IEC 62246-1:2011

Reed switches - Part 1: Generic specification

IEC 62246-1:2011 applies to all types of reed switches including magnetically biased reed switches of assessed quality for use in general and industrial applications. It lists the tests and measurement procedures which may be selected for use in detail specifications for such reed switches. It also specifies the quality assessment procedures to be followed. This new edition includes the following significant technical changes with respect to the previous one:
- inclusion of the generic specifications for all types of reed switches, but mercury wetted reed switches have been removed from the scope due to their potential for environmental impact;
- inclusion of three fundamental conformity assessment procedures for quality assessment.

Contacts à lames souples - Partie 1: Spécification générique

La CEI 62246-1:2011 s'applique à tous les types de contacts à lames souples, y compris les contacts à lames souples polarisés magnétiquement ayant une qualité assurée pour être utilisés dans des applications générales et industrielles. Elle énumère les essais et les procédures de mesure qui peuvent être sélectionnés pour être utilisés dans des spécifications particulières relatives à de tels contacts à lames souples. Elle spécifie également les procédures d'évaluation de la qualité devant être suivies. La présente nouvelle édition comporte les modifications techniques significatives suivantes par rapport à l'édition précédente:
- ajout de spécifications génériques pour tous les types de contacts à lames souples, mais les contacts à lames souples mouillés au mercure ont été retirés du domaine d'application en raison de leur potentiel d'impact sur l'environnement;
- ajout de trois procédures fondamentales d'évaluation de la conformité pour l'évaluation de la qualité.

General Information

• Status: Published
• Publication Date: 09-Feb-2011
• ICS: 29.120.70 - Relays
• Technical Committee: TC 94 - Electrical relays
• Drafting Committee: WG 6 - TC 94/WG 6
• Current Stage: DELPUB - Deleted Publication
• Start Date: 28-Jan-2015
• Completion Date: 26-Oct-2025

Relations

• Replaces: IEC 62246-2:2007 - Reed contact units - Part 2: Heavy-duty reed switches
• Effective Date: 05-Sep-2023
• Revises: IEC 62246-1:2002 - Reed contact units - Part 1: Generic specification
• Effective Date: 05-Sep-2023
• Revised: IEC 62246-1:2015 - Reed switches - Part 1: Generic specification
• Effective Date: 05-Sep-2023

Overview

IEC 62246-1:2011 is an international standard developed by the International Electrotechnical Commission (IEC) detailing the generic specifications for reed switches. This standard applies to all types of reed switches, including magnetically biased reed switches, which are widely used in both general and industrial applications. Notably, mercury wetted reed switches have been excluded from the scope of this edition due to environmental concerns. The document defines essential tests, measurement procedures, and quality assessment methodologies essential to ensure reed switch performance and reliability.

This edition introduces significant updates, such as:

• Inclusion of generic specifications covering all types of reed switches (except mercury wetted types).
• Introduction of three fundamental conformity assessment procedures for quality assurance.

IEC 62246-1:2011 acts as a foundational reference that helps manufacturers, designers, and quality engineers align their products with internationally recognized standards, facilitating market access and ensuring consistent quality.

Key Topics

The standard covers several critical aspects of reed switch specifications, including:

• Terms and Definitions: Clear definitions related to reed switch types, operating values, contact characteristics, and timing parameters.
• Rated Values: Specifications related to electrical ratings such as current, load, frequency, open-circuit voltage, operating cycles, climatic categories, and surge voltages.
• Marking: Requirements for identifiable and traceable product markings.
• Quality Assessment Procedures:
  • Supplier’s Declaration of Conformity
  • Second-party conformity assessments
  • Third-party certification
  • IECEE and IECQ schemes for consistent manufacturing quality
• Test and Measurement Procedures:
  • Visual inspections and dimensional checks
  • Functional and remanence tests
  • Contact resistance and dielectric tests
  • Insulation resistance and operating time measurements
  • Sticking, robustness of terminals, solderability
  • Climatic tests including damp heat, rapid temperature changes, salt mist exposure
  • Mechanical stress tests such as vibration, shock, and acceleration
  • Electrical endurance testing under various load conditions
• Environmental and Reliability Considerations: Ensuring reed switches meet operational demands under realistic environmental stresses.

By providing detailed procedures for these essential tests, the standard supports manufacturers in producing reliable, high-performance reed switches adhering to international quality benchmarks.

Applications

IEC 62246-1:2011 is relevant for a wide spectrum of industries and applications where reed switches play a crucial role, such as:

• Industrial Automation: Reed switches are critical components in control systems, sensors, and safety devices.
• Consumer Electronics: Used in proximity sensing, position detection, and user interface controls.
• Automotive Industry: Applied in safety systems, door position detection, and component monitoring.
• Medical Devices: Ensuring reliable switching in diagnostic and treatment equipment.
• Security Systems: Utilized in alarm activation and intrusion detection technologies.
• Home Appliances & HVAC: For device operation feedback, door sensors, and temperature control systems.

By adhering to IEC 62246-1, manufacturers ensure their reed switches deliver high reliability, environmental compliance, and long service life, which is vital for safety-critical and precise applications.

Related Standards

For comprehensive compliance and design optimization, the following standards and resources are closely related to IEC 62246-1:

• IEC 62246-2: Part 2, which may cover detail specifications and application guidance for reed switches.
• IEC 60068 Series: Environmental testing standards that support the climatic and mechanical testing procedures referenced.
• IECEE and IECQ Systems: Standards facilitating conformity assessments and quality control certifications.
• Electropedia (IEC Online Dictionary): A valuable resource for electrical and electronic terminology related to reed switches.
• International environmental standards related to hazardous substances for components, particularly addressing mercury restrictions.

Adopting these standards alongside IEC 62246-1 enables a harmonized approach to reed switch design, testing, and certification.

---

Keywords: IEC 62246-1, reed switches, generic specification, reed switch testing, magnetically biased reed switch, quality assessment procedures, electrical endurance, climatic testing, industrial applications, IEC standards, compliance, conformity assessment.
