IEC 63075:2019

(Main)

Superconducting AC power cables and their accessories for rated voltages from 6 kV to 500 kV - Test methods and requirements

Superconducting AC power cables and their accessories for rated voltages from 6 kV to 500 kV - Test methods and requirements

IEC 63075:2019 specifies test methods and requirements for high-temperature superconducting (HTS) AC power cable systems, cables and their accessories, for fixed installations, for rated voltages from 6 kV (Um = 7,2 kV) up to and including 500 kV (Um = 550 kV).
The requirements apply to single-core, three-core and three-phase concentric cables with cold dielectric and their accessories that are not intended for fault current limitation purposes.
This document does not cover special cables and their accessories, such as fault current limiting cables or submarine cables, for which modifications to the standard tests may be necessary or special test conditions may need to be devised.
This document does not cover test methods and requirements for the cooling system.

General Information

Status
Published
Publication Date
04-Feb-2019
ICS
01 - GENERALITIES. TERMINOLOGY. STANDARDIZATION. DOCUMENTATION
29.060.20 - Cables
Technical Committee
TC 20 - Electric cables
Drafting Committee
PT 63075 - TC 20/PT 63075
Current Stage
PPUB - Publication issued
Start Date
08-Mar-2019
Completion Date
05-Feb-2019
Ref Project

Buy Standard

IEC 63075:2019 - Superconducting AC power cables and their accessories for rated voltages from 6 kV to 500 kV - Test methods and requirementsIEC 63075:2019 - Superconducting AC power cables and their accessories for rated voltages from 6 kV to 500 kV - Test methods and requirements
PreviousNext
Standard
IEC 63075:2019 - Superconducting AC power cables and their accessories for rated voltages from 6 kV to 500 kV - Test methods and requirements
English language
49 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (Sample)

IEC 63075
®

Edition 1.0 2019-02
INTERNATIONAL
STANDARD

colour
inside


Superconducting ac power cables and their accessories for rated voltages
from 6 kV to 500 kV – Test methods and requirements
IEC 63075:2019-02(en)
