IEC 61003-2:2016

Industrial-process control systems - Instruments with analogue inputs and two- or multi-position outputs - Part 2: Guidance for inspection and routine testing

IEC 61003-2:2016 gives guidelines for inspection and routine testing of electrical and pneumatic instruments with two- or multi-position output, for instance, for acceptance tests or after repair. It is applicable to electrical and pneumatic industrial-process instruments, using measured values that are continuous signals. The set point value may be either a mechanical (position, force, etc.) or a standard signal. These instruments may be used as controllers or as switches for alarms and other similar purposes. This second edition cancels and replaces the first edition published in 2009. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- use of the term "two- or multi-position output" instead of "two- or multi-state instrument" (see Scope);
- use of the term "differential gap" instead of "switching differential" (see Table 1 No 2);
- use of the term "dielectric strength" instead of "isolation test" (see Table 1 No 5).
This publication is to be read in conjunction with IEC 61003-1:2016, IEC 61298-2:2008 and IEC 61298-3:2008

Système de commande de processus industriels - Instruments avec entrées analogiques et sorties à deux ou plusieurs positions - Partie 2: Conseils pour les inspections et les essais individuels de série

L'IEC 61003-2:2016 donne des lignes directrices pour les inspections et les essais individuels de série des instruments électriques et pneumatiques à sorties à deux ou plusieurs positions, par exemple pour les essais de réception ou après réparation. Elle est applicable aux instruments électriques et pneumatiques des processus industriels, utilisant des valeurs mesurées qui sont des signaux continus. La valeur de consigne peut être soit un signal mécanique (position, force, etc.) soit un signal normalisé. Ces instruments peuvent être utilisés comme régulateurs ou comme interrupteurs pour systèmes d'alarme et autres usages similaires. Cette deuxième édition annule et remplace la première édition parue en 2009. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
- utilisation du terme "sortie à deux ou plusieurs positions" au lieu de "instrument à deux ou plusieurs états" (voir Domaine d'application);
- utilisation du terme "recouvrement" au lieu de "différentiel de coupure" (voir Tableau 1, n° 2);
- utilisation du terme "rigidité diélectrique" au lieu d'"essai d'isolation" (voir Tableau 1 n° 5).
Cette publication doit être lue conjointement avec la IEC 61003-1:2016, IEC 61298-2:2008 et IEC 61298-3:2008.

General Information

• Status: Published
• Publication Date: 13-Jun-2016
• ICS: 01 - GENERALITIES. TERMINOLOGY. STANDARDIZATION. DOCUMENTATION
• ICS: 25.040.40 - Industrial process measurement and control
• Technical Committee: SC 65B - Measurement and control devices
• Drafting Committee: WG 6 - TC 65/SC 65B/WG 6
• Current Stage: PPUB - Publication issued
• Start Date: 14-Jun-2016
• Completion Date: 30-Jun-2016

Relations

• Revises: IEC 61003-2:2009 - Industrial-process control systems - Instruments with analogue inputs and two or multi-state outputs - Part 2: Guidance for inspection and routine testing
• Effective Date: 05-Sep-2023

IEC 61003-2:2016 Overview

IEC 61003-2:2016 is an international standard developed by the International Electrotechnical Commission (IEC) that provides comprehensive guidance for the inspection and routine testing of industrial-process control instruments. This second edition, published in 2016, supersedes the 2009 edition, introducing updated terminology and technical revisions to enhance clarity and operational relevance.

This standard specifically addresses electrical and pneumatic instruments with analogue inputs and two- or multi-position outputs. It covers testing methods used for acceptance testing, routine inspections, and post-repair qualifications. The instruments in question process continuous measured values and serve as controllers or switches, including applications such as alarms in industrial scenarios.

Key Topics and Terminology

IEC 61003-2:2016 lays out essential test procedures and environmental conditions with the aim to verify proper instrument performance under defined conditions. Notable improvements over the previous edition include:

• Use of the term "two- or multi-position output" instead of "two- or multi-state instrument" for accuracy in describing output characteristics.
• The term "differential gap" replaces "switching differential" to correctly reference the measurement in performance testing.
• Adoption of "dielectric strength" in place of "isolation test" to better describe electric insulation testing specifics.

Core Testing Areas

• Inaccuracy of switching points – assessing deviation from set values.
• Inaccuracy of differential gap – verifying precision in output change points.
• Set point evaluation – checking adjustability and indication capability.
• Dielectric strength – testing the insulation to prevent electrical failure.
• Characteristics of multi-position outputs – ensuring reliable switching over multiple positions.
• Supply variations – evaluating device response under varying electrical voltage or pneumatic pressure.

Standardized Test Conditions

The testing environment adheres to well-defined parameters for accuracy and reproducibility:

• Ambient temperature between 15 °C and 25 °C.
• Relative humidity from 45% to 75%.
• Atmospheric pressure between 86 kPa and 106 kPa.
• Electrical supply stability with voltage and frequency variations within ±1%.
• Pneumatic supply maintained within ±3% of rated pressure.

Applications of IEC 61003-2

This standard is critical for manufacturers, users, and quality assurance professionals involved in industrial-process control systems. It supports:

• Acceptance testing – confirming newly manufactured instruments meet contractual specifications.
• Routine inspections – ongoing verification of operational performance during service.
• Post-repair validation – ensuring instruments maintain reliability after maintenance.

Typical applications include:

• Controllers in automated manufacturing.
• Switches for alarm signaling and safety systems.
• Pneumatic and electrical instruments used in process measurement and control industries.

Adhering to IEC 61003-2 helps minimize risks related to instrument failure, optimize maintenance schedules, and ensure operational safety and compliance with international industry standards.

Related Standards

IEC 61003-2 is to be used in conjunction with a series of complementary standards to provide a comprehensive performance evaluation framework:

• IEC 61003-1:2016 – Methods for evaluating performance of instruments with analogue inputs and two- or multi-position outputs.
• IEC 61298-2:2008 – Tests under reference conditions for process measurement and control devices.
• IEC 61298-3:2008 – Tests evaluating the effects of influence quantities on devices.
• IEC 61298-4 – Guidelines for evaluation report content ensuring thorough documentation.

Together, these standards ensure that industrial-process instruments meet rigorous international criteria for accuracy, reliability, and environmental resilience.

---

By following IEC 61003-2:2016, industries can maintain high-quality control systems that are essential for efficient, safe, and compliant industrial automation and process monitoring. This standard is indispensable for stakeholders seeking to implement robust inspection and testing routines for analogue input instruments with digital multi-position outputs.
