are handled by E-UTRAN for NR option 3 (those are measured according to TS 32.425 [9]
and related KPIs in TS 32.451 [10]).
The performance measurements are defined based on the measurement template as described in TS 32.404 [3].
2 References
The following documents contain provisions which, through reference in this text, constitute provisions of the present
document.
- References are either specific (identified by date of publication, edition number, version number, etc.) or
non-specific.
- For a specific reference, subsequent revisions do not apply.
- For a non-specific reference, the latest version applies. In the case of a reference to a 3GPP document (including
a GSM document), a non-specific reference implicitly refers to the latest version of that document in the same
Release as the present document.
[1] 3GPP TR 21.905: "Vocabulary for 3GPP Specifications".
[2] 3GPP TS 32.401: "Telecommunication management; Performance Management (PM); Concept
and requirements".
[3] 3GPP TS 32.404: "Performance Management (PM); Performance measurements - Definitions and
template".
[4] 3GPP TS 23.501: "System Architecture for the 5G System".
[5] IETF RFC 5136: "Defining Network Capacity".
[6] 3GPP TS 38.473: "NG-RAN; F1 Application Protocol (F1AP)".
[7] 3GPP TS 23.502: "Procedures for the 5G System".
[8] 3GPP TS 28.554: “Management and orchestration; 5G end to end Key Performance Indicators
(KPI)”.
[9] 3GPP TS 32.425: “Performance Management (PM); Performance measurements for Evolved
Universal Terrestrial Radio Access Network (E-UTRAN)”
[10] 3GPP TS 32.451: "Key Performance Indicators (KPI) for Evolved Universal Terrestrial Radio
Access Network (E-UTRAN); Requirements”

ETSI
3GPP TS 28.552 version 15.5.0 Release 15 8 ETSI TS 128 552 V15.5.0 (2020-01)
3 Definitions, abbreviations and measurement family
3.1 Definitions
For the purposes of the present document, the terms and definitions given in 3GPP TR 21.905 [1] and the following
apply. A term defined in the present document takes precedence over the definition of the same term, if any, in 3GPP
TR 21.905 [1].
IP Latency: the time it takes to transfer a first/initial packet in a data burst from one point to another.
Mapped 5QI: In case when a single 5QI is assigned to the DRB, the mapped 5QI refers to the 5QI that is used for a
DRB within the gNB.
NOTE 1: In this case the mapped 5QI is used for separating certain measurements per QoS class.
NOTE 2: Individual QoS flows into a common 5QI is specified in TS 38.473 [6].
Packet Delay: the time it takes to transfer any packet from one point to another.
Packet Drop Rate: share of packets that were not sent to the target due to congestion or traffic management and should
be seen as a part of the packet loss rate.
Packet Loss Rate: share of packets that could not be received by the target including packets droped, packets lost in
transmission and packets received in wrong format.
3.2 Abbreviations
For the purposes of the present document, the abbreviations given in 3GPP TR 21.905 [1], 3GPP TS 23.501 [4] and the
following apply. An abbreviation defined in the present document takes precedence over the definition of the same
abbreviation, if any, in 3GPP TR 21.905 [1] and 3GPP TS 23.501 [4].
kbit kilobit (1000 bits)
NG-RAN Next Generation Radio Access Network
NSI Network Slice Instance
3.4 Measurement family
The measurement names defined in the present document are all beginning with a prefix containing the measurement
family name. This family name identifies all measurements which relate to a given functionality and it may be used for
measurement administration.
The list of families currently used in the present document is as follows:
- DRB (measurements related to Data Radio Bearer)
- RRC (measurements related to Radio Resource Control)
- UECNTX (measurements related to UE Context)
- RRU (measurements related to Radio Resource Utilization)
- RM (measurements related to Registration Management)
- SM (measurements related to Session Management)
- GTP (measurements related to GTP Management)
- IP (measurements related to IP Management)
- PA (measurements related to Policy Association)
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 9 ETSI TS 128 552 V15.5.0 (2020-01)
4 Concepts and overview
5 Performance measurements for 5G Network
Functions
5.1 Performance measurements for gNB
5.1.1 Performance measurements valid for all gNB deployment scenarios
5.1.1.1 Packet Delay
5.1.1.1.1 Average delay DL air-interface
a) This measurement provides the average (arithmetic mean) time it takes to get a reponse back on a HARQ
transmission in the downlink direction. The measurement is optionally split into subcounters per QoS level
(mapped 5QI or QCI in NR option 3).
b) DER (n=1)
c) This measurement is obtained as: sum of (time when the last part of an RLC SDU packet was received by the UE
according to received HARQ feedback information for UM mode or time when the last part of an RLC SDU
packet was received by the UE according to received RLC ACK for AM mode, minus time when corresponding
RLC SDUs arriving at MAC lower SAP) divided by total number of RLC SDUs transmitted to UE successfully.
Separate counters are optionally maintained for each mapped 5QI (or QCI for option 3).
d) Each measurement is an integer representing the mean delay in microseconds. The number of measurements is
equal to one. If the optional QoS level measurement is perfomed, the number of measurements is equal to the
number of mapped 5QIs.
e) The measurement name has the form DRB.AirIfDelayDl or optionally DRB. AirIfDelayDl.QOS, where QOS
identifies the target quality of service class.
f) NRCellDU
g) Valid for packet switched traffic
h) 5GS
i) One usage of this measurement is for performance assurance within integrity area (user plane connection
quality).
5.1.1.2 Radio resource utilization
5.1.1.2.1 DL Total PRB Usage
a) This measurement provides the total usage (in percentage) of physical resource blocks (PRBs) on the downlink
for any purpose.
b) SI
M1(T) 
c) This measurement is obtained as: M (T) = ∗100 , where M (T ) is the DL total PRB usage, which
 
