IEC 60282-1:2020

High-voltage fuses - Part 1: Current-limiting fuses

IEC 60282-1:2020 applies to all types of high-voltage current-limiting fuses designed for use outdoors or indoors on alternating current systems of 50 Hz and 60 Hz and of rated voltages exceeding 1 000 V.
This eighth edition cancels and replaces the seventh edition published in 2009.
This edition includes the following significant technical changes with respect to the previous edition:
– additional information concerning thermally operated strikers;
– the division of ratings, characteristics and type tests into those applicable to all fuses and those applicable to particular fuse-link types and applications;
– adjustment of Series II voltages and tests to meet present North American standard system voltages and applications;
– clarification of requirements for fuse-links used in surrounding temperatures above 40 °C; and
– clarification of homogeneous requirements for fuse-links containing one element.

Fusibles à haute tension - Partie 1: Fusibles limiteurs de courant

IEC 60282-1:2020 s'applique à tous les types de fusibles à haute tension limiteurs de courant destinés à être utilisés à l'extérieur ou à l'intérieur sur des réseaux à courant alternatif 50 Hz et 60 Hz et dont les tensions assignées sont supérieures à 1 000 V.
Cette huitième édition annule et remplace la septième édition parue en 2009.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
– des informations supplémentaires concernant les percuteurs thermiques;
– la division des valeurs assignées, des caractéristiques et des essais de type en un groupe qui s'applique à tous les fusibles et en un groupe qui s'applique à des types particuliers d'éléments de remplacement et des applications;
– le réglage des tensions de la Série II et les essais pour satisfaire aux tensions réseaux normalisées actuelles et aux applications d'Amérique du Nord;
– la clarification des exigences pour les éléments de remplacement utilisés avec des températures environnantes supérieures à 40 °C;
– et la clarification d'exigences homogènes pour les éléments de remplacement contenant un élément.

General Information

• Status: Published
• Publication Date: 13-Apr-2020
• ICS: 29.120.50 - Fuses and other overcurrent protection devices
• Technical Committee: SC 32A - High-voltage fuses
• Drafting Committee: MT 3 - TC 32/SC 32A/MT 3
• Current Stage: PPUB - Publication issued
• Start Date: 14-Apr-2020
• Completion Date: 01-May-2020

Relations

• Revises: IEC 60282-1:2009/AMD1:2014 - Amendment 1 - High-voltage fuses - Part 1: Current-limiting fuses
• Effective Date: 05-Sep-2023
• Revises: IEC 60282-1:2009 - High-voltage fuses - Part 1: Current-limiting fuses
• Effective Date: 05-Sep-2023

Overview

IEC 60282-1:2020 is the internationally recognized standard governing high-voltage current-limiting fuses. Specifically, it focuses on current-limiting fuses used in alternating current (AC) systems of 50 Hz and 60 Hz with rated voltages exceeding 1,000 volts. This eighth edition supersedes the 2009 seventh edition, featuring key technical updates to enhance fuse performance, safety, and applicability across diverse industrial environments. The International Electrotechnical Commission (IEC) developed this standard to ensure consistent quality and safety for fuse manufacturers, system designers, and users worldwide.

Key Topics

• Scope and Application: Applies to high-voltage current-limiting fuses designed for indoor and outdoor use on AC systems operating above 1,000 V.
• Ratings and Characteristics: Establishes essential electrical parameters such as rated voltage, current, breaking capacity, time-current characteristics, and insulation levels for fuse-links and fuse-bases.
• Design and Performance Criteria: Defines stringent requirements for fuse construction, operation under normal and special service conditions, and environmental behavior, including temperature tolerance up to and above 40 °C.
• Type Testing and Verification: Specifies comprehensive type tests including dielectric, temperature-rise, breaking capacity, and electromagnetic compatibility (EMC) tests to verify fuse performance under realistic conditions.
• Special Applications and Fuse-Link Types: Covers specific tests and requirements for applications such as transformers, motors, capacitors, and fuse-links with indicators or strikers.
• Updated Technical Changes: Incorporates additional guidance on thermally operated strikers, divides ratings and tests into general and application-specific categories, and aligns test voltages with North American standards.

Applications

IEC 60282-1:2020 is essential for industries and sectors reliant on high-voltage electrical protection, offering standards for protective devices that limit fault currents quickly to safeguard equipment, reduce damage, and maintain system stability. Typical applications include:

• Power Generation and Distribution: Protection of transformers, switchgear, and transmission lines in substations and utility environments.
• Industrial Facilities: Ensures safe operation of motor circuits and capacitor banks by limiting short-circuit currents and protecting sensitive downstream equipment.
• Infrastructure Projects: Suitable for outdoor and indoor installations in power plants, railways, and large manufacturing plants where high-voltage systems are employed.
• Electrical Equipment Manufacturers: Guides design and production of current-limiting fuse assemblies and accessories, ensuring compliance and interoperability.

Implementing IEC 60282-1 compliant fuses enhances system reliability and conformity with international electrical safety practices, minimizing risks of fire, equipment failure, and prolonged outages.

Related Standards

• IEC 62271-105: Switch-fuse combinations standard, referenced for back-up fuse applications integrated with high-voltage switches.
• IEC 60694: Common specifications for high-voltage switchgear and controlgear standards, supporting coordination of circuit protection.
• IEC 60060-1: High-voltage testing techniques standard, related to dielectric and impulse withstand tests referenced in IEC 60282-1.
• IEC 60947 Series: Low-voltage switchgear and controlgear standards, important for coordinating protection devices complementing high-voltage fuses.
• National Standards Adaptations: IEC 60282-1 aligns with North American voltage and testing conventions to ensure cross-region standard compatibility.

---

Keywords: IEC 60282-1, high-voltage current-limiting fuses, fuse standards, electrical safety, high-voltage protection devices, AC systems, fuse ratings, fuse testing, high-voltage fuse applications, IEC standards, current-limiting fuse design.
