High-voltage switchgear and controlgear - Part 37-082: Standard practice for the measurement of sound pressure levels on alternating current circuit-breakers

IEC/IEEE 62271-37-082:2012(E) provides methods for the measurement of sound pressure level produced by outdoor alternating current circuit-breakers in a free-field environment. These methods may also be used indoors or in restricted field, provided that precautions are observed in the measurement and interpretation of the results. This standard has been prepared by subcommittee 17A: High-voltage switchgear and controlgear, of IEC technical committee 17: Switchgear and controlgear, in cooperation with the Switchgear Committee of the IEEE Power & Energy Society, under the IEC/IEEE Dual Logo Agreement between IEC and IEEE. The contents of the corrigendum of January 2014 have been included in this copy.

General Information

Status
Published
Publication Date
24-Oct-2012
Technical Committee
Current Stage
PPUB - Publication issued
Start Date
25-Oct-2012
Completion Date
25-Oct-2012
Ref Project

Buy Standard

Standard
IEC/IEEE 62271-37-082:2012 - High-voltage switchgear and controlgear - Part 37-082: Standard practice for the measurement of sound pressure levels on alternating current circuit-breakers
English language
19 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (sample)

IEC/IEEE 62271-37-082
Edition 1.0 2012-10
INTERNATIONAL
STANDARD
High-voltage switchgear and controlgear –
Part 37-082: Standard practice for the measurement of sound pressure levels on
alternating current circuit-breakers
IEC/IEEE 62271-37-082:2012(E)
---------------------- Page: 1 ----------------------
THIS PUBLICATION IS COPYRIGHT PROTECTED
Copyright © 2012 IEC, Geneva, Switzerland
Copyright © 2012 IEEE

All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form

or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing being

secured.

Requests for permission to reproduce should be addressed to either IEC at the address below or IEC’s member

National Committee in the country of the requester or from IEEE.
IEC Central Office Institute of Electrical and Electronics Engineers, Inc.
3, rue de Varembé 3 Park Avenue
CH-1211 Geneva 20 New York, NY 10016-5997
Switzerland United States of America
Tel.: +41 22 919 02 11 stds.ipr@ieee.org
Fax: +41 22 919 03 00 www.ieee.org
info@iec.ch
www.iec.ch
About the IEC

The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes

International Standards for all electrical, electronic and related technologies.
About the IEEE

IEEE is the world’s largest professional association dedicated to advancing technological innovation and excellence for

the benefit of humanity. IEEE and its members inspire a global community through its highly cited publications,

conferences, technology standards, and professional and educational activities.
About IEC/IEEE publications

The technical content of IEC/IEEE publications is kept under constant review by the IEC and IEEE. Please make sure

that you have the latest edition, a corrigendum or an amendment might have been published.

Useful links:

IEC publications search - www.iec.ch/searchpub IEC Just Published - webstore.iec.ch/justpublished

The advanced search enables you to find IEC publications Stay up to date on all new IEC publications. Just Published

by a variety of criteria (reference number, text, technical details all new publications released. Available on-line and

committee,…). also once a month by email.
It also gives information on projects, replaced and
withdrawn publications. Electropedia - www.electropedia.org
The world's leading online dictionary of electronic and
IEEE products and services - www.ieee.org/go/shop
electrical terms containing more than 30 000 terms and

IEEE publishes nearly a third of the world’s technical definitions in English and French, with equivalent terms in

literature in electrical engineering, computer science, and additional languages. Also known as the International

electronics. Browse the latest publications including Electrotechnical Vocabulary (IEV) on-line.

standards, draft standards, standards collections, and
much more. Customer Service Centre - webstore.iec.ch/csc
If you wish to give us your feedback on this publication
or need further assistance, please contact the
Customer Service Centre: csc@iec.ch.
---------------------- Page: 2 ----------------------
IEC/IEEE 62271-37-082
Edition 1.0 2012-10
INTERNATIONAL
STANDARD
High-voltage switchgear and controlgear –
Part 37-082: Standard practice for the measurement of sound pressure levels on
alternating current circuit-breakers
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
PRICE CODE
ICS 29.130.10 ISBN 978-2-83220-406-1

Warning! Make sure that you obtained this publication from an authorized distributor.