P(T)
 
is percentage of PRBs used, averaged during time period T with value range: 0-100%; M1(T ) is a count of
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 10 ETSI TS 128 552 V15.5.0 (2020-01)
full physical resource blocks and all PRBs used for DL traffic transmission shall be included; P(T ) is total
number of PRBs available for DL traffic transmission during time period T ; and T is the time period during
which the measurement is performed.
d) A single integer value from 0 to 100.
e) RRU.PrbTotDl, which indicates the DL PRB Usage for all traffic
f) NRCellDU
g) Valid for packet switched traffic
h) 5GS
i) One usage of this measurement is for monitoring the load of the radio physical layer.
5.1.1.2.2 UL Total PRB Usage
a) This measurement provides the total usage (in percentage) of physical resource blocks (PRBs) on the uplink for
any purpose.
b) SI
 
M1(T)
c) This measurement is obtained as: M (T) = ∗100 , where M (T ) is the UL total PRB usage, which
 
P(T)
 
is percentage of PRBs used, averaged during time period T with value range: 0-100%; M1(T ) is a count of
full physical resource blocks and all PRBs used for UL traffic transmission shall be included; P(T ) is total
number of PRBs available for UL traffic transmission during time period ; and is the time period during
T T
which the measurement is performed
d) A single integer value from 0 to 100.
e) RRU.PrbTotUl, which indicates the UL PRB Usage for all traffic
f) NRCellDU
g) Valid for packet switched traffic
h) 5GS
i) One usage of this measurement is for monitoring the load of the radio physical layer.
5.1.1.2.3 Distribution of DL Total PRB Usage
a) This measurement provides the distribution of samples with total usage (in percentage) of physical resource
blocks (PRBs) on the downlink in different ranges. This measurement is a useful measure of whether a cell is
under high loads or not in the scenario which a cell in the downlink may experience high load in certain short
times (e.g. in a second) and recover to normal very quickly.
b) CC
� �
c) Each measurement sample is obtained as: � � = � ∗ 100�, where �� is total PRB usage at sample

