IEC 61000-4-5:2014

Electromagnetic compatibility (EMC) - Part 4-5: Testing and measurement techniques - Surge immunity test

IEC 61000-4-5:2014 relates to the immunity requirements, test methods, and range of recommended test levels for equipment with regard to unidirectional surges caused by over-voltages from switching and lightning transients. Several test levels are defined which relate to different environment and installation conditions. These requirements are developed for and are applicable to electrical and electronic equipment. The object of this standard is to establish a common reference for evaluating the immunity of electrical and electronic equipment when subjected to surges. The test method documented describes a consistent method to assess the immunity of an equipment or system against a defined phenomenon. This standard defines a range of:
- test levels;
- test equipment;
- test setups; and
- test procedures. The task of the described laboratory test is to find the reaction of the equipment under test (EUT) under specified operational conditions to surge voltages caused by switching and lightning effects. It is not intended to test the capability of the EUT's insulation to withstand high-voltage stress. Direct injections of lightning currents, i.e. direct lightning strikes, are not considered in this standard. This third edition cancels and replaces the second edition published in 2005, and constitutes a technical revision which includes the following significant technical changes with respect to the previous edition:
- a new Annex E on mathematical modelling of surge waveforms;
- a new Annex F on measurement uncertainty;
- a new Annex G on method of calibration of impulse measuring systems; and
- a new Annex H on coupling/decoupling surges to lines rated above 200 A. Moreover while surge test for ports connected to outside telecommunication lines was addressed in 6.2 of the second edition (IEC 61000-4-5:2005), in this third edition (IEC 61000-4-5:2014) the normative Annex A is fully dedicated to this topic. In particular it gives the specifications of the 10/700 µs combined wave generator. Keywords: electromagnetic compatibility, EMC, TC77, SC77B

Compatibilité électromagnétique (CEM) - Partie 4-5: Techniques d'essai et de mesure - Essai d'immunité aux ondes de choc

L'IEC 61000-4-5:2014 se rapporte aux exigences d'immunité pour les matériels, aux méthodes d'essai et à la gamme des niveaux d'essai recommandés, vis-à-vis des ondes de choc unidirectionnelles provoquées par des surtensions dues aux transitoires de foudre et de man uvre. Elle définit plusieurs niveaux d'essai se rapportant à différentes conditions d'environnement et d'installation. Ces exigences sont développées pour les matériels électriques et électroniques et leur sont applicables. Cette norme a pour objet d'établir une référence commune dans le but d'évaluer l'immunité des matériels électriques et électroniques, quand ils sont soumis à des ondes de choc. La méthode d'essai documentée décrit une méthode cohérente en vue d'évaluer l'immunité d'un matériel ou d'un système vis-à-vis d'un phénomène défini. La présente norme définit:
- une gamme de niveaux d'essai;
- le matériel d'essai;
- les montages d'essai; et
- les procédures d'essai. L'essai de laboratoire décrit ici a pour but de déterminer la réaction du matériel en essai (EUT), dans des conditions opérationnelles spécifiées, aux surtensions dues à la foudre ou à des manoeuvres. Il n'est pas destiné à évaluer la capacité de l'isolation de l'EUT à supporter des tensions élevées. Les injections directes de courants de foudre, par exemple les coups de foudre directs, ne sont pas prises en compte par la présente norme. Cette troisième édition annule et remplace la deuxième édition publiée 2005, et constitue une révision technique qui inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
- une nouvelle Annexe E sur la modélisation mathématique des formes d'ondes de choc;
- une nouvelle Annexe F sur les incertitudes de mesure;
- une nouvelle Annexe G sur la méthode d'étalonnage des systèmes de mesure d'impulsion; et
- une nouvelle Annexe H sur les ondes de choc de couplage/découplage appliquées à des lignes de valeurs assignées supérieures à 200 A. De plus, alors que l'essai à l'onde de choc sur les accès connectés à des lignes de télécommunication extérieures était traité dans le 6.2 de la deuxième édition (IEC 61000-4-5:2005), dans cette troisième édition (IEC 61000-4-5:2014), l'Annexe normative A est complètement dédiée à ce sujet. En particulier elle donne les spécifications du générateur d'onde combinée 10/700 µs. Mots clé: Compatibilité électromagnétique, EMC, CEM, TC77, SC77B

