IEC 62475:2010

High-current test techniques - Definitions and requirements for test currents and measuring systems

IEC 62475:2010 is applicable to high-current testing and measurements on both high-voltage and low-voltage equipment. It deals with steady-state and short-time direct current (as e.g. encountered in high-power d.c. testing), steady-state and short-time alternating current (as e.g. encountered in high-power a.c. testing), and impulse-current. In general, currents above 100 A are considered in this International Standard, although currents less than this can occur in tests. This standard also covers fault detection during, for example, lightning impulse testing.

Techniques des essais à haute intensité - Définitions et exigences relatives aux courants d'essai et systèmes de mesure

La CEI 62475:2010 s'applique aux essais et mesures à haute intensité sur des matériels haute et basse tensions. Elle couvre les essais à haute intensité en courant continu et courant alternatif en régime établi et de courte durée ainsi que des essais de courant de choc. De manière générale, la présente Norme internationale prend en compte des courants de plus de 100 A, même si des intensités moindres peuvent apparaître dans les essais. La présente norme couvre également la détection de défauts, comme par exemple dans le cadre d'essais aux chocs de foudre.

General Information

• Status: Published
• Publication Date: 28-Sep-2010
• ICS: 19.080 - Electrical and electronic testing
• Technical Committee: TC 42 - High-voltage and high-current test techniques
• Drafting Committee: MT 12 - TC 42/MT 12
• Current Stage: PPUB - Publication issued
• Start Date: 29-Sep-2010
• Completion Date: 31-Oct-2010

Overview

The IEC 62475:2010 standard, titled "High-current test techniques - Definitions and requirements for test currents and measuring systems", provides comprehensive guidelines for performing high-current testing and measurement in electrical equipment. This International Electrotechnical Commission (IEC) standard applies to both high-voltage and low-voltage equipment, covering steady-state and short-time direct current (DC), steady-state and short-time alternating current (AC), as well as impulse current tests.

Designed for currents generally above 100 A, IEC 62475:2010 also accommodates currents below this threshold in specific test scenarios. Additionally, the standard addresses fault detection, such as during lightning impulse testing, ensuring reliable and accurate measurement and testing practices across various electrical industries.

Key Topics

IEC 62475:2010 encompasses a range of critical subjects within the domain of high-current testing:

• Definitions and Terminology: Clear terms related to measuring systems, scale factors, rated values, dynamic behavior, uncertainty, and specific test scenarios are rigorously defined to ensure common understanding.

• Measuring Systems:

  • Components, calibration methods, linearity assessments, and dynamic behavior are outlined to qualify and use measuring systems effectively.
  • Special focus is given to stability (short-term and long-term), temperature effects, and interference impacts on measurement accuracy.

• Test Current Specifications:

  • Requirements and tolerances for different types of currents including steady-state DC/AC, short-time DC/AC, and impulse currents are detailed.
  • The standard prescribes procedures for measuring these currents with approved measurement systems, accounting for uncertainty and dynamic effects.

• Fault Detection and Withstand Tests:

  • Guidelines for identifying faults during high-current testing, including those due to lightning impulse phenomena.
  • Voltage and current withstand testing requirements ensure equipment safety and durability.

• Uncertainty and Performance Evaluation:

  • Procedures for uncertainty calculations in various measurement contexts, including time-parameter measurements for impulse currents.
  • Schedules for performance tests, routine checks, and record-keeping of measuring system data.

Applications

IEC 62475:2010 is essential for professionals involved in high-current testing across multiple sectors:

• Electrical Equipment Manufacturers: Ensure compliance with standardized testing conditions, enhancing product reliability and certification readiness.

• High-Voltage and Low-Voltage Testing Laboratories: Implement calibrated and validated measurement systems based on globally accepted protocols, improving test accuracy.

• Power Generation and Distribution Utilities: Perform safe and accurate testing on transformers, switchgear, and circuit breakers subjected to high current conditions.

• Quality Assurance and Compliance Teams: Maintain records of performance and calibrations, demonstrate consistent uncertainty management, and comply with regulatory requirements.

• Research and Development: Apply standardized high-current test techniques for validating new electrical components and technologies involving high-power current loads.

Related Standards

Professionals working with IEC 62475:2010 should consider these related standards for a broader technical framework:

• IEC 60060 series – High-voltage test techniques covering voltage testing methods complementing current tests.

• IEC 61242 – For design and performance requirements of measuring current transformers.

• IEC 61000 series – Electromagnetic compatibility (EMC) testing, encompassing interference considerations relevant to measurement systems.

• IEC 60529 – Degrees of protection provided by enclosures important during high-current testing conditions.

Conclusion

IEC 62475:2010 sets a rigorous foundation for high-current test techniques, defining essential requirements for test currents and measuring systems. By following this standard, industries can achieve consistent, accurate, and reliable testing and measurement outcomes, ensuring electric equipment safety, performance, and compliance with international benchmarks. The standard’s detailed approach to uncertainty, dynamic behavior, and fault detection makes it a critical resource for high-current testing in modern electrical engineering applications.