� �
n for DL, which is a percentage of PRBs used, averaged during time period t with value range: 0-100%; �1 �
n
is a count of full physical resource blocks and all PRBs used for DL traffic transmission shall be
included; �� is the total number of PRBs available for DL traffic transmission during time period t and n is
n
the sample with time period t during which the measurement is performed.
n
Distribution of total PRB usage is calculated in the time-frequency domain only. The reference point is the
Service Access Point between MAC and L1. The distribution of PRB usage provides the histogram result of the
samples collected during time period T.
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 11 ETSI TS 128 552 V15.5.0 (2020-01)
Depending on the value of the sample, the proper bin of the counter is increased. The number of samples during
one measurement period is provided by the operator.
d) A set of integers. Each representing the (integer) number of samples with a DL total PRB percentage usage in
the range represented by that bin.
e) RRU.PrbTotDlDist.BinX, which indicates the distribution of DL PRB Usage for all traffic.
f) NRCellDU
g) Valid for packet switched traffic
h) 5GS
i) One usage of this measurement is for monitoring the load of the radio physical layer.
5.1.1.2.4 Distribution of UL Total PRB Usage
a) This measurement provides the distribution of samples with total usage (in percentage) of physical resource
blocks (PRBs) on the uplink in different usage ranges. This measurement is a useful measure of whether a cell is
under high loads or not in the scenario which a cell in the uplink may experience high load in certain short times
(e.g. in a second) and recover to normal very quickly.
b) CC
� �
c) Each measurement sample is obtained as: � � = � ∗ 100�, where �� is total PRB usage at sample

n for UL, which is a percentage of PRBs used, averaged during time period t with value range: 0-100%; �1���
n
is a count of full physical resource blocks and all PRBs used for UL traffic transmission shall be
included; �� is the total number of PRBs available for UL traffic transmission during time period t and n is
n
the sample with time period t during which the measurement is performed.
n
Distribution of total PRB usage is calculated in the time-frequency domain only. The reference point is the
Service Access Point between MAC and L1. The distribution of PRB usage provides the histogram result of the
samples collected during time period T.
Depending on the value of the sample, the proper bin of the counter is increased. The number of samples during
one measurement period is provided by the operator.
d) A set of integers, each representing the (integer) number of samples with a UL PRB percentage usage in the
range represented by that bin.
e) RRU.PrbTotUlDist.BinX, which indicates the distribution of UL PRB Usage for all traffic.
f) NRCellDU
g) Valid for packet switched traffic
h) 5GS
i) One usage of this measurement is for monitoring the load of the radio physical layer.
5.1.1.3 UE throughput
5.1.1.3.1 Average DL UE throughput in gNB
a) This measurement provides the average UE throughput in downlink. This measurement is intended for data
bursts that are large enough to require transmissions to be split across multiple slots. The UE data volume refers
to the total volume scheduled for each UE regardless if using only primary- or also supplemental aggregated
carriers. The measurement is optionally split into subcounters per QoS level (mapped 5QI or QCI in NR option
3).
b) DER(N=1)
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 12 ETSI TS 128 552 V15.5.0 (2020-01)
c) This measurement is obtained according to the following formula based on the “ThpVolDl” and “ThpTimeDl”
defined below. It is optionally split into subcounters for each QoS level.

∑∑
If ∑∑ℎ>0, ×1000 [kbit/s]
∑∑
If ∑∑ℎ=0, 0 [kbit/s]
For small data bursts, where all buffered data is included in one initial HARQ transmission, ThpTimeDl = 0 ,
otherwise ThpTimeDl =T1− T 2[]ms

