Overview

IEC 60335-2-86:2002 is the IEC particular-requirements standard for the safety of electric fishing machines - appliances that electrify water to catch fish or to create barriers for animals living in water. It is a Part 2 standard that supplements IEC 60335-1 (general safety for household and similar electrical appliances). The scope covers mains‑operated and battery‑operated units: portable machines with rated voltage up to 250 V, and fixed machines permanently connected to fixed wiring with rated voltage up to 1000 V.

Key Topics and Requirements

This standard addresses safety risks and test conditions specific to electric fishing machines, including:

• Definitions and scope: clear definitions for terms such as electrode, output circuit, output voltage/current, impulse and pulsed voltage.
• Construction and protection: requirements for guarding live parts, protection against access to live parts, provision for earthing and secure terminals.
• Electrical output characteristics: treatment of pulsed voltages and impulses (an impulse is defined as the pulsed voltage portion exceeding 12 V).
• Rated voltages and classifications: portable <250 V, fixed ≤1000 V; battery‑operated units meeting safety extra‑low voltage constraints.
• Testing and test conditions: general test methods as motor‑operated appliances, polarity and worst‑case connection considerations, environmental tests (includes reference to salt‑mist cyclic test IEC 60068‑2‑52).
• Safety performance: leakage current, electric strength, transient overvoltages, moisture resistance, overload protection and endurance under abnormal conditions.
• Marking and instructions: manufacturer information, connections, polarity, and safe use instructions.
• Normative references: includes IEC 60335‑1, IEC 60068‑2‑52 and IEC 61558‑2‑4 among others.

Practical Applications and Who Uses It

IEC 60335-2-86 is used by:

• Manufacturers and designers of electric fishing machines for product design, compliance and CE marking.
• Test laboratories verifying compliance with electrical safety, leakage, insulation and environmental tests.
• Regulatory bodies and procurement teams that set safety requirements for commercial, research or fisheries equipment.
• Safety engineers and certification bodies performing conformity assessments.

Note: national rules may restrict use (e.g., some countries limit electric fishing machines to research use).

Related Standards

• IEC 60335‑1 - General requirements for household and similar electrical appliances (base standard).
• IEC 60335‑2‑76 - Electric fence energizers (excluded from this part).
• IEC 60335‑2‑87 - Electric animal stunning equipment (excluded).
• IEC 60068‑2‑52 - Environmental testing (salt mist).
• IEC 61558‑2‑4 - Safety of isolating transformers (referenced for associated circuits).

Keywords: IEC 60335-2-86, electric fishing machines, safety standard, IEC 60335-1, output voltage, electrodes, mains-operated, battery-operated.
