IEC 60146-1-1:2024

Semiconductor converters - General requirements and line commutated converters - Part 1-1: Specification of basic requirements

IEC 60146-1-1:2024 specifies the requirements for the performance of all semiconductor power converters and semiconductor power switches using controllable and/or non-controllable electronic valve devices. It is primarily intended to specify the basic requirements for converters in general and the requirements applicable to line commutated converters for conversion of AC power to DC power or vice versa. Parts of this document are also applicable to other types of electronic power converter provided that they do not have their own product standards.
This fifth edition introduces four main changes:
a) re-edition of the whole standard according to the current directives;
b) deletion of safety-related descriptions considering coordination with IEC 62477 series;
c) changes of calculation methods of inductive voltage regulation;
d) changes considering coordination with IEC 61378 series.
The content of the corrigendum 1 (2025-03) has been included in this copy.

Convertisseurs à semiconducteurs - Exigences générales et convertisseurs commutés par le réseau - Partie 1-1: Spécification des exigences de base

L’IEC 60146-1-1:2024 spécifie les exigences relatives aux caractéristiques de fonctionnement de tous les convertisseurs de puissance à semiconducteurs, ainsi que des commutateurs de puissance à semiconducteurs utilisant des valves électroniques, commandables et/ou non commandables.
Le présent document est prévu en premier lieu pour spécifier les exigences de base applicables aux convertisseurs en général, ainsi que les exigences applicables aux convertisseurs commutés par le réseau, pour la conversion de puissance alternative en puissance continue ou vice versa. Certaines parties du présent document s’appliquent également à d’autres types de convertisseurs électroniques de puissance, sous réserve qu’il n’existe pas de normes de produit qui leur soient propres.
Cette cinquième édition introduit quatre modifications principales:
a) réédition de l’ensemble de la norme conformément aux directives en vigueur;
b) suppression des descriptions relatives à la sécurité, pour prendre en compte la coordination avec la série IEC 62477;
c) modifications des méthodes de calcul de la variation inductive de tension;
d) modifications pour prendre en compte la coordination avec la série IEC 61378.
Le contenu du corrigendum 1 (2025-03) a été pris en considération dans cet exemplaire.

General Information

• Status: Published
• Publication Date: 18-Mar-2024
• ICS: 29.045 - Semiconducting materials
• ICS: 29.200 - Rectifiers. Convertors. Stabilized power supply
• Technical Committee: TC 22 - Power electronic systems and equipment
• Drafting Committee: MT 3 - TC 22/MT 3
• Current Stage: PPUB - Publication issued
• Start Date: 19-Mar-2024
• Completion Date: 29-Mar-2024

Relations

• Corrected By: IEC 60146-1-1:2024/COR1:2025 - Corrigendum 1 - Semiconductor converters - General requirements and line commutated converters - Part 1-1: Specification of basic requirements
• Effective Date: 07-Mar-2025
• Revises: IEC 60146-1-1:2009 - Semiconductor converters - General requirements and line commutated converters - Part 1-1: Specification of basic requirements
• Effective Date: 05-Sep-2023

Overview

IEC 60146-1-1:2024 - "Semiconductor converters – General requirements and line commutated converters – Part 1‑1: Specification of basic requirements" defines performance and basic technical requirements for semiconductor power converters and semiconductor power switches that use controllable and/or non‑controllable electronic valve devices. The standard is primarily aimed at line‑commutated converters used for conversion between AC and DC power, and its clauses are also applicable to other converter types when no specific product standard exists. This fifth edition incorporates four main updates:

• Re‑edition to current IEC directive structure
• Removal of safety descriptions to coordinate with the IEC 62477 series
• Revised calculation methods for inductive voltage regulation
• Updates for coordination with the IEC 61378 series
  Corrigendum 1 (2025‑03) has been included in this edition.

Key topics and technical requirements

The standard addresses foundational topics needed for design, testing and specification of semiconductor converters:

• Terms and definitions for semiconductor devices, arms, commutation and ratings
• Service conditions and environmental tolerances (temperature, cooling codes, duty cycles)
• Operation and classification of semiconductor power equipment including commutation types and calculation factors
• Electrical connections and calculation factors: losses, efficiency, power factor, and voltage regulation methods (including updated inductive regulation calculations)
• Rated values and duty classes, selection guidance and marking requirements
• Test requirements: insulation, functional and routine tests, temperature rise, losses, EMC and audible noise
• Harmonics and EMC (Annex A) and measurement methods for non‑sinusoidal voltages/currents
• Protection and safety coordination (informative intro and normative references to safety standards in Annex C)

Applications and who uses it

IEC 60146-1-1:2024 is essential for organizations involved in the specification, design, manufacture, testing and procurement of power conversion equipment, including:

• Converter and power electronics manufacturers (rectifiers, converters for HVDC, large industrial DC supplies)
• Power system integrators and OEMs specifying AC↔DC conversion solutions
• Test laboratories and compliance engineers performing insulation, EMC and performance tests
• Utilities and industrial end‑users procuring line‑commutated converter stations and assemblies
• Standards and safety engineers coordinating product safety with IEC 62477 and transformer interfaces with IEC 61378

Related standards

• IEC 62477 series - safety requirements for power electronic converter systems (safety coordination referenced in this edition)
• IEC 61378 series - converters’ transformer interfaces and coordination (referenced for alignment)

Keywords: IEC 60146-1-1:2024, semiconductor converters, line commutated converters, power conversion, inductive voltage regulation, harmonics, EMC, insulation tests, duty classes.

Standards Content (Sample)