The time to transmit a data burst excluding the data
transmitted in the slot when the buffer is emptied. A sample
ThpTimeDl
of "ThpTimeDl" for each time the DL buffer for one
DataRadioBearer (DRB) is emptied.
The point in time after T2 when data up until the second last
piece of data in the transmitted data burst which emptied
the RLC SDU available for transmission for the particular
T1
DRB was successfully transmitted, as acknowledged by the
UE.
The point in time when the first transmission begins after a
RLC SDU becomes available for transmission, where
T 2
previously no RLC SDUs were available for transmission
for the particular DRB.
The RLC level volume of a data burst, excluding the data
transmitted in the slot when the buffer is emptied. A sample
for ThpVolDl is the data volume, counted on RLC SDU
ThpVolDl level, in kbits successfully transmitted (acknowledged by
UE) in DL for one DRB during a sample of ThpTimeDl. (It
shall exclude the volume of the last piece of data emptying
the buffer).
d) Each measurement is a real value representing the throughput in kbits per second. The number of measurements
is equal to one. If the optional QoS level measurement is perfomed, the number of measurements is equal to the
number of mapped 5QIs.
e) The measurement name has the form
DRB.UEThpDl, or optionally DRB.UEThpDl.QOS, where QOS identifies the target quality of service class.
f) NRCellDU
g) Valid for packet switched traffic
h) 5GS
i) One usage of this measurement is for performance assurance within integrity area (user plane connection
quality).
5.1.1.3.2 Distribution of DL UE throughput in gNB
a) This measurement provides the distribution of the UE throughput in downlink. This measurement is intended for
data bursts that are large enough to require transmissions to be split across multiple slots. The UE data volume
refers to the total volume scheduled for each UE regardless if using only primary- or also supplemental
aggregated carriers.
b) CC
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 13 ETSI TS 128 552 V15.5.0 (2020-01)
c) Considering there are n samples during measurement time T and each sample has the same time period tn, the
measurement of one sample is obtained by the following formula for a measurement period tn:

∑∑
If ∑∑ℎ>0, ×1000 [kbit/s]
∑∑
If ∑∑ℎ=0, 0 [kbit/s]
For small data bursts, where all buffered data is included in one initial HARQ transmission, ThpTimeDl = 0 ,
otherwise ThpTimeDl=T1−T 2[]ms

The time to transmit a data burst excluding the data
transmitted in the slot when the buffer is emptied. A sample
ThpTimeDl
of "ThpTimeDl" for each time the DL buffer for one
DataRadioBearer (DRB) is emptied.
The point in time after T2 when data up until the second last
piece of data in the transmitted data burst which emptied
the RLC SDU available for transmission for the particular
T1
DRB was successfully transmitted, as acknowledged by the
UE.
The point in time when the first transmission begins after a
RLC SDU becomes available for transmission, where
T 2
previously no RLC SDUs were available for transmission
for the particular DRB.
The RLC level volume of a data burst, excluding the data
transmitted in the slot when the buffer is emptied. A sample
for ThpVolDl is the data volume, counted on RLC SDU
ThpVolDl level, in kbits successfully transmitted (acknowledged by
UE) in DL for one DRB during a sample of ThpTimeDl. (It
shall exclude the volume of the last piece of data emptying
the buffer).
Alternatively, for small data bursts, that are successfully transmitted in any given slot (i.e. the requirement that
data bursts need to span across several slots excluding transmission of the last piece of the data in a data burst
does not apply). where all buffered data is included in one initial HARQ transmission, fraction of the slot
time (ℎ) may be counted and obtained by the formula:

()TBVol − PaddingVol
ThpTimeDl = slot × []ms
TBVol
slot Duration of the slot
TBVol Volume of the TB related to one slot burst
Volume of padding bits added into Transport Block related
PaddingVol
to one slot burst.
For each measurement sample, the bin corresponding to the DL throughput experienced by the UE is
incremented by one.
d) A set of integers, each representing the (integer) number of samples with a DL UE throughput in the range
represented by that bin.
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 14 ETSI TS 128 552 V15.5.0 (2020-01)
e) The measurement name has the form
DRB.UEThpDlDist.BinX where BinX represents the bin.
NOTE: Number of bins and the range for each bin is left to implementation
f) NRCellDU
g) Valid for packet switched traffic
h) 5GS
i) One usage of this measurement is for performance assurance within integrity area (user plane connection
quality).
5.1.1.3.3 Average UL UE throughput in gNB
a) This measurement provides the average UE throughput in uplink. This measurement is intended for data bursts
that are large enough to require transmissions to be split across multiple slots. The UE data volume refers to the
total volume scheduled for each UE regardless if using only primary- or also supplemental aggregated carriers.
The measurement is optionally split into subcounters per QoS level (mapped 5QI or QCI in NR option 3).
b) DER(N=1)
c) This measurement is obtained according to the following formula based on the “ThpVolUl” and “ThpTimeUl”
defined below. It is optionally split into subcounters for each QoS level.

