1 Scope
This part of IEC 62880 describes a constant temperature (isothermal) aging method for
testing copper (Cu) metallization test structures on microelectronics wafers for susceptibility
to stress-induced voiding (SIV). This method is to be conducted primarily at the wafer level of
production during technology development, and the results are to be used for lifetime
prediction and failure analysis. Under some conditions, the method can be applied to
package-level testing. This method is not intended to check production lots for shipment,
because of the long test time.
Dual damascene Cu metallization systems usually have liners, such as tantalum (Ta) or
tantalum nitride (TaN) on the bottom and sides of trenches etched into dielectric layers.
Hence, for structures in which a single via contacts a wide line below it, a void under the via
can cause an open circuit at almost the same time as any percentage resistance shift that
would satisfy a failure criterion.
2 Normative references
There are no normative references in this document.
NOTE Related documents are listed in the Bibliography.
