IEC 60695-10-2:2014

Fire hazard testing - Part 10-2: Abnormal heat - Ball pressure test method

IEC 60695-10-2:2014 specifies the ball pressure test as a method for evaluating the softening temperature and accelerated material flow under load of polymeric materials and parts of end products in their ability to resist abnormal heat. It is applicable to the materials used in electrotechnical equipment, subassemblies and components, and to solid electrical insulating materials except ceramics. The Ball Pressure test method is not appropriate for certain elastomers, foamed materials, and other materials that tend to be soft at room temperature. Product Committees are encouraged to evaluate these materials using other methods such as IEC 60695-10-3. This third edition cancels and replaces the second edition of IEC 60695-10-2 published in 2003. It constitutes a technical revision. The main changes with respect to the previous edition are as follows:
- The addition of an introduction introduces the user to the basic guidance documents published by TC 89,
- Addition of a reference to IEC Guide 104 and ISO/IEC Guide 51 in the Scope,
- Additional relevant Terms and Definitions in new Clause 3,
- 5.2: Additional requirements to the test specimen support at the suggestion of IECEE-CTL to improve reproducibility,
- 5.3: Clarification of heating oven requirements at the suggestion of IECEE-CTL to improve reproducibility,
- 5.4: Specification of minimum resolution consistent with method requirements for optical measurement instrument,
- New Test Procedure in Clauses 6 and 8 which introduces separate methods for End Product proof testing (Method A) and material performance testing (Method B) and
- Updated Clause 11 Test Report to be consistent with other IEC 60695 documents.
Key words: Abnormal heat, Ball pressure test method, Fire hazard

Essais relatifs aux risques du feu - Partie 10-2: Chaleurs anormales - Essai à la bille

IEC 60695-10-2:2014 spécifie l'essai à la bille comme méthode d'essai permettant d'évaluer la température de ramollissement et le flux accéléré sous charge des polymères et parties de produits finis, afin de vérifier leur aptitude à résister à un échauffement anormal. Elle est applicable aux matériaux utilisés dans les matériels, sous-ensembles et composants électrotechniques, et aux matériaux isolants électriques solides à l'exception des céramiques. L'essai à la bille n'est pas approprié à certains élastomères, matériaux alvéolaires et autres matériaux qui présentent une tendance au ramollissement à la température ambiante. Les comités de produits sont encouragés à évaluer ces matériaux en appliquant d'autres méthodes, telles que celles de l'IEC 60695-10-3. Cette troisième édition annule et remplace la deuxième édition de l'IEC 60695-10-2 publiée en 2003. Elle constitue une révision technique. Les principales modifications apportées par rapport à l'édition précédente sont énumérées ci-dessous:
- Ajout d'une introduction qui renseigne l'utilisateur sur les documents directeurs de base publiés par le CE 89,
- Ajout d'une référence au Guide IEC 104 et au Guide ISO/IEC 51 dans le Domaine d'application,
- Ajout d'un nouvel Article 3 comportant des termes et définitions pertinents,
- 5.2: Exigences supplémentaires applicables au support d'éprouvette d'essai sur proposition du IECEE-CTL, afin d'améliorer la reproductibilité,
- 5.3: Clarification des exigences applicables à l'étuve sur proposition du IECEE-CTL, afin d'améliorer la reproductibilité,
- 5.4: Spécification d'une résolution minimale cohérente avec les exigences relatives aux méthodes utilisant un instrument de mesure optique,
- Nouveau mode opératoire d'essai aux Articles 6 et 8, qui présente des méthodes distinctes pour les essais de validité de produit fini (Méthode A) et les essais de performance des matériaux (Méthode B), et
- Mise à jour de l'Article 11 Rapport d'essai pour alignement avec les autres documents de l'IEC 60695.
Mots-clés: Echauffement anormal, essai à la bille, risques du feu

