IEC 61784-5-3:2018

Industrial communication networks - Profiles - Part 5-3: Installation of fieldbuses - Installation profiles for CPF 3

IEC 61784-5-3:2018 specifies the installation profiles for CPF 3 (PROFIBUS/PROFINET).
This contribution contains a number of related files covering the communication profiles to be used in conjunction with IEC 61918.
This installation profile documents contained herewith provide the installation profiles of the communication profiles (CP) of a specific communication profile family (CPF) by stating which requirements of IEC 61918 fully apply and, where necessary, by supplementing, modifying, or replacing the other requirements. The installation profiles are specified in the annexes. These annexes are read in conjunction with IEC 61918. This fourth edition cancels and replaces the third edition published in 2013. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) an addition of 4-pair cabling (see C.4.4.1.2.1and C.5.3.2);
b) an addition of the connector M12 X-Coding (see C.4.4.2.2);
c) an addition of the definition of End-to-end links (see C.4.4.3.1);
d) a revision of Table C.17 (see C.5.2.1);
e) a formula for the NEXT limits of End-to-end links (see C.6.3.2.1.2).

Réseaux de communication industriels - Profils - Partie 5-3: Installation des bus de terrain - Profils d’installation pour CPF 3

L’IEC 61784-5-3:2018 spécifie les profils d’installation pour la CPF 3 (PROFIBUS/PROFINET) .
Les profils d'installation spécifiques sont donnés dans les annexes. Ces annexes sont utilisées conjointement avec l’IEC 61918:2018.

General Information

• Status: Published
• Publication Date: 25-Mar-2024
• ICS: 01 - GENERALITIES. TERMINOLOGY. STANDARDIZATION. DOCUMENTATION
• ICS: 25.040.40 - Industrial process measurement and control
• ICS: 35.100.40 - Transport layer
• Technical Committee: SC 65C - Industrial networks
• Drafting Committee: JWG 10 - TC 65/SC 65C/JWG 10
• Current Stage: PPUB - Publication issued
• Start Date: 30-Aug-2018
• Completion Date: 03-Aug-2018

Relations

• Amended By: IEC 61784-5-3:2018/AMD1:2024 - Amendment 1 - Industrial communication networks - Profiles - Part 5-3: Installation of fieldbuses - Installation profiles for CPF 3
• Effective Date: 23-Feb-2024
• Revises: IEC 61784-5-3:2013 - Industrial communication networks - Profiles - Part 5-3: Installation of fieldbuses - Installation profiles for CPF 3
• Effective Date: 05-Sep-2023

Overview

IEC 61784-5-3:2018 defines installation profiles for CPF 3 (PROFIBUS/PROFINET) and specifies how the communication profiles in this family are to be installed and verified. This fourth edition (2018) is a technical revision that replaces the 2013 edition. The standard provides annexed installation profiles read in conjunction with IEC 61918 and documents which IEC 61918 requirements fully apply, and where they are supplemented, modified or replaced.

Key updates in the 2018 edition include:

• Addition of 4‑pair cabling support
• Addition of M12 X‑Coding connector guidance
• Definition of End‑to‑end links
• Revisions to key installation tables and a formula for NEXT (near‑end crosstalk) limits on end‑to‑end links

Key topics and requirements

• Scope and structure: Installation profiles for CPF 3 are provided in normative annexes covering CP 3/1, CP 3/2 (PROFIBUS) and CP 3/3–3/6 (PROFINET).
• Installation planning: Network capabilities, topology recommendations, cabling selection, and planning documentation requirements.
• Cabling components: Requirements for cable types (including 4‑pair copper and optical fibre options), shields, connectors (including M12 X‑Coding), terminators and connector pin assignments.
• Earthing and bonding: Recommended shielding and earthing practices for field devices and cables to minimize noise and ensure EMC compliance.
• End‑to‑end links: Definition and measurement/verification methods for assembled links; guidance on crosstalk (NEXT) limits and formulas for compliance.
• Verification and acceptance testing: Resistance and continuity tests, dedicated test circuits, installation acceptance procedures and documentation of “as‑implemented” cabling.
• Conformance and maintenance: Procedures for demonstrating conformance to profiles, administration, troubleshooting and lifecycle maintenance recommendations.

Practical applications and users

This standard is essential for:

• Industrial network designers and system integrators deploying PROFIBUS or PROFINET fieldbus systems
• Electrical and instrumentation installers performing cabling, connectorization and earthing
• Plant engineers and maintenance teams responsible for network acceptance testing, troubleshooting and documentation
• Certification bodies and inspectors verifying installation conformance to CPF 3 profiles

Use cases include factory automation networks, process control installations and machine-level I/O networks where deterministic, reliable fieldbus communications are required.

Related standards

• IEC 61918 - Communication profiles referenced by this installation profile
• Other parts of IEC 61784 (Profiles series) for alternate CPF families and profile definitions

Keywords: IEC 61784-5-3, CPF 3, PROFIBUS, PROFINET, installation profiles, fieldbus installation, M12 X‑Coding, 4‑pair cabling, end‑to‑end link, NEXT, cabling verification.
