IEC TS 63236-1:2021

Direct current (DC) appliance couplers for information and communication technology (ICT) equipment installed in data centres and telecom central offices - Part 1: 2,6 kW system

IEC TS 63236-1:2021(E) applies to DC appliance couplers for class I equipment with two active contacts plus an earthing contact, a rated power of 2,6 kW and a rated voltage range from 294 V to 400 V DC. They are intended to power DC information and communication technology equipment only, as specified in IEC 62368‑1.

General Information

• Status: Published
• Publication Date: 24-Jun-2021
• ICS: 29.120.01 - Electrical accessories in general
• ICS: 29.120.30 - Plugs, socket-outlets, couplers
• Technical Committee: TC 23 - Electrical accessories
• Current Stage: PPUB - Publication issued
• Start Date: 25-Jun-2021
• Completion Date: 27-Jul-2021

Overview

IEC TS 63236-1:2021 is a Technical Specification that defines requirements for DC appliance couplers used to power information and communication technology (ICT) equipment installed in data centres and telecom central offices. It covers a 2.6 kW system for Class I equipment with two active contacts plus an earthing contact, rated for a DC voltage range of 294 V to 400 V. These couplers are intended specifically for powering ICT equipment as specified by IEC 62368‑1.

Key topics and technical requirements

This specification addresses design, safety and verification requirements for DC appliance couplers, including:

• Electrical ratings and classification for a 2.6 kW DC appliance coupler (294–400 V DC).
• Mechanical and dimensional requirements to ensure compatibility and secure mating.
• Protection against electric shock, correct earthing/earth continuity and prevention of single‑pole connection.
• Terminal, cable and cord requirements (rewirable and non‑rewirable types) and cable anchorage tests.
• Insulation resistance and dielectric strength tests to verify electrical safety.
• Temperature rise and resistance to heating tests for connectors and inlets.
• Breaking capacity and normal operation criteria for safe disconnection under load.
• Mechanical strength tests: impact, pull, free-fall and flexing to ensure durability in data centre/telecom environments.
• Material resistance: ageing, heat, fire and tracking performance of insulating materials.
• Electromagnetic compatibility (EMC) requirements for accessories not containing active electronics.
• Marking, legibility, and documentation requirements, plus standard sheets and test gauges (annexes).

Practical applications and who uses this standard

IEC TS 63236-1 is used to ensure safe, interoperable DC power connections in mission-critical ICT environments:

• Connector and cable manufacturers designing DC appliance couplers for data centres and telecom central offices.
• Data centre and telecom infrastructure engineers specifying DC power distribution and rack-level power delivery.
• ICT equipment manufacturers that design devices intended to be powered from DC appliance couplers.
• Testing and certification labs performing electrical, mechanical and environmental tests to verify compliance.
• Procurement and compliance teams ensuring equipment meets IEC safety and interoperability expectations.

Benefits include improved safety, consistent mechanical compatibility, reliable thermal and electrical performance, and simplified installation and maintenance of DC power systems in data centres and central offices.

Related standards

• IEC 62368‑1 - safety requirements for audio/video, information and communication technology equipment (referenced for intended use and equipment classification).
• Other IEC connector and power distribution standards for complementary technical details and testing guidance.
