IEC TR 63309: 2025, which is a Technical Report, provides an introduction of active fibres describing key characteristics and measurement methods. For the purpose of this document, an active fibre is a silica-based optical fibre doped in the core with rare-earth ions to allow optical gain, named rare-earth doped fibre. Other fibres enabling optical gain by means of different effects (e.g. Raman effect) are not included in the scope of this document.

General Information

• Status: Published
• Publication Date: 04-Jun-2025
• ICS: 33.180.10 - Fibres and cables
• Technical Committee: SC 86A - Fibres and cables
• Drafting Committee: WG 1 - TC 86/SC 86A/WG 1
• Current Stage: PRVDTR - Preparation of RVDTR
• Start Date: 13-Dec-2024
• Completion Date: 13-Dec-2024

Overview

IEC TR 63309:2025 - Active fibres – Characteristics and measurement methods – Guidance - is a Technical Report from the IEC that introduces active fibres, defined here as silica-based optical fibres whose cores are doped with rare-earth ions (rare‑earth doped fibre) to provide optical gain. Edition 1.0 (2025‑06) summarizes key characteristics, classification, and practical measurement methods used for characterizing active fibres for use in fibre lasers and fibre amplifiers. The scope explicitly excludes fibres that rely on other gain mechanisms (e.g., Raman-effect fibres).

Key topics

• Background & classification
  • Definition of active fibres and rare‑earth elements (Er, Yb, Nd, Tm, etc.)
  • Cladding and core geometries affecting pump coupling and gain
• Key characteristics analyzed
  • Fibre geometry (core/inner-cladding cross sections)
  • Optical characteristics: attenuation, numerical aperture (NA)
  • Laser transmission characteristics: absorption coefficient, slope efficiency, high‑power scaling, and photodarkening
  • Nonlinear and limiting effects: mode instability (MI), stimulated Raman scattering (SRS), stimulated Brillouin scattering (SBS)
• Measurement method guidance
  • General measurement principles and recommended apparatus layouts (pump calibration, oscillator/amplifier test setups)
  • Detailed guidance sections for slope efficiency, absorption coefficient, optical‑to‑optical conversion efficiency, photodarkening, and high‑power scaling
  • Practical notes on sample preparation, test procedures and data interpretation (figures and schematic diagrams support setup design)
• Informative annex
  • Annex A provides typical applications (e.g., Er‑doped fibre amplifiers) and contextual examples

Applications and practical value

IEC TR 63309 is practical guidance for:

• Manufacturers of rare‑earth doped fibres validating product performance (attenuation, slope efficiency, photodarkening resistance)
• Test laboratories developing reproducible measurement procedures and test rigs for fibre characterization
• Laser and amplifier designers selecting active fibre types and assessing high power scaling and nonlinear limits (SRS/SBS, MI)
• Component suppliers and system integrators optimizing pump coupling, numerical aperture and cladding shapes for improved pumping efficiency

The report helps translate laboratory metrics into system‑level expectations for fibre lasers, high‑power amplifiers, and precision optical amplifiers used in industrial, telecom and scientific applications.

Related standards

• IEC TR 61931 - Fibre optic terminology
• IEC TS 62627‑09 - Vocabulary for passive optical devices
• References also note IEC TR 61282‑4 regarding SRS/SBS phenomena

Keywords: IEC TR 63309, active fibres, rare‑earth doped fibre, fibre laser, measurement methods, slope efficiency, photodarkening, absorption coefficient, numerical aperture.
