IEC 62287-2:2017

Maritime navigation and radiocommunication equipment and systems - Class B shipborne equiment of the automatic identification system (AIS) - Part 2: Self-organising time division multiple access (SOTDMA) techniques

IEC 62287-2:2017 specifies operational and performance requirements, methods of testing and required test results for Class B "SO" shipborne automatic identifications system (AIS) equipment using self-organising time division multiple access (SOTDMA) techniques as described in Recommendation ITU-R M.1371. This document takes into account other associated IEC International Standards and existing national standards, as applicable.
This edition includes the following significant technical change with respect to the previous edition: the introduction of transmission of Message 27 on channels 75 and 76 for the long range application by broadcast.

Matériels et systèmes de navigation et de radiocommunication maritimes - Transpondeur embarqué du système d’identification automatique (AIS) de classe B - Partie 2: Techniques auto-organisées d’accès multiple par répartition dans le temps (SOTDMA)

L’IEC 62287-2:2017 spécifie les exigences opérationnelles et de performance, les méthodes d’essai et les résultats d’essai exigés pour le transpondeur embarqué du système d’identification automatique (AIS) "AO" de classe B utilisant les techniques d’accès multiple par répartition dans le temps auto-organisé (AMRTAO) telles qu’elles sont décrites dans la Recommandation UIT-R M.1371. Le présent document prend en compte d’autres Normes internationales IEC associées et des normes nationales existantes, selon le cas.

General Information

• Status: Published
• Publication Date: 06-Feb-2017
• ICS: 01 - GENERALITIES. TERMINOLOGY. STANDARDIZATION. DOCUMENTATION
• ICS: 47.020.70 - Navigation and control equipment
• Technical Committee: TC 80 - Maritime navigation and radiocommunication equipment and systems
• Drafting Committee: WG 15 - TC 80/WG 15
• Current Stage: PPUB - Publication issued
• Start Date: 03-Mar-2017
• Completion Date: 07-Feb-2017
