ISO/IEC TS 11801-9903:2025

Information technology - Generic cabling for customer premises - Part 9903: Modelling of channels and links

ISO/IEC TS 11801-9903:2025 establishes modelling of limits for mixed-mode transmission parameters within and between two pairs of balanced cabling. This document consists of a detailed description of matrix modelling and gives explanations on how to convert matrices, by using the S to T and T to S matrix conversion. Further it consists of terms and definitions used, how specific parameters are modelled, alternative calculation and signal-to-noise ratio (SNR) modelling.
Chain parameters and alternative approaches and formulas are described for combining component cable and connector transmission parameters into cabling link and channel transmission parameters. S-parameter limit matrix formulas are covered, which can be transformed into T-parameter limit matrices for use in chain parameter link and channel limit formulas. The formulas are applicable to all transmission parameters for forming complete differential-mode, mixed-mode, and common-mode link and channel models.
Terms and definitions used for modelling are discussed, together with how modelling is done for specific transmission parameters. Alternative calculation models are explained, and the SNR modelling introduced.
This second edition cancels and replaces the first edition published in 2021. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) the expansion of the list of specified parameters to include mixed-mode mode-conversion and related unbalance attenuation parameters;
b) the addition of an informative annex covering the topic of signal-to-noise ratio and its relation to the S-parameter matrix channel model.

General Information

• Status: Published
• Publication Date: 23-Sep-2025
• ICS: 35.200 - Interface and interconnection equipment
• Technical Committee: ISO/IEC JTC 1/SC 25 - Interconnection of information technology equipment
• Drafting Committee: WG 3 - ISO/IEC JTC 1/SC 25/WG 3
• Current Stage: PPUB - Publication issued
• Start Date: 24-Sep-2025
• Completion Date: 03-Oct-2025

Relations

• Revises: ISO/IEC TR 11801-9903:2015 - Information technology - Generic cabling systems for customer premises - Part 9903: Matrix modelling of channels and links
• Effective Date: 26-Oct-2025
• Revises: ISO/IEC TS 11801-9903:2021 - Information technology - Generic cabling for customer premises - Part 9903: Matrix modelling of channels and links
• Effective Date: 08-Nov-2024

Overview

ISO/IEC TS 11801-9903:2025 - “Information technology - Generic cabling for customer premises - Part 9903: Modelling of channels and links” specifies matrix-based modelling methods for mixed‑mode transmission over balanced cabling. The Technical Specification defines how to represent limits for mixed‑mode transmission parameters within and between two pairs of balanced cabling using S‑parameter (scattering) and T‑parameter (transmission) matrices, conversion formulas (S↔T), and chain‑parameter concatenation to form complete link and channel models. The 2025 edition is a technical revision of the 2021 edition and expands specified parameters (including mixed‑mode mode‑conversion and unbalance attenuation) and adds an informative annex on signal‑to‑noise ratio (SNR) modelling.

Key Topics

• Matrix modelling: Definitions and structure for quadriport and mixed‑mode matrices representing a two‑pair cabling system.
• S‑ and T‑parameter conversion: Formal S to T and T to S conversion formulas and conversion matrices for practical modelling and concatenation.
• Chain and link parameters: Methods to combine component cable and connector transmission parameters into permanent link and channel transmission parameters.
• Transmission parameters covered: Insertion loss, NEXT, ACR‑F, return loss, and mixed‑mode mode‑conversion/unbalance attenuation.
• Alternative calculation methods: Annexes describe alternative extraction of limit lines and component‑level assumptions.
• SNR modelling: Informative annex linking the S‑parameter channel model to power spectral density, noise definitions, modulation, BER and SNR calculations.
• Operational definitions: Terms, symbols and operational scattering/transfer functions used consistently for modelling and limits.

Applications

• Design and verification of balanced cabling systems and customer‑premises cabling channels.
• Creation of link and channel limit models for manufacturers of cables, connectors and patching hardware.
• Algorithm and test-equipment vendors implementing S/T‑parameter conversions, chain concatenation and SNR estimations in certification tools.
• Network planners and integrators assessing mixed‑mode behaviour (differential/common‑mode) and mode‑conversion impacts on high‑speed data transmission.
• Standards committees and test labs requiring consistent modelling methods for compliance, interoperability and statistical limit extraction.

Who Should Use This Standard

• Cable and connector manufacturers
• Test equipment developers and calibration labs
• Cabling system designers and installation contractors
• Network architects concerned with high‑frequency, mixed‑mode interference and SNR performance

Related Standards

• ISO/IEC 11801 series (Generic cabling for customer premises) - Part 9903 supplements the generic cabling family with advanced modelling techniques.
• Previous edition: ISO/IEC TS 11801-9903:2021 (replaced by 2025 edition)

This specification is essential for anyone implementing or testing mixed‑mode transmission models, S‑/T‑parameter conversions, and SNR assessments in balanced customer‑premises cabling.