General Information

• Status: Published
• Publication Date: 14-May-2014
• ICS: 33.100.20 - Immunity
• Technical Committee: SC 77B - High frequency phenomena
• Drafting Committee: MT 12 - TC 77/SC 77B/MT 12
• Current Stage: PPUB - Publication issued
• Start Date: 15-May-2014
• Completion Date: 15-May-2014

Relations

• Amended By: IEC 61000-4-5:2014/AMD1:2017 - Amendment 1 - Electromagnetic compatibility (EMC) - Part 4-5: Testing and measurement techniques - Surge immunity test
• Effective Date: 05-Sep-2023
• Revises: IEC 61000-4-5:2005/COR1:2009 - Corrigendum 1 - Electromagnetic compatibility (EMC) - Part 4-5: Testing and measurement techniques - Surge immunity test
• Effective Date: 05-Sep-2023
• Revises: IEC 61000-4-5:2005 - Electromagnetic compatibility (EMC) - Part 4-5: Testing and measurement techniques - Surge immunity test
• Effective Date: 05-Sep-2023

Overview

IEC 61000-4-5:2014 is an international standard developed by the International Electrotechnical Commission (IEC) focusing on electromagnetic compatibility (EMC). This standard addresses testing and measurement techniques specifically for the surge immunity test of electrical and electronic equipment. It defines immunity requirements and test methods to evaluate equipment performance under unidirectional surge conditions caused by switching operations and lightning transients. The standard provides a common framework to assess equipment robustness against such transient over-voltages.

This 2014 edition replaces the 2005 version and includes major revisions such as added annexes on mathematical modeling of surge waveforms, measurement uncertainty, calibration of impulse measuring systems, and surge coupling/decoupling for high-current lines. It also adds a dedicated normative annex addressing surge testing for telecommunication lines connected to outdoor environments.

Key Topics

• Surge Immunity Requirements: Specifies immunity thresholds equipment must meet to withstand surges typical of over-voltages from switching and lightning.
• Test Levels: Defines various surge voltage/current waveforms and amplitude levels representing different environmental conditions and installation scenarios.
• Test Equipment and Setup: Includes detailed specifications for combination wave generators (notably the 1.2/50 µs voltage wave and 8/20 µs current waveforms), coupling/decoupling networks for power and interconnection lines, and test arrangement protocols.
• Measurement and Calibration: Provides guidance on calibrating surge generators and impulse measuring systems to ensure accurate and repeatable test results.
• Surge Waveform Modeling: Introduces mathematical models for transient waveforms enhancing simulation accuracy.
• Measurement Uncertainty: Addresses factors affecting precision in surge measurements and establishes methods to quantify and minimize uncertainties.
• Specialized Testing: Normative annexes define procedures for testing unshielded outdoor symmetrical communication lines with a 10/700 µs impulse and considerations for lines rated above 200 A.

Applications

IEC 61000-4-5:2014 is crucial for manufacturers, test laboratories, and compliance bodies involved in:

• Electrical and Electronic Equipment Design: Ensures products such as industrial machinery, consumer electronics, and communication devices meet required surge immunity levels for reliable operation.
• Quality Assurance Testing: Provides a standard method for assessing equipment resilience against transient over-voltage events during design validation and routine production testing.
• Installation and System Safety: Helps integrators and engineers implement surge protection strategies in power distribution and telecommunication systems to reduce equipment failures caused by switching surges or indirect lightning strikes.
• Certification and Compliance: Supports global regulatory compliance by standardizing surge immunity evaluation in line with EMC directives and safety regulations.
• Research and Development: Offers a foundation for further innovation in EMC testing techniques, including improved simulation, measurement accuracy, and surge mitigation technologies.

Related Standards

• IEC 61000-4 Series: IEC 61000-4-x standards collectively cover various EMC testing methods, including radiated immunity, electric fast transients, and conducted disturbances.
• IEC 61000-2-x Series: Defines the environment and installation conditions related to EMC phenomena.
• IEC 62305 Series: Focuses on lightning protection standards which complement surge immunity testing by addressing direct strikes and protection system design.
• ISO/IEC 17025: Specifies general requirements for test laboratories performing EMC testing to ensure competence and reliability.
• Telecommunication EMC Standards: Specific documents addressing immunity of telecommunication equipment to surges often reference IEC 61000-4-5 for test methodologies.

---

Keywords: electromagnetic compatibility, EMC, surge immunity test, IEC 61000-4-5, combination wave generator, test procedure, over-voltage, switching transients, lightning surge, coupling/decoupling networks, test levels, measurement uncertainty, impulse measuring systems, telecommunication line testing.
