IEC 60099-5:2013
(Main)Surge arresters - Part 5: Selection and application recommendations
Surge arresters - Part 5: Selection and application recommendations
IEC 60099-5:2013 is not a mandatory standard but provides information, guidance, and recommendations for the selection and application of surge arresters to be used in three-phase systems with nominal voltages above 1 kV. It applies to gapless metal-oxide surge arresters as defined in IEC 60099-4, to surge arresters containing both series and parallel gapped structure - rated 52 kV and less as defined in IEC 60099-6 and metal-oxide surge arresters with external series gap for overhead transmission and distribution lines (EGLA) as defined in IEC 60099-8. In Annex H, some aspects regarding the old type of SiC gapped arresters are discussed. This second edition cancels and replaces the first edition published in 1996 and its amendment 1 published in 1999. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- Expanded discussion of different types of arresters and their application, including additions of discussion on transmission of line arresters, arresters for shunt capacitor switching arresters for series capacitor protection, application of arresters between phases connecting arresters in parallel;
- Addition of section on asset management, including: managing surge arresters in the power grid, arrester maintenance, significantly expanded discussion of performance diagnostic tools, end-of-life considerations;
- New annexes dealing with: arrester modelling for system studies, example of data needed for specifying arresters. Key words: selection and application of surge arrestors, nominal voltages above 1 kV
Parafoudres - Partie 5: Recommandations pour le choix et l'utilisation
IEC 60099-5:2013 n’est pas une norme obligatoire, mais comporte des informations, un guide et autres recommandations pour le choix et l'utilisation des parafoudres à utiliser sur des réseaux triphasés de tensions nominales supérieures à 1 kV. Elle concerne les parafoudres à oxyde métallique sans éclateur définis dans l’IEC 60099-4, les parafoudres contenant des structures avec éclateur en série et en parallèle – de tension assignée inférieure ou égale à 52 kV tels que définis dans l’IEC 60099-6 et les parafoudres à oxyde métallique à éclateur extérieur en série pour les lignes aériennes de transmission ou de distribution (EGLA) tels que définis dans l’IEC 60099-8. L’Annexe H traite de quelques aspects concernant les anciens parafoudres au carbure de silicium (SiC) avec éclateur. Cette deuxième édition annule et remplace la première édition parue en 1996, et son amendement 1 paru en 1999. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
-Présentation élargie des différents types de parafoudres et de leur utilisation, y compris des éléments de présentation supplémentaires concernant: la transmission des parafoudres de ligne, les parafoudres pour manœuvre de condensateurs dérivés, les parafoudres pour la protection des condensateurs série, l’utilisation de parafoudres entre phases, la connexion de parafoudres en parallèle;
-Ajout d’une section relative à la gestion des biens, y compris: la gestion des parafoudres dans un réseau électrique, la maintenance des parafoudres, une présentation très élargie des outils de diagnostic des performances, les considérations relatives à la fin de vie;
- Nouvelles annexes portant sur: la modélisation des parafoudres pour les études de réseau, un exemple de données nécessaires pour la spécification des parafoudres.
