IEC 61158-6-2:2014

Industrial communication networks - Fieldbus specifications - Part 6-2: Application layer protocol specification - Type 2 elements

IEC 61158-6-2:2014 defines the protocol provided to define the wire-representation of the service primitives defined in IEC 61158-5-2, and define the externally visible behavior associated with their transfer. This standard specifies the protocol of the Type 2 fieldbus application layer, in conformance with the OSI Basic Reference Model (ISO/IEC 7498-1) and the OSI application layer structure (ISO/IEC 9545). This third edition cancels and replaces the second edition published in 2010 and constitutes a technical revision. The main changes are:
- Updates of definition used by the Time Sync object;
- Addition of "member" and object specific services in 4.1.2.1, 4.1.8, 4.1.10, 8.2;
- Removal of obsolete transport classes 4 to 6 in 4.1.4.6, and 9.3.9 to 9.3.12;
- Clarification of transport header formats in 4.1.4;
- Update of CM and MR PDUs in 4.1.5 to 4.1.7;
- Updates of Identity object PDUs in 4.1.8.2;
- Updates of Assembly object PDUs in 4.1.8.4;
- Updates of Time sync object PDUs in 4.1.8.6;
- Updates of Parameter object PDUs in 4.1.8.7;
- Updates of Connection Manager object PDUs in 4.1.8.8;
- Updates of message and connection paths in 4.1.9;
- Updates of object class codes in 4.1.10 and error codes in 4.1.11;
- Updates of data types in 4.2.4 and 5.2.3;
- Updates of the encapsulation abstract syntax in 4.3;
- Updates to the DLL mapping protocol machine 2 in Clause 11.

Réseaux de communication industriels - Spécifications des bus de terrain - Partie 6-2: Spécification du protocole de la couche application - Eléments de type 2

L'IEC 61158-6-2:2014 décrit le protocole mis en place pour définir la représentation filaire des primitives de service définies dans la CEI 61158-5-2 et définir le comportement visible de l'extérieur associé à leur transfert. La présente norme spécifie le protocole de la couche application de bus de terrain de Type 2, en conformité avec le modèle de référence de base OSI (ISO/CEI 7498-1) et la structure de la couche application OSI (ISO/CEI 9545). Cette troisième édition annule et remplace la deuxième édition parue en 2010. Elle constitue une révision technique. Les principales modifications par rapport à l'édition précédente sont les suivantes:
- mise à jour des définitions utilisées par l'objet Time Sync;
- ajout de "membre" et des services spécifiques à un objet en 4.1.2.1, 4.1.8, 4.1.10, 8.2;
- suppression des classes de transport obsolètes 4 à 6 en 4.1.4.6 et de 9.3.9 à 9.3.12;
- clarification des formats d'en-tête de transport en 4.1.4;
- mise à jour du CM et des PDU de MR de 4.1.5 à 4.1.7;
- mise à jour des PDU de l'objet Identity en 4.1.8.2;
- mise à jour des PDU de l'objet Assembly en 4.1.8.4;
- mise à jour des PDU de l'objet Time Sync en 4.1.8.6;
- mise à jour des PDU de l'objet Parameter en 4.1.8.7;
- mise à jour des PDU de l'objet Connection Manager en 4.1.8.8;
- mise à jour des chemins de message et de connexion en 4.1.9;
- mise à jour des codes de classe d'objet en 4.1.10 et des codes d'erreur en 4.1.11;
- mise à jour des types de données en 4.2.4 et 5.2.3;
- mise à jour de la syntaxe abstraite d'encapsulation en 4.3;
- mise à jour du diagramme protocolaire de mapping DLL 2 à l'Article 11.

General Information

• Status: Published
• Publication Date: 18-Aug-2014
• ICS: 25.040.40 - Industrial process measurement and control
• ICS: 35.100.70 - Application layer
• ICS: 35.110 - Networking
• Technical Committee: SC 65C - Industrial networks
• Current Stage: DELPUB - Deleted Publication
• Start Date: 20-Jun-2019
• Completion Date: 26-Oct-2025

Relations

• Revises: IEC 61158-6-2:2010 - Industrial communication networks - Fieldbus specifications - Part 6-2: Application layer protocol specification - Type 2 elements
• Effective Date: 05-Sep-2023
• Revised: IEC 61158-6-2:2019 - Industrial communication networks - Fieldbus specifications - Part 6-2: Application layer protocol specification - Type 2 elements
• Effective Date: 05-Sep-2023