∑∑
∑∑ℎ>0, ×1000 [kbit/s]
If
∑∑
If ∑∑ℎ=0, 0 [kbit/s]
For small data bursts, where all buffered data is included in one initial HARQ transmission ThpTimeUl = 0
otherwise:
ThpTimeUl =T1− T 2[]ms
The time to transmit a data burst excluding the data
transmitted in the slot when the buffer is emptied. A sample
ThpTimeUl
of "ThpTimeUl" for each time the UL buffer for one
DataRadioBearer (DRB) is emptied.
The point in time when the data up until the second last
piece of data in data burst has been successfully received
T1
for a particular DRB
The point in time when transmission is started for the first
T 2
data in data burst for a particular DRB.
The RLC level volume of a data burst, excluding the data
transmitted in the slot when the buffer is emptied. A sample
for ThpVolUl is the data volume counted on RLC SDU level
ThpVolUl
in kbits received in UL for one DRB during a sample of
ThpTimeUl, (It shall exclude the volume of the last piece of
data emptying the buffer).
d) Each measurement is a real value representing the throughput in kbits per second. The number of measurements
is equal to one. If the optional QoS level measurement is perfomed, the number of measurements is equal to the
number of mapped 5QIs.
e) The measurement name has the form
DRB.UEThpUl, or optionally DRB.UEThpUl.QOS, where QOS identifies the target quality of service class.
f) NRCellDU
g) Valid for packet switched traffic
ETSI
3GPP TS 28.552 version 15.5.0 Release 15 15 ETSI TS 128 552 V15.5.0 (2020-01)
h) 5GS
i) One usage of this measurement is for performance assurance within integrity area (user plane connection
quality).
5.1.1.3.4 Distribution of UL UE throughput in gNB
a) This measurement provides the distribution of the UE throughput in uplink. This measurement is intended for
data bursts that are large enough to require transmissions to be split across multiple slots. The UE data volume
refers to the total volume scheduled for each UE regardless if using only primary- or also supplemental
aggregated carriers.
b) CC
c) Considering there are n samples during measurement time T and each sample has the same time period tn,
the measurement of one sample is obtained by the following formula for a measurement period tn:

∑∑
If ∑∑ℎ >0, ×1000 [kbit/s]
∑∑
If ∑∑ℎ =0, 0 [kbit/s]
For small data bursts, where all buffered data is included in one initial HARQ transmission ThpTimeUl = 0
otherwise:
ThpTimeUl =T1− T 2[]ms
The time to transmit a data burst excluding the data
transmitted in the slot when the buffer is emptied. A sample
ThpTimeUl
of "ThpTimeUl" for each time the UL buffer for one
DataRadioBearer (DRB) is emptied.
The point in time when the data up until the second last
T1 piece of data in data burst has been successfully received
for a particular DRB
The point in time when transmission is started for the first
T2
data in data burst for a particular DRB.
The RLC level volume of a data burst, excluding the data
transmitted in the slot when the buffer is emptied. A sample
for ThpVolUl is the data volume counted on RLC SDU level
ThpVolUL
in kbits received in UL for one DRB during a sample of
ThpTimeUl, (It shall exclude the volume of the last piece of
data emptying the buffer).
Alternatively, for small data bursts, that are successfully transmitted in any given slot (i.e. the requirement that
data bursts need to span across several slots excluding transmission of the last piece of the data in a data burst
does not apply). where all buffered data is included in one initial HARQ transmission, fraction of the slot
time (ℎ) may be counted and obtained by the formula:

()TBVol − PaddingVol
ThpTimeUl = slot
...