---------------------- Page: 3 ----------------------
– 2 – 62271-37-082 © IEC/IEEE:2012(E)
CONTENTS

FOREWORD ........................................................................................................................... 4

1 Scope ............................................................................................................................... 6

2 Terms and definitions ....................................................................................................... 6

3 Acoustical environment .................................................................................................... 9

3.1 Ambient noise ......................................................................................................... 9

3.2 Wind conditions ....................................................................................................... 9

3.3 Air condition ............................................................................................................ 9

3.4 Local topography ..................................................................................................... 9

4 Instrumentation .............................................................................................................. 10

4.1 Sound level meter ................................................................................................. 10

4.1.1 General ..................................................................................................... 10

4.1.2 Preferred sound level meter....................................................................... 10

4.1.3 Peak and time average .............................................................................. 10

4.2 Calibration capability ............................................................................................. 10

4.3 Supplemental instrumentation ............................................................................... 10

5 Type test methods .......................................................................................................... 10

5.1 General test requirements ..................................................................................... 10

5.1.1 General ..................................................................................................... 10

5.1.2 Sound pressure level measurements ......................................................... 10

5.1.3 No load conditions ..................................................................................... 11

5.1.4 Impulse noise measurement ...................................................................... 11

5.1.5 Location of microphone ............................................................................. 11

5.1.6 Orientation of microphone ......................................................................... 11

5.2 Near-field measurements ...................................................................................... 11

5.2.1 Type of noise measurements ..................................................................... 11

5.2.2 Near field measurement with fully opened doors ........................................ 12

5.2.3 Near field measurement with fully closed doors ......................................... 12

5.3 Far-field measurements ......................................................................................... 12

5.3.1 Type of noise measurements ..................................................................... 12

5.3.2 Far field measurement ............................................................................... 13

5.3.3 Equivalent data ......................................................................................... 14

5.4 Data ...................................................................................................................... 14

5.4.1 General ..................................................................................................... 14

5.4.2 Circuit-breaker being tested ....................................................................... 14

5.4.3 Environment .............................................................................................. 15

5.4.4 Instrumentation.......................................................................................... 15

5.4.5 Acoustical data .......................................................................................... 15

5.4.6 Miscellaneous ............................................................................................ 15

5.5 Report ................................................................................................................... 15

5.5.1 Completeness of the report........................................................................ 15

5.5.2 Conversion ................................................................................................ 15

6 Field test methods .......................................................................................................... 17

6.1 General ................................................................................................................. 17

6.2 Wind conditions ..................................................................................................... 17

6.3 Circuit-breaker operating conditions ...................................................................... 17

6.3.1 Operating conditions .................................................................................. 17

---------------------- Page: 4 ----------------------
62271-37-082 © IEC/IEEE:2012(E) – 3 –

6.3.2 Specific conditions..................................................................................... 17

6.3.3 Measurements ........................................................................................... 17

6.4 Microphone locations ............................................................................................ 17

7 Measurements to be taken ............................................................................................. 18

7.1 Limitation of the measurement .............................................................................. 18

7.2 Measurement of impulsive noise............................................................................ 18

7.3 Data and report ..................................................................................................... 18

Bibliography .......................................................................................................................... 19

Figure 1 – Location of measurement points with respect to the reference

parallelepiped for near field measurements ........................................................................... 12

Figure 2 – Location of measurement points with respect to circuit-breaker outline for

far field measurements ......................................................................................................... 14

Figure 3 – Measurement of sound pressure levels of a.c. circuit-breakers – Record

form ...................................................................................................................................... 16

Table 1 – Wind conditions for sound measurements ............................................................... 9

---------------------- Page: 5 ----------------------
– 4 – 62271-37-082 © IEC/IEEE:2012(E)
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
HIGH-VOLTAGE SWITCHGEAR AND CONTROLGEAR –
Part 37-082: Standard practice for the measurement of sound
pressure levels on alternating current circuit-breakers
FOREWORD

1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising

all national electrotechnical committees (IEC National Committees). The object of IEC is to promote

international co-operation on all questions concerning standardization in the electrical and electronic fields. To

this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,

Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC

Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested

in the subject dealt with may participate in this preparatory work. International, governmental and non-

governmental organizations liaising with the IEC also participate in this preparation.

