IEC 61850-10:2012

Communication networks and systems for power utility automation - Part 10: Conformance testing

IEC 61850-10:2012 specifies standard techniques for testing of conformance of client, server and sampled value devices and engineering tools, as well as specific measurement techniques to be applied when declaring performance parameters. The use of these techniques will enhance the ability of the system integrator to integrate IEDs easily, operate IEDs correctly, and support the applications as intended. The major technical changes with regard to the previous edition are as follows:
- updates to server device conformance test procedures;
- additions of certain test procedures (client device conformance, sampled values device conformance, (engineering) tool related conformance, GOOSE performance).

Réseaux et systèmes de communication pour l'automatisation des systèmes électriques - Partie 10: Essais de conformité

La CEI 61850-10:2012 spécifie les techniques courantes d'essais de conformité du client, du serveur et des dispositifs à valeurs échantillonnées, ainsi que des outils techniques, et les techniques de mesurage spécifiques à appliquer pour la déclaration des paramètres de performances. L'emploi de ces techniques renforce la capacité de l'intégrateur de systèmes à intégrer aisément les IED, à les exploiter correctement et à prendre en charge les applications, tel que prévu. Les modifications techniques principales par rapport à l'édition précédente sont les suivantes:
- actualisation des procédures d'essai de conformité du serveur,
- ajout de certaines procédures d'essai (conformité du système client, conformité des dispositifs à valeurs échantillonnées, conformité associée aux outils (techniques), performances GOOSE).

General Information

• Status: Published
• Publication Date: 29-Jul-2025
• ICS: 29.080.10 - Insulators
• ICS: 33.200 - Telecontrol. Telemetering
• Technical Committee: TC 57 - Power systems management and associated information exchange
• Drafting Committee: WG 10 - TC 57/WG 10
• Current Stage: PPUB - Publication issued
• Start Date: 14-Dec-2012
• Completion Date: 15-Jan-2013

Relations

• Amended By: IEC 61850-10:2012/AMD1:2025 - Amendment 1 - Communication networks and systems for power utility automation - Part 10: Conformance testing
• Effective Date: 05-Sep-2023
• Revises: IEC 61850-10:2005 - Communication networks and systems in substations - Part 10: Conformance testing
• Effective Date: 05-Sep-2023

Overview

IEC 61850-10:2012 (Consolidated with Amendment) defines standardized methods for conformance testing within the IEC 61850 family - the communications framework for power utility automation. The standard specifies test techniques for verifying client, server and sampled values devices, as well as engineering tools. It also defines measurement techniques for declaring performance parameters (for example, communications latency and time synchronization). Updates include revised server test procedures and added test procedures for client devices, sampled value devices, tool-related conformance and GOOSE performance.

Key Topics

• Conformance test procedures: Standardized test structure, test cases and acceptance criteria for server, client and sampled values devices.
• Device testing methodology: Use of SCL files, device documentation checks, data model validation and service-level testing.
• Tool-related conformance: Test procedures for IED configurator tools and system configurator tools (format, behavior and interoperability).
• Performance tests: Measurement methods for communications latency, GOOSE performance, round-trip time and time synchronization/accuracy.
• Reporting & QA: Quality plans, documentation of conformance test reports and test-system architecture guidance for reproducible results.
• Security considerations: Conformance test aspects related to cyber security are included to support secure integration.
• Sampled Values (SV): Publish/subscribe testing, control block validation and SV-specific positive/negative test cases.

Applications

IEC 61850-10 is practical for anyone responsible for verifying that Intelligent Electronic Devices (IEDs), engineering tools and system components conform to IEC 61850 interoperability and performance expectations. Typical applications:

• Verifying interoperability of IED servers and clients in substations.
• Testing sampled values publishers/subscribers used for protection and measurement.
• Validating engineering/configurator tools that generate or consume SCL (Substation Configuration Language) files.
• Measuring GOOSE messaging latency and behavior under defined test conditions.
• Producing formal conformance test reports for procurement, compliance or certification purposes.

Who uses this standard

• Utility engineers and substation integrators
• IED and relay manufacturers
• Test laboratories and certification bodies
• Engineering tool vendors and system integrators
• QA teams responsible for commissioning and interoperability testing

Related standards

• Part of the IEC 61850 series (communication services, data models and SCL). For complete conformance and interoperability programs, IEC 61850-10 should be used together with other IEC 61850 parts covering data models, services and configuration.

Keywords: IEC 61850-10, conformance testing, power utility automation, IED testing, GOOSE performance, sampled values, SCL, conformance test procedures, time synchronization.
