Measurement method of a half-wavelength voltage for Mach-Zehnder optical modulator in wireless communication and broadcasting systems

IEC 62801:2020 specifies a measurement method of half-wavelength voltage applicable to Mach-Zehnder optical modulators in wireless communication and broadcasting systems. In addition, this method is also effective for the estimation of the intermodulation distortion of Mach-Zehnder optical modulators. The method applies for the following:
– frequency range: 10 MHz to 30 GHz;
– wavelength band: 0,8 µm to 2,0 µm;
– electro-optic material based Mach-Zehnder optical modulators and their modules.

Méthode de mesure de la tension à une demi-longueur d'onde relative aux modulateurs optiques Mach-Zehnder dans les systèmes de communication et transmission radiofréquence

IEC 62801:2020 spécifie une méthode de mesure de la tension d’une demi-longueur d’onde applicable aux modulateurs optiques de Mach-Zehnder dans les systèmes de communication et de transmission radiofréquence. De plus, cette méthode est également efficace pour estimer la distorsion d’intermodulation des modulateurs optiques de Mach-Zehnder. La méthode s'applique à ce qui suit:
– plage de fréquences: 10 MHz à 30 GHz;
– bande de longueur d’onde: 0,8 µm à 2,0 µm;
– modulateurs optiques de Mach-Zehnder fondés sur matériau électro-optique et leurs modules associés.

General Information

Status
Published
Publication Date
23-Sep-2020
Current Stage
PPUB - Publication issued
Completion Date
24-Sep-2020
Ref Project

Buy Standard

Standard
IEC 62801:2020 - Measurement method of a half-wavelength voltage for Mach-Zehnder optical modulator in wireless communication and broadcasting systems
English and French language
75 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (sample)

IEC 62801
Edition 1.0 2020-09
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
Measurement method of half-wavelength voltage for Mach-Zehnder optical
modulator in wireless communication and broadcasting systems
Méthode de mesure de la tension à une demi-longueur d’onde relative aux
modulateurs optiques Mach-Zehnder dans les systèmes de communication
et transmission radiofréquence
IEC 62801:2020-09(en-fr)