IEEE Standards documents are developed within IEEE Societies and Standards Coordinating Committees of the

IEEE Standards Association (IEEE-SA) Standards Board. IEEE develops its standards through a consensus

development process, which brings together volunteers representing varied viewpoints and interests to achieve

the final product. Volunteers are not necessarily members of IEEE and serve without compensation. While IEEE

administers the process and establishes rules to promote fairness in the consensus development process, IEEE

does not independently evaluate, test, or verify the accuracy of any of the information contained in its

standards. Use of IEEE Standards documents is wholly voluntary. IEEE documents are made available for use

subject to important notices and legal disclaimers (see http://standards.ieee.org/IPR/disclaimers.html for more

information).

IEC collaborates closely with IEEE in accordance with conditions determined by agreement between the two

organizations.

2) The formal decisions of IEC on technical matters express, as nearly as possible, an international consensus of

opinion on the relevant subjects since each technical committee has representation from all interested IEC

National Committees. The formal decisions of IEEE on technical matters, once consensus within IEEE Societies

and Standards Coordinating Committees has been reached, is determined by a balanced ballot of materially

interested parties who indicate interest in reviewing the proposed standard. Final approval of the IEEE

standards document is given by the IEEE Standards Association (IEEE-SA) Standards Board.

3) IEC/IEEE Publications have the form of recommendations for international use and are accepted by IEC

National Committees/IEEE Societies in that sense. While all reasonable efforts are made to ensure that the

technical content of IEC/IEEE Publications is accurate, IEC or IEEE cannot be held responsible for the way in

which they are used or for any misinterpretation by any end user.

4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications

(including IEC/IEEE Publications) transparently to the maximum extent possible in their national and regional

publications. Any divergence between any IEC/IEEE Publication and the corresponding national or regional

publication shall be clearly indicated in the latter.

5) IEC and IEEE do not provide any attestation of conformity. Independent certification bodies provide conformity

assessment services and, in some areas, access to IEC marks of conformity. IEC and IEEE are not responsible

for any services carried out by independent certification bodies.

6) All users should ensure that they have the latest edition of this publication.

7) No liability shall attach to IEC or IEEE or their directors, employees, servants or agents including individual

experts and members of technical committees and IEC National Committees, or volunteers of IEEE Societies

and the Standards Coordinating Committees of the IEEE Standards Association (IEEE-SA) Standards Board,

for any personal injury, property damage or other damage of any nature whatsoever, whether direct or indirect,

or for costs (including legal fees) and expenses arising out of the publication, use of, or reliance upon, this

IEC/IEEE Publication or any other IEC or IEEE Publications.

8) Attention is drawn to the normative references cited in this publication. Use of the referenced publications is

indispensable for the correct application of this publication.

9) Attention is drawn to the possibility that implementation of this IEC/IEEE Publication may require use of

material covered by patent rights. By publication of this standard, no position is taken with respect to the

existence or validity of any patent rights in connection therewith. IEC or IEEE shall not be held responsible for

identifying Essential Patent Claims for which a license may be required, for conducting inquiries into the legal

validity or scope of Patent Claims or determining whether any licensing terms or conditions provided in

connection with submission of a Letter of Assurance, if any, or in any licensing agreements are reasonable or

non-discriminatory. Users of this standard are expressly advised that determination of the validity of any patent

rights, and the risk of infringement of such rights, is entirely their own responsibility.

---------------------- Page: 6 ----------------------
62271-37-082 © IEC/IEEE:2012(E) – 5 –

International Standard IEC/IEEE 62271-37-082 has been prepared by subcommittee 17A:

High-voltage switchgear and controlgear, of IEC technical committee 17: Switchgear and

controlgear, in cooperation with the Switchgear Committee of the IEEE Power & Energy

Society , under the IEC/IEEE Dual Logo Agreement between IEC and IEEE.
This publication is published as an IEC/IEEE Dual Logo standard.
The text of this standard is based on the following IEC documents:
FDIS Report on voting
17A/1014/FDIS 17A/1023/RVD

Full information on the voting for the approval of this standard can be found in the report on

voting indicated in the above table.

