IEC 60749-34-1:2025

Semiconductor devices - Mechanical and climatic test methods - Part 34-1: Power cycling test for power semiconductor module

IEC 60749-34-1:2025 describes a test method that is used to determine the capability of power semiconductor modules to withstand thermal and mechanical stress resulting from cycling the power dissipation of the internal semiconductors and the internal connectors. It is based on IEC 60749-34, but is developed specifically for power semiconductor module products, including insulated-gate bipolar transistor (IGBT), metal-oxide-semiconductor field-effect transistor (MOSFET), diode and thyristor.
If there is a customer request for an individual use or an application specific guideline (for example ECPE Guideline AQG 324), details of the test method can be based on these requirements if they deviate from the content of this document.
This test caused wear-out and is considered destructive.

Dispositifs à semiconducteurs - Méthodes d’essais mécaniques et climatiques - Partie 34-1: Essai de cycles en puissance pour modules de puissance à semiconducteurs

L’IEC 60749-34-1:2025 décrit une méthode d’essai utilisée pour déterminer la capacité des modules de puissance à semiconducteurs à résister aux contraintes thermiques et mécaniques du fait du cyclage de la dissipation de puissance des semiconducteurs internes et des connecteurs internes. Elle est basée sur l’IEC 60749‑34, mais est développée spécifiquement pour les modules de puissance à semiconducteurs, y compris les transistors bipolaires à grille isolée (IGBT), les transistors à effet de champ à structure métal-oxyde-semiconducteur (MOSFET), les diodes et les thyristors.
En cas de demande d’un client pour une utilisation individuelle ou une ligne directrice spécifique à une application (par exemple la ligne directrice AQG 324 de l’ECPE), les détails de la méthode d’essai peuvent être basés sur ces exigences s’ils s’écartent du contenu du présent document.
Cet essai provoque une usure et est considéré comme destructif.

General Information

• Status: Published
• Publication Date: 19-Jun-2025
• ICS: 31.080.01 - Semiconductor devices in general
• Technical Committee: TC 47 - Semiconductor devices
• Drafting Committee: WG 2 - TC 47/WG 2
• Current Stage: PPUB - Publication issued
• Start Date: 20-Jun-2025
• Completion Date: 04-Jul-2025

Overview

IEC 60749-34-1:2025 is an international standard developed by the International Electrotechnical Commission (IEC) that specifies a power cycling test method for power semiconductor modules. This standard focuses on evaluating the durability of power semiconductor devices such as Insulated-Gate Bipolar Transistors (IGBTs), Metal-Oxide-Semiconductor Field-Effect Transistors (MOSFETs), diodes, and thyristors under thermal and mechanical stress caused by repeated cycling of power dissipation.

The test simulates real-world operating conditions by inducing temperature fluctuations within the device through controlled power cycling, which stresses internal semiconductor dies and connectors. IEC 60749-34-1:2025 distinguishes between short-time and long-time power cycling tests-each targeting different failure mechanisms relevant to power electronics applications like motor control, robotics, and renewable energy systems.

Being a destructive test method, this standard helps manufacturers and designers evaluate the lifetime and reliability of power semiconductor modules by replicating wear-out phenomena resulting from thermal cycling.

---

Key Topics

• Test Methodology: Guidelines for applying thermal and mechanical stress through power cycling to measure the module’s endurance.
• Device Coverage: Applicable to power modules including IGBTs, MOSFETs, diodes, and thyristors.
• Thermal Stress Simulation: Includes control of virtual junction temperature (T_vj) for short-time tests and case temperature (T_c) for long-time tests.
• Failure Mechanisms: Focuses on joint deterioration between semiconductor die and wire, die attach degradation, and substrate joining layer failures.
• Test Modes:
  • Short-Time Test: Simulates quick temperature cycles found in devices with rapid acceleration and deceleration, stressing internal connections.
  • Long-Time Test: Mimics longer operational cycles, affecting base plates and insulating substrate layers.
• Data Analysis: Employs statistical methods such as Weibull regression and least squares regression to estimate power cycling capability and lifetime.
• Test Setup: Describes required test apparatus, temperature measurement protocols, and circuit configurations for various device types.
• Application-Specific Adaptations: Allows adjustment based on user requests or specific guidelines like ECPE Guideline AQG 324 if they differ from the standard.

---

Applications

IEC 60749-34-1:2025 power cycling testing is critical for industries relying heavily on power semiconductor modules and needing assurance of device reliability and longevity under operational stresses:

• Industrial Motor Drives: Ensures that semiconductor modules powering motors withstand frequent power cycling without premature failure.
• Renewable Energy Systems: Validates robustness of inverters and converters managing fluctuating power loads in solar and wind applications.
• Robotics and Automation: Confirms reliability of modules controlling robotic joints and automation equipment where rapid cycling occurs.
• Electric Vehicles: Supports design validation for power modules in EV drivetrains that experience periodic switching and power load changes.
• Power Electronics Design: Assists engineers in lifetime estimation for product development and quality certification.

Through rigorous and standardized testing, manufacturers can improve product quality, reduce unexpected downtime, and provide users with reliable power semiconductor modules for demanding environments.

---

Related Standards

• IEC 60749 Series: Covers various mechanical and climatic test methods for semiconductor devices, providing a broad framework for reliability and environmental assessments.
• IEC 60749-23: Specifies high-temperature operating life (HTOL) tests which differ from power cycling by simulating stable high temperature stress instead of temperature fluctuations.
• ECPE Guideline AQG 324: An example of a specialized guideline that may be referred to or integrated with IEC 60749-34-1 tests for application-specific requirements.
• ISO/IEC Directives: Provide foundational procedures for standard development which underpin IEC 60749-34-1 creation and maintenance.

---

IEC 60749-34-1:2025 is an essential reference for reliability engineers, semiconductor manufacturers, and product developers seeking to understand and mitigate failure modes in power semiconductor modules through standardized power cycling testing. Adopting this test method supports product certification and helps predict operation lifetime, ensuring safer and more durable power electronic systems.
