IEC 62439-1:2010
(Main)Industrial communication networks - High availability automation networks - Part 1: General concepts and calculation methods
Industrial communication networks - High availability automation networks - Part 1: General concepts and calculation methods
IEC 62439-1:2010 is applicable to high-availability automation networks based on the ISO/IEC 8802-3 (IEEE 802.3) (Ethernet) technology. It specifies:
- the common elements and definitions for other parts of the IEC 62439 series;
- the conformance test specification (normative);
- a classification scheme for network characteristics (informative);
- a methodology for estimating network availability (informative);
- the configuration rules, calculation and measurement method for a deterministic recovery time in RSTP. This standard cancels and replaces IEC 62439 published in 2008 and constitutes a technical revision. It includes the following changes:
- a new calculation method for RSTP (rapid spanning tree protocol, IEEE 802.1Q),
- two new redundancy protocols: HSR (High-availability Seamless Redundancy) and DRP (Distributed Redundancy Protocol),
- a new method to calculate the maximum recovery time of RSTP in a restricted configuration (ring) to IEC 62439-1 as Clause 8, new specifications of the HSR (High-availability Seamless Redundancy) protocol, which shares the principles of PRP to IEC 62439-3 as Clause 5, and
- introduces the DRP protocol as IEC 62439-6. This bilingual version (2013-07) corresponds to the monolingual English version, published in 2010-02.
Réseaux industriels de communication - Réseaux d'automatisme à haute disponibilité - Partie 1: Concepts généraux et méthodes de calcul
La CEI 62439-1:2010 s'applique aux réseaux de haute disponibilité pour l'automatisation reposant sur la technologie 8802-3 (IEEE 802.3) (Ethernet) de l'ISO/CEI. Elle spécifie:
- les éléments communs et les définitions pour d'autres parties de la série CEI 62439;
- la spécification d'essai de conformité (normative);
- un système de classification pour les caractéristiques de réseau (informative);
- une méthodologie pour l'estimation de la disponibilité du réseau (informative);
- les règles de configuration, la méthode de calcul et de mesure pour un temps de reprise déterministe dans le protocole RSTP. Elle annule et remplace la CEI 62439 publiée en 2008. Elle constitue une révision technique. Cette édition inclut les modifications suivantes:
- ajout d'une méthode de calcul pour le protocole RSTP (Rapid Spanning Tree Protocol, IEEE 802.1Q),
- ajout de deux nouveaux protocoles de redondance: HSR (High-availability Seamless Redundancy) et DRP (Distributed Redundancy Protocol),
- ajout d'une méthode de calcul du temps de reprise maximal du protocole RSTP dans une configuration restreinte (anneau) dans la CEI 62439-1 (Article 8),
- ajout de spécifications du protocole HSR (High-availability Seamless Redundancy), qui partage les principes du protocole PRP dans la CEI 62439-3 (Article 5), et introduction du protocole DRP (CEI 62439-6). La présente version bilingue (2013-07) correspond à la version anglaise monolingue publiée en 2010-02.