International standards are drafted in accordance with the rules given in the ISO/IEC

Directives, Part 2.

A list of all parts of the IEC 62271 series can be found, under the general title High-voltage

switchgear and controlgear, on the IEC website.

The IEC Technical Committee and IEEE Technical Committee have decided that the contents

of this publication will remain unchanged until the stability date indicated on the IEC web site

under "http://webstore.iec.ch" in the data related to the specific publication. At this date, the

publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
A bilingual version of this standard may be issued at a later date.
The contents of the corrigendum of January 2014 have been included in this copy.
—————————
A list of IEEE participants can be found at the following URL:

http://standards.ieee.org/downloads/62271-37-082/62271-37-082-2012/62271-37-082_wg-participants.pdf

---------------------- Page: 7 ----------------------
– 6 – 62271-37-082 © IEC/IEEE:2012(E)
HIGH-VOLTAGE SWITCHGEAR AND CONTROLGEAR –
Part 37-082: Standard practice for the measurement of sound
pressure levels on alternating current circuit-breakers
1 Scope

This part of International Standard 62271 provides methods for the measurement of sound

pressure level produced by outdoor alternating current circuit-breakers in a free-field

environment. These methods may also be used indoors or in restricted field, provided that

precautions are observed in the measurement and interpretation of the results.
2 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
2.1
A-weighted sound level

sound level as measured on a sound level meter using a setting that emphasizes the middle

frequency components similar to the frequency response of the human ear at levels typical of

rural backgrounds in mid frequencies
2.2
ambient noise

all noises that exist in an area that are not related to a facility or equipment under

consideration

Note 1 to entry: Ambient noise includes sound from other industrial noise, transportation sources, animals, and

nature, etc.
2.3
ambient sound level
ASL

sound level that is a composite of different airborne sounds from many sources far away from

and near the point of measurement

Note 1 to entry: The ASL does not include any sound from the facility or equipment under consideration and is

measured without it.
Note 2 to entry: The ASL is measured under representative conditions.

Note 3 to entry: As with comprehensive sound levels, representative conditions do not constitute absolute worst-

case conditions but conditions that portray typical conditions for the area
2.4
bands
octave
1/3 octave

series of electronic filters separate sound into discrete frequency bands, making it possible to

know how sound energy is distributed as a function of frequency

Note 1 to entry: Each octave band has a centre frequency that is double the centre frequency of the octave band

preceding it. The 1/3 octave band analysis provides a finer breakdown of sound distribution as a function of

frequency.
---------------------- Page: 8 ----------------------
62271-37-082 © IEC/IEEE:2012(E) – 7 –
2.5
C-weighted sound level

approximation of the sensitivity of human hearing at industrial noise levels (above about

85 dBA)

Note 1 to entry: The C-weighted sound level (i.e., measured with the C-weighting) is more sensitive to sounds at

low frequencies than the A-weighted sound level and is sometimes used to assess the low-frequency content of

complex sound environments.
2.6
calibration

procedure used for the adjustment of a sound level meter using a reference source of a

known sound pressure level and frequency
2.7
decibel

unit of measure of sound pressure that compresses a large range of numbers into a more

meaningful scale

Note 1 to entry: Hearing tests indicate that the lowest audible pressure is about 2 × 10 Pa (0 dB), while the

sensation of pain is about 2 × 10 Pa (140 dB). Generally, an increase of 10 dB is perceived as twice as loud.

 
p  p 
 
Sound pressure level (dB) = 10 log = 20 log 
 
 2
 0
 
where
p is the root-mean-square of the sound pressure (in Pa);

p is the reference root-mean-square-sound of the sound pressure, generally 2 × 10 Pa.

The decibel is a linear weighting and can also be used when referring to differences in weightings.

...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
