This model of an energy management system for residences extends the set of HES (Home
Electronic System) application models. Models for lighting and security have already been
developed and accepted. These models should facilitate the validation of the language
specified for HES in ISO/IEC 15067-1.
These models have been developed to foster interoperability among products from competing
or complementary manufacturers. Product interoperability is essential when using home
control standards, such as HES. This document defines a typical security system and
describes the communications services needed. A high-level model for an energy
management system using HES is presented.
ISO and IEC would appreciate comments by developers of energy management systems
regarding possible enhancements to this model.
– 6 – TR 15067-3 © ISO/IEC:2000(E)
INFORMATION TECHNOLOGY –
HOME ELECTRONIC SYSTEM (HES) APPLICATION MODEL –
Part 3: Model of an energy management system for HES
1 Scope
The model for energy management presented in this Technical Report is generic and
representative of a wide range of situations. Since one model cannot be completely
comprehensive other models or operating modes may be more appropriate for certain
applications.
This model for energy management accommodates a range of load control strategies.
Examples of implementations that could be described with this model include:
– the CELECT Intelligent Load Management System in the United Kingdom. The utility
transmits electricity cost data and forecasted outdoor air temperatures to residential
heater controllers;
– the “bleu, blanc, rouge” technique used by Electricité de France to announce price tiers
one day in advance. The tier signal is displayed using a blue, white or red light to alert the
customer;
– real-time pricing experiments by Consolidated Edison of New York and by Pacific Gas and
Electric, both in the United States.
2 Reference documents
ISO/IEC 15067-1: Information technology – Home Electronic System (HES) Application Model
– Part 1: Application Services and Protocol (under consideration)
3 Abbreviations
DSM Demand-Side Management
EPRI Electric Power Research Institute (Palo Alto, California, U.S.A.)
4 Evolution of energy management
Electricity consumption patterns have high peaks. During weather extremes of heat and cold
the demand for electricity rises sharply. In the United States the average rate of power
generation is only about 46 % of the peak generation that occurs during these situations.
Ideally, the utilities would like to maintain the supply of electricity sufficiently high to meet any
demand. This has been achieved in some regions of developed countries. However, this is
becoming less practical because of public pressure and government rules. Therefore, utilities
have developed many methods of Demand-Side Management (DSM) for influencing the
demand to match the available supply.
DSM tools enable utilities to modify the cumulative demand for energy, known as the load
shape when plotted over a one-day interval. Utilities have developed a variety of DSM
programs to manipulate the load shape. Different programs have different load shape goals,
with the majority intended for peak clipping.
TR 15067-3 © ISO/IEC:2000(E) – 7 –
DSM programs initially focused on providing incentives for using electricity more efficiently.
Customer cooperation may be obtained by offering a financial incentive, such as an up-front
rebate, a loan guarantee, a lower rate for electricity, or free energy efficient planning and
evaluation services. Some programs offer rebates for switching from tungsten to fluorescent
lights, for adding building insulation, and for purchasing energy efficient appliances.
Utilities have developed more deterministic methods for influencing the demand through load
control. The more innovative methods of load control depend on market forces for exerting
control by varying the price of electricity. In the United States, almost 20 million customers out
of a total of 130 million participate in some DSM program. About 30 % of these programs are
load control.
5 Load control
5.1 Responding to pricing
In North America electricity traditionally has been sold at a flat rate or a volume-sensitive rate.
New pricing schemes are adding time as a factor. Time-of-use rates vary the price according
to the time of day. Typically, on-peak and off-peak rates are announced. The hours for each
rate are fixed for each day, or at least for work days, similar to telephone rates. Rates that
change dynamically with one-day or even no advance notice constitute real-time pricing.
Most load control programs by utilities have been limited to local control and direct control.
However, the most innovative load control uses a combination called distributed control.
These varieties of DSM help users respond effectively to utility price variations.
5.2 Local control
The utility publishes an electricity tariff that has between two and four different rates
depending on the time of day. Customers with time-of-use pricing for electricity are
encouraged to operate heavy power consuming appliances at off peak pricing times. In order
to maximize the savings, the customer must know the rates, know the power requirements of
the appliance, and know the cost of operating the appliance. Then the customer can decide if
it is convenient to defer the operation or spend the money during the peak cost time.
A few utilities have instituted a tariff that discourages a peak load. The consumer pays a
special charge called a demand charge if the total electricity con
...
