IEC 60793-2-30:2012

Optical fibres - Part 2-30: Product specifications - Sectional specification for category A3 multimode fibres

IEC 60793-2-30:2012 is applicable to sub-categories A3a, A3b, A3c, A3d and A3e. Three types of requirements apply to these fibres:
- general requirements, as defined in IEC 60793-2;
- specific requirements common to the category A3 multimode fibres covered in this standard and which are given in Clause 3;
- particular requirements applicable to the individual sub-categories or specific applications (e.g. automotive or industrial applications), which are defined in the normative sub-category annexes. This third edition cancels and replaces the second edition, published in 2007. It constitutes a technical revision and includes the following significant technical changes with respect to the previous edition:
- addition of a new sub-category A3e;
- changed unit for core-cladding concentricity error and proof stress level. Keywords: A3 multimode fibres, sub-categories A3a, A3b, A3c, A3d and A3e

Fibres optiques - Partie 2-30: Spécifications de produits - Spécification intermédiaire pour les fibres multimodales de catégorie A3

La CEI 60793-2-30:2012 est applicable aux sous-catégories A3a, A3b, A3c, A3d et A3e. Trois types d'exigences s'appliquent à ces fibres:
- les exigences générales, comme définies dans la CEI 60793-2;
- des exigences spécifiques communes aux fibres multimodales de catégorie A3, couvertes par la présente norme, et qui sont données dans l'Article 3;
- des exigences particulières applicables à des sous-catégories particulières ou à des applications spécifiques (comme des applications automobiles ou industrielles), qui sont définies dans les annexes normatives relatives aux sous-catégories. Cette troisième édition annule et remplace la deuxième édition publiée en 2007. Elle constitue une révision technique La présente édition contient les modifications techniques significatives suivantes par rapport à l'édition précédente:
- l'ajout d'une nouvelle sous-catégorie A3e;
- modification d'unité concernant l'erreur de concentricité entre le coeur et la gaine et le niveau de contrainte d'essai. Mots clés: multimodales de catégorie A3, sous-catégories A3a, A3b, A3c, A3d et A3e

General Information

• Status: Published
• Publication Date: 24-Oct-2012
• ICS: 31.220.01 - Electromechanical components in general
• ICS: 33.180.10 - Fibres and cables
• Technical Committee: SC 86A - Fibres and cables
• Drafting Committee: WG 1 - TC 86/SC 86A/WG 1
• Current Stage: DELPUB - Deleted Publication
• Completion Date: 25-Jun-2015

Relations

• Revised: IEC 60793-2-30:2015 - Optical fibres - Part 2-30: Product specifications - Sectional specification for category A3 multimode fibres
• Effective Date: 05-Sep-2023
