IEC 61784-5-2:2018

Industrial communication networks - Profiles - Part 5-2: Installation of fieldbuses - Installation profiles for CPF 2

IEC 61784-5-2:2018 specifies the installation profiles for CPF 2 (CIP™ ). This contribution contains a number of related files covering the communication profiles to be used in conjunction with IEC 61918. The installation profile documents contained herewith provide the installation profiles of the communication profiles (CP) of a specific communication profile family (CPF) by stating which requirements of IEC 61918 fully apply and, where necessary, by supplementing, modifying, or replacing the other requirements. The installation profiles are specified in the annexes. These annexes are read in conjunction with IEC 61918. This fourth edition cancels and replaces the third edition published in 2013. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) references to ISO/IEC 24702 have been replaced with references to ISO/IEC 11801-3 in Table B.1;
b) errors have been corrected;
c) Tables B11 and B13 have been added in support of 1,000 Mb/s 4 Pair Ethernet;
d) Clarification of dual power supplies for Annex C.

Réseaux de communication industriels - Profils - Partie 5-2: Installation des bus de terrain - Profils d’installation pour CPF 2

L‘IEC 61784-5-2:2018 spécifie les profils d'installation pour le CPF 2 (CIP™ ). La présente contribution contient un certain nombre de fichiers associés couvrant les profils de communication à utiliser conjointement avec la CEI 61918. Les documents de profil d'installation contenus ci-joint fournissent les profils d'installation des profils de communication (CP) d'une famille de profils de communication (CPF) spécifique en indiquant quelles exigences de la CEI 61918 s'appliquent pleinement et, le cas échéant, en complétant, modifiant ou remplaçant les autres exigences. Les profils d'installation sont spécifiés dans les annexes. Ces annexes sont lues conjointement avec la CEI 61918. Cette quatrième édition annule et remplace la troisième édition publiée en 2013. Cette édition constitue une révision technique.
Cette édition comprend les modifications techniques significatives suivantes par rapport à l'édition précédente :
a) les références à l'ISO/IEC 24702 ont été remplacées par des références à l'ISO/IEC 11801-3 dans le Tableau B.1 ;
b) des erreurs ont été corrigées ;
c) Les Tableaux B11 et B13 ont été ajoutés pour prendre en charge l'Ethernet à 4 paires de 1,000 Mb/s ;
d) Clarification des alimentations doubles pour l'Annexe C.

General Information

• Status: Published
• Publication Date: 20-Mar-2024
• ICS: 25.040.40 - Industrial process measurement and control
• ICS: 35.100.40 - Transport layer
• Technical Committee: SC 65C - Industrial networks
• Drafting Committee: JWG 10 - TC 65/SC 65C/JWG 10
• Current Stage: PPUB - Publication issued
• Start Date: 30-Aug-2018
• Completion Date: 03-Aug-2018

Relations

• Amended By: IEC 61784-5-2:2018/AMD1:2024 - Amendment 1 - Industrial communication networks - Profiles - Part 5-2: Installation of fieldbuses - Installation profiles for CPF 2
• Effective Date: 23-Feb-2024
• Revises: IEC 61784-5-2:2013 - Industrial communication networks - Profiles - Part 5-2: Installation of fieldbuses - Installation profiles for CPF 2
• Effective Date: 05-Sep-2023
• Revised: IEC 61784-5-21:2018/AMD1:2024 - Amendment 1 - Industrial communication networks - Profiles - Part 5-21: Installation of fieldbuses - Installation profiles for CPF 21
• Effective Date: 05-Sep-2023

Overview

IEC 61784-5-2:2018 (consolidated with Amendment 1, 2024) defines installation profiles for CPF 2 (CIP™) used in industrial communication networks. It specifies how the communication profiles (CP) in CPF 2 - notably ControlNet™ (CP 2/1), EtherNet/IP™ (CP 2/2) and DeviceNet™ (CP 2/3) - shall be installed, tested and maintained by referencing IEC 61918 and by providing annexes that supplement, modify or replace applicable requirements. This edition is a technical revision that includes updates such as referencing ISO/IEC 11801‑3, support material for 1 000 Mb/s 4‑pair Ethernet, and clarifications on dual power supplies.

Key topics and technical requirements

• Installation profiles per CP/CPF: Normative annexes for CP 2/1, CP 2/2 and CP 2/3 cover device- and media-specific installation rules.
• Cabling planning and selection: Guidance on choosing cabling components, drop cables, connectors, shielding and earthing/bonding practices aligned with IEC 61918 conventions.
• Installation implementation: Procedures for cable routing, connector and terminator installation, device mounting, labelling and documentation of “as‑implemented” cabling.
• Verification and acceptance testing: Requirements for installation verification and acceptance tests to validate cabling, connectivity and network capabilities.
• Maintenance and troubleshooting: Recommended administration, maintenance routines and troubleshooting steps specific to each CP.
• Network topologies and extension: Advice on repeaters, star/line/ring topologies, node limits and redundant media configurations.
• Updates and technical changes: Replacement of ISO/IEC 24702 references with ISO/IEC 11801‑3, added tables for 1 000 Mb/s 4‑pair Ethernet, and dual‑power supply clarifications.

Practical applications and users

IEC 61784-5-2 is aimed at professionals deploying and maintaining industrial communication networks in factory automation, process control and machine systems. Typical users include:

• Network and automation engineers designing fieldbus and CIP-based systems
• System integrators implementing ControlNet, EtherNet/IP and DeviceNet installations
• Installation contractors and cabling specialists responsible for field wiring, connectorization and shielding
• Maintenance teams and commissioning engineers performing acceptance tests and troubleshooting
• Standards or procurement specialists creating vendor/contract specifications to ensure interoperability and compliance

Related standards and integration

• IEC 61918 (referenced as the baseline for communication profile requirements)
• ISO/IEC 11801‑3 (referenced for structured cabling aspects in this edition)
• Other IEC 61784 parts (for additional CPF families and profile relationships)

Keywords: IEC 61784-5-2, CPF 2, CIP, EtherNet/IP, DeviceNet, ControlNet, industrial communication networks, installation profiles, fieldbus installation, cabling planning, installation verification, 1 000 Mb/s 4‑pair Ethernet.
