IEC 61511-3:2016

Functional safety - Safety instrumented systems for the process industry sector - Part 3: Guidance for the determination of the required safety integrity levels

IEC 61511-3:2016 applies when functional safety is achieved using one or more SIF for the protection of either personnel, the general public, or the environment; may be applied in non-safety applications such as asset protection; illustrates typical hazard and risk assessment methods that may be carried out to define the safety functional requirements and SIL of each SIF; illustrates techniques/measures available for determining the required SIL; provides a framework for establishing SIL but does not specify the SIL required for specific applications; does not give examples of determining the requirements for other methods of risk reduction. This second edition cancels and replaces the first edition published in 2003. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: Additional H&RA example(s) and quantitative analysis consideration annexes are provided.

Sécurité fonctionnelle - Systèmes instrumentés de sécurité pour le secteur des industries de transformation - Partie 3: Conseils pour la détermination des niveaux exigés d'intégrité de sécurité

L'IEC 61511-3:2016 s'applique lorsque la sécurité fonctionnelle est obtenue en utilisant une ou plusieurs SIF pour la protection du personnel, du grand public ou de l'environnement; peut s'appliquer dans des applications non liées à la sécurité (notamment la protection des biens); présente les méthodes d'analyse de danger et de risque qui peuvent être réalisées pour définir les exigences fonctionnelles de sécurité et le SIL de chaque SIF; identifie des techniques et mesures disponibles pour déterminer le SIL exigé; fournit un cadre pour la détermination du SIL, mais ne spécifie pas le SIL exigé pour des applications spécifiques; ne donne aucun exemple de détermination des exigences relatives à d'autres méthodes de réduction de risque. Cette deuxième édition annule et remplace la première édition parue en 2003. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente: Réalisation d'exemples additionnels H&RA et d'annexes sur la considération d'analyse quantitative.

General Information

• Status: Published
• Publication Date: 20-Jul-2016
• ICS: 13.110 - Safety of machinery
• ICS: 25.040.01 - Industrial automation systems in general
• Technical Committee: SC 65A - System aspects
• Drafting Committee: MT 61511 - TC 65/SC 65A/MT 61511
• Current Stage: PPUB - Publication issued
• Start Date: 21-Jul-2016
• Completion Date: 15-Mar-2016

Relations

• Revises: IEC 61511-3:2003 - Functional safety - Safety instrumented systems for the process industry sector - Part 3: Guidance for the determination of the required safety integrity levels
• Effective Date: 05-Sep-2023
• Revises: IEC 61511-3:2003/COR1:2004 - Corrigendum 1 - Functional safety - Safety instrumented systems for the process industry sector - Part 3: Guidance for the determination of the required safety integrity levels
• Effective Date: 05-Sep-2023

Overview

IEC 61511-3:2016 - Part 3 of the IEC 61511 series - provides guidance for determining the required Safety Integrity Levels (SILs) for Safety Instrumented Functions (SIFs) in the process industry. Intended for applications that protect personnel, the public, or the environment (and applicable to asset protection), this second edition (2016) updates and replaces the 2003 edition and adds expanded hazard & risk assessment (H&RA) examples and quantitative analysis annexes.

Key topics and technical requirements

• Scope and intent
  • Framework for establishing the required SIL for each SIF.
  • Applies when functional safety is achieved using one or more SIF; may be used for non-safety applications (asset protection).
  • Clarifies that it provides guidance and techniques but does not prescribe the SIL for specific applications.
• Risk assessment methods explained
  • Semi‑quantitative methods (event tree analysis).
  • Qualitative and semi‑qualitative risk graphs, including guidance on designing and calibrating risk graphs.
  • Layer of Protection Analysis (LOPA) and variations (including matrix-based LOPA).
  • Safety layer matrix and multiple safety systems approaches.
  • ALARP (As Low As Reasonably Practicable) and tolerable risk concepts.
• Supporting guidance and annexes
  • Numerous informative annexes with worked examples, calibration techniques, H&RA examples, multiple-system treatments, and documentation practices.
  • Guidance on selecting methods for SIL determination and on allocating safety requirements across protection layers.

Practical applications and who uses it

IEC 61511-3 is used to:

• Define the Safety Functional Requirements (SFRs) and required SIL for instrumented protective systems.
• Support HAZOP, LOPA, and risk‑assessment workshops to derive required risk reduction.
• Calibrate risk graphs and document SIL decisions for verification and audits.

Typical users:

• Process safety engineers and functional safety specialists
• Asset owners, operations and maintenance teams
• Safety consultants and third‑party assessors
• HAZOP/LOPA facilitators and regulatory compliance teams

Related standards

• IEC 61511-1 and IEC 61511-2 (other parts of the process industry functional safety series)
• IEC 61508 (generic functional safety of electrical/electronic/programmable systems)

Keywords: IEC 61511-3, SIL determination, safety instrumented systems, SIF, process industry, LOPA, risk graph, HAZOP, functional safety.
