IEC 61169-71:2022

Radio-frequency connectors - Part 71: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 5,0 mm - Characteristic impedance 50 Ohms (type NEX10®)

IEC 61169-71:2022, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connector, typically for use in 50 Ω radio communication systems, type NEX10® .
This document describes mating face dimensions for general purpose connectors (grade 2), dimensional details of standard test connectors (grade 1), gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to type NEX10® RF coaxial connectors.
This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.

Connecteurs pour fréquences radioélectriques - Partie 71: Spécification intermédiaire pour connecteurs RF coaxiaux avec conducteur extérieur présentant un diamètre intérieur de 5 mm - Impédance caractéristique de 50 ohms (type NEX10®)

IEC 61169-71:2022, qui est une spécification intermédiaire (SI), fournit des informations et des règles pour l’établissement de spécifications particulières (SP) relatives aux connecteurs RF coaxiaux, généralement utilisés dans les systèmes de radiocommunication de 50 Ω, de type NEX10® [1].
Le présent document décrit les dimensions des interfaces d’accouplement pour les connecteurs à usage général (grade 2), les détails dimensionnels des connecteurs d’essai normalisés (grade 1), les informations relatives aux calibres et les essais choisis à partir de l’IEC 61169-1, applicables à toutes les spécifications particulières relatives aux connecteurs RF coaxiaux de type NEX10®.
Le présent document indique les caractéristiques de performance recommandées à prendre en considération pour la rédaction d’une spécification particulière et elle couvre les programmes d’essai et les exigences de contrôle pour les niveaux d’assurance M et H.

General Information

• Status: Published
• Publication Date: 29-May-2022
• ICS: 33.120.30 - RF connectors
• Technical Committee: SC 46F - RF and microwave passive components
• Drafting Committee: WG 1 - TC 46/SC 46F/WG 1
• Current Stage: PPUB - Publication issued
• Start Date: 30-May-2022
• Completion Date: 24-Jun-2022

Overview

IEC 61169-71:2022 is an international standard developed by the International Electrotechnical Commission (IEC) that specifies the sectional requirements for RF coaxial connectors with an inner diameter of the outer conductor of 5.0 mm and a characteristic impedance of 50 Ohms, specifically the type NEX10®. This standard serves as a guideline for the preparation of detailed specifications used in designing and manufacturing these connectors primarily for use in 50 Ω radio communication systems.

The document covers critical aspects such as mating face dimensions, gauging information, and testing procedures and requirements, providing a comprehensive framework that ensures interchangeability, reliable performance, and quality assessment of RF connectors within the NEX10® series. It caters to connectors operating at frequencies up to 20 GHz, making it particularly relevant for modern radio frequency transmission systems involving RF cables and microstrip circuits.

Key Topics

• Connector Specifications:
  IEC 61169-71:2022 outlines detailed mating face dimensions for general-purpose connectors (Grade 2), including screw type connectors with pin center contacts, quick lock types, and connectors with socket center contacts.

• Gauging and Testing:
  The standard specifies gauge pins and rings, facilitating precision measurement and verification of connector dimensions, ensuring compliance with interface requirements. It adopts test procedures and selected tests from IEC 61169-1, particularly focusing on acceptance and periodic testing which are essential for quality assurance.

• Performance Characteristics:
  Recommended performance parameters are detailed for use when drafting detailed specifications, emphasizing parameters such as electrical, mechanical, and environmental performance to meet high reliability needs.

• Quality Assessment:
  A comprehensive quality conformance framework is included, covering inspection requirements for different assessment levels (M and H), qualification approval processes, and schedules for routine acceptance and periodic testing to maintain connector integrity over time.

• Detailed Specification Guidelines:
  The standard provides instructions for preparing detailed specifications, including identification, marking, ordering information, test selections, and test severities, supporting manufacturers in aligning product development with international benchmarks.

Applications

IEC 61169-71:2022 applies primarily to the design, manufacturing, testing, and quality control of NEX10® RF coaxial connectors used in:

• Radio Communication Systems:
  These connectors ensure reliable signal transmission in communication equipment operating at 50 Ω impedance and frequencies up to 20 GHz.

• RF and Microwave Components:
  They are suitable for applications involving RF cables and microstrip circuits in systems requiring precise impedance matching and low signal loss.

• Test and Measurement Devices:
  The standard’s guidelines on standard test connectors aid manufacturers and test labs in consistent device testing and calibration.

• High-Frequency Industrial Applications:
  Including aerospace, telecommunications, and defense sectors, where robust, high-performance RF connectors are crucial.

Related Standards

IEC 61169-71:2022 complements and references other IEC publications that contribute to a holistic RF connector specification framework:

• IEC 61169-1:
  Provides general test methods and quality assessment procedures applicable to all RF coaxial connectors, forming the foundation for IEC 61169-71’s test requirements.

• IEC 61169 Series:
  Covers a variety of RF connector types, materials, and interfaces facilitating uniformity and interoperability among RF connectors worldwide.

By adhering to IEC 61169-71:2022, manufacturers and system integrators can ensure their type NEX10® RF coaxial connectors meet international standards for dimensional accuracy, electrical performance, and durability, thereby enhancing system performance and reliability in critical radio frequency applications.

---

Keywords: IEC 61169-71, RF coaxial connectors, NEX10®, 50 Ohms impedance, radio-frequency connectors, IEC standards, RF connector specifications, coaxial connector testing, quality assessment, microwave connectors, RF cables, radio communication systems, RF connector gauges, IEC RF connectors, high-frequency connectors.