General Information

• Status: Published
• Publication Date: 18-Feb-2014
• ICS: 13.220.40 - Ignitability and burning behaviour of materials and products
• ICS: 29.020 - Electrical engineering in general
• ICS: 31.040.10 - Fixed resistors
• Technical Committee: TC 89 - Fire hazard testing
• Drafting Committee: WG 12 - TC 89/WG 12
• Current Stage: PPUB - Publication issued
• Start Date: 19-Feb-2014
• Completion Date: 28-Feb-2014

Relations

• Revises: IEC 60695-10-2:2003/COR1:2006 - Corrigendum 1 - Fire hazard testing - Part 10-2: Abnormal heat - Ball pressure test
• Effective Date: 05-Sep-2023
• Revises: IEC 60695-10-2:2003 - Fire hazard testing - Part 10-2: Abnormal heat - Ball pressure test
• Effective Date: 05-Sep-2023

Overview

IEC 60695-10-2:2014, titled Fire hazard testing - Part 10-2: Abnormal heat - Ball pressure test method, is an international standard developed by the International Electrotechnical Commission (IEC). This standard specifies the ball pressure test to evaluate the softening temperature and the behavior of polymeric materials and components under mechanical load and elevated temperatures. The primary aim is to assess the resistance of these materials to abnormal heat conditions, which is critical for ensuring fire safety in electrotechnical equipment.

This test method focuses on the deformation characteristics of polymeric materials (excluding ceramics) when subjected to heat and pressure, providing valuable data on material performance under thermal stress. It is applicable to materials used in electrical insulating parts, subassemblies, and components but is not suitable for certain elastomers, foamed materials, or polymers that are soft at room temperature.

Key Topics

• Ball Pressure Test Method: This test involves placing a weighted ball on a material sample heated in an oven to monitor its softening and deformation under load.
• Material Softening Temperature: Determines the temperature at which a polymeric material begins to soften and deform under pressure.
• Test Procedures: The standard outlines two separate methods:
  • Method A: For end product proof testing to evaluate the performance of the final manufactured product.
  • Method B: For material performance testing focusing on raw material properties.
• Test Apparatus Requirements: Specifications include:
  • Loading device with accurate application of the ball pressure.
  • Heating oven with precise temperature controls to ensure uniform heating.
  • Optical measuring instruments with minimum resolution levels for accurate deformation measurement.
• Test Specimen Preparation and Conditioning: Clear guidelines on test specimen size, conditioning methods, and environmental factors impacting accuracy and reproducibility.
• Data Reporting and Reproducibility Enhancements: Updated requirements for test specimen support and oven specifications aim to improve test result consistency.

Applications

• Material Selection in Electrotechnical Equipment: Helps manufacturers evaluate polymeric insulating materials and components for their ability to withstand abnormal heat without losing mechanical integrity.
• Fire Safety Assessment: Provides critical data for assessing fire hazards related to material behavior under thermal stress, supporting product safety designs that reduce ignition risk and fire spread.
• Quality Control and Compliance Testing: Used by product committees and manufacturers during development and production phases to ensure materials conform to safety standards.
• Research and Development: Offers a standardized method for comparing different polymeric materials' heat resistance and mechanical stability under abnormal heating scenarios.

Related Standards

• IEC 60695-1-10 & IEC 60695-1-11: These companion standards provide methodologies for preventing ignition and confining fire within electrotechnical enclosures, complementing the material behavior insights gained from IEC 60695-10-2.
• IEC 60695-10-3: An alternative test method recommended for elastomers, foamed material, and other polymers unsuitable for the ball pressure test.
• IEC Guide 104 and ISO/IEC Guide 51: These guides offer foundational safety principles and risk assessment frameworks referenced within IEC 60695-10-2 for evaluating and managing fire hazards.

---

By adhering to IEC 60695-10-2:2014, manufacturers and safety engineers can reliably evaluate polymer material performance against abnormal heat, enhancing fire hazard assessments and ensuring safer electrotechnical products worldwide. This standard plays a crucial role in product safety compliance, helping reduce fire risks through improved material selection and testing methodologies.
